Summary of Contents for Bush DWSLEINT94W
- Page 1 Instruction manual Dishwasher DWSLEINT94W...
-
Page 2: Help And Guidance
We’re here to help you get the most from your Dishwasher. Should you require any guidance, a simple solution can often be found online at: www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. -
Page 3: Table Of Contents
Programme Table Using your Dishwasher First use of dishwasher Water softener setting Salt and detergent use Rinse-aid usage Loading your dishwasher or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. -
Page 5: Safety Information
Safety information Icon Type Meaning WARNING Serious injury or death risk RISK OF ELECTRIC SHOCK Dangerous voltage risk FIRE Fire risk CAUTION Injury or property damage risk IMPORTANT / NOTE Operating the system correctly... -
Page 6: General Safety Warnings
Safety information Important - Please read these instructions fully before installing or operating. Keep this manual for future reference. 1.1 General Safety Warnings Check that the indoor electrical fuse system is connected in line with safety regulations. Please check the packaging of your All electrical connections must match the machine before installation and the outer surface of values on the plate. - Page 7 You must make sure that the electric cable is positioned safely. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Safety information...
-
Page 9: Getting To Know Your Dishwasher
Getting to know your Dishwasher... -
Page 10: Ready? Let's Begin
Getting to know your Dishwasher You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your dishwasher and ensure safe and correct installation and operation. -
Page 11: Product Overview
If you still require further assistance, call one of our experts on 0345 257 7271. Getting to know your Dishwasher... -
Page 12: Technical Specifications
Getting to know your Dishwasher You’ll be up and running in no time Technical Specifications Capacity place settings Dimensions 815mm Height 448mm Width 550mm Depth Net weight 27,5 kg Operating 220-240V~ 50 Hz voltage / frequency Total power 1760-2100W Water supply Maximum:1.00MPa pressure Minimum:0.04 MPa... -
Page 13: Product Dimensions
448mm Depth (D1) 550mm (with the door closed) Depth (D2) 1150mm (with the door opened 90°) or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Getting to know your Dishwasher... -
Page 15: Installing Your Dishwasher
Installing your Dishwasher... -
Page 16: Installation Requirements
Installing your Dishwasher Bringing it all together 3.3 Water inlet hose 3.1 Positioning your Machine When installing the machine, the mains plug of the power cord and the water tap must be freely accessible. When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. -
Page 17: Connection Of Drain Hoses
"Technical Specifications" table". or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Installing your Dishwasher... -
Page 18: Step 2. Aesthetic Panel's Dimensions And Installation
Installing your Dishwasher Bringing it all together Step 2. Aesthetic panel's dimensions and 6. Level the dishwasher. The rear foot can be adjusted from the front of the dishwasher by turning the Philips screw in installation the middle of the base of dishwasher by a Philips screw driver . -
Page 19: Functions
Functions... -
Page 20: Control Panel
Functions Simple everyday use 4.1 The Control Panel Operation (Button) Power Press this button to turn on your dishwasher. Press this button to select the appropriate washing program, the program indicator will be lit. Program Delay Press the button to set the delay time. Display Intensive Program... -
Page 21: Operating The Machine
3. You can change the program to the desired cycle setting. 3 sec WARNING It is dangerous to open the door mid-cycle, as hot steam may scald you. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Functions... -
Page 22: Programme Table
Functions Simple everyday use Programme Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. Consumption values and program duration are only indicative except for ECO program. ) indicates that the program uses rinse aid in the last rinse. -
Page 23: Using Your Dishwasher
Using your Dishwasher... -
Page 24: First Use Of Dishwasher
Using your Dishwasher Using your Dishwasher Getting the most fr tting the most from y om your applianc our appliance e 5.3. Fill the salt 5.1. Preparing your dishwasher for first use Please follow the steps below for adding dishwasher salt: •... -
Page 25: Water Hardness Table
To find out the hardness level of your tap water, contact your water company or use a test strip (if available). or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Using your Dishwasher... -
Page 26: Filling The Detergent
Using your Dishwasher Using your Dishwasher Getting the most fr tting the most from y om your applianc our appliance e 5.7. Adjusting salt consumption 5.9. Filling the detergent The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of the water used. -
Page 27: 5.11. Rinse-Aid Usage
) will be lit when The default setting is D3. more rinse aid is needed. Do not overfill the rinse aid dispenser. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Using your Dishwasher... -
Page 28: Loading Your Dishwasher
Using your Dishwasher Getting the most from your appliance Loading your dishwasher Upper Basket Height adjustment For best results, follow these loading guidelines. The height of the upper basket can be easily adjusted to Loading the household dishwasher up to the accommodate taller dishes in either the upper or lower basket. -
Page 29: Cutlery Rack
Position of the upper basket: lower position Program: ECO Gravy ladle Rinse aid setting: Max Softener setting: H3 or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Using your Dishwasher... -
Page 31: Care And Maintenance
Care and maintenance... -
Page 32: Spray Arms
Care and maintenance Looking after your appliance Cleaning 6.2. Spray arms Cleaning your dishwasher is important to maintain Make sure that the spray holes are not clogged and that no the machine’s service life. Make sure that the water food waste or foreign object is stuck to the spray arms. If softening setting (If available) is done correctly and there is any clogging,remove the spray arms and clean correct amount of detergent is used to prevent... -
Page 33: Product Support
Product support... -
Page 34: Troubleshooting
Product support Help is always at hand Troubleshooting Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. start circuit break tripped. - Page 35 The dishes were not are not clean loaded correctly. Dishes”. The program was not Select a more intensive program. powerful enough. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
- Page 36 Product support Help is always at hand Troubleshooting Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent, or change your are not clean. was dispensed. detergent. Items are blocking the Rearrange the items so that the spray movement of the spray can rotate freely.
- Page 37 Self-repair or non-professional repair may cause serious risks to the safety of the user of the appliance and impact warranty. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
- Page 38 Product support Help is always at hand AUTOMATIC FAULT WARNINGS AND WHAT TO DO If there is a malfunction the dishwasher will display an error code. The following table shows possible error codes and their causes. Codes Meanings Possible Causes WARNING If overflow occurs,turn off the main water supply before calling a service.
- Page 39 The model information can be retrieved using the QR-code reported in the energy label. The label also includes the model identifier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
-
Page 40: Help And Assistance
Lines open 8am-7pm Monday to Saturday and 10am-4pm Sunday. *Calls to Bush enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tariff. Mobile and other providers costs may vary, see www.bt.com/pricing for details. -
Page 41: Declaration Of Conformance To Product Standards
• Contact a relevant recycling centre to obtain information about disposal of different materials. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support... -
Page 42: Important Data Protection Information
Help is always at hand Call us now and activate your 12 month guarantee Thank you for choosing Bush. Your new product is guaranteed against faults and breakdowns for 12 months. Don’t forget to register it with us today so we can provide you with our best possible after-sales service and useful updates. - Page 43 If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
- Page 44 Produced in China. Argos Limited, London, EC1N 2HT, UK. Argos (N.I.) Ltd., Forestside Shopping Centre, Upper Galwally, Belfast, BT8 6FX, UK. www.argos.co.uk/bush Contact: www.bush-support.com Helpline: 0345 257 7271...
