- Page 1 Installation Guide...
- Page 2 Instructions for use Thank you for purchasing the Nu-Vista UNI PSU by Musical Fidelity. The Nu-Vista UNI PSU is a very special high-quality power supply for the Nu-Vista source devices: the Nu-Vista DAC, Nu-Vista Vinyl 2 and a new soon to be released Nu-Vista CD player.
-
Page 3: Table Of Contents
CONTENTS Section Page – Safety Information Mains plug (UK only), modification warning – General advice Installation precautions – Introduction, cleaning, installation, power connections, spike feet Installation – Facilities and connections Illustrations, front & rear panels – Specifications Product specifications Manual history Item disposal information P a g e... -
Page 4: Safety Information
SAFETY INFORMATION IMPORTANT! (U.K. only) This unit is supplied in the U.K. with mains lead fitted with a moulded 13 amp plug. If, for any reason, it is necessary to remove the plug, please remove the fuse holder and dispose of the plug safely, out of reach of children. -
Page 5: General Advice
Do not remove any covers or try to gain access to the inside. There are no internal adjustments or fuses you can replace yourself. Refer all service work to an authorised Musical Fidelity agent. * Note: Unauthorised opening of the equipment will invalidate any warranty claim. -
Page 6: Installation
INSTALLATION Cleaning Before cleaning the unit, switch off power at the mains switch and remove the mains plug from the wall socket. Clean the cabinets using a moist cloth. Using solvents, white spirit or thinners is not advised, as they could damage the surface finish. - Page 7 INSTALLATION Example for Nu-Vista Vinyl 2 power connection using Nu-Vista UNI PSU: Don’t connect when using Nu-Vista UNI PSU! Important notes: Only switch the Nu-Vista UNI PSU on using the ON/OFF switch on the back panel once ALL connections are made. Only connect or disconnect power cables when the ON/OFF switch on the Nu-Vista UNI PSU is set to OFF! If the LH and RH POWER cables are wrongly or not connected, the Nu-Vista Vinyl 2, DAC or CD...
-
Page 8: Facilities And Connections
FACILITIES & CONNECTIONS 1 NU-VISTA VINYL 2 POWER / STANDBY 3 NU-VISTA DAC POWER / STANDBY button button 2 NU-VISTA CD POWER / STANDBY button 4 NU-VISTA DAC RH POWER output 10 NU-VISTA VINYL 2 RH POWER output 5 NU-VISTA DAC CONTROL output 11 NU-VISTA VINYL 2 CONTROL output 6 NU-VISTA DAC LH POWER output 12 NU-VISTA VINYL 2 LH POWER output... -
Page 9: Specifications
4x Spike Foot Cup 4x Spike Foot Screw 4x Felt pad for Spike Foot Cup 4x Felt pad for Standard Foot Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice. P a g e... - Page 10 DISPOSAL INFORMATION RELEASE DATE CHANGES 2024 Nu-Vista UNI PSU June issue, incl. power cables added DISPOSAL The crossed out wheeled bin label that appears on the back panel of the product indicates that the product must not be disposed of as normal household waste. To prevent possible harm to the environment please separate the product from other waste to ensure that it can be recycled in an environmentally safe manner.
- Page 11 Musical Fidelity www.musicalfidelity.com S S pecifications and details are correct as we go to press, but in the interests of product improvement they may be subject to change during manufacture.
