Musical Fidelity V-PSUII Instructions

V-PSU

Power Supply Unit

II
Instructions
Connections
All connections must be made before the mains adaptor is
plugged in, and before any amplifier connected is switched
and
on. Always switch off the V-PSU ( connected amplifiers
II
etc) before connecting/disconnecting power, or changing
leads.
Power Inputs
Using figure-8 moulded mains lead (supplied), connect the
V-PSU to a mains socket.
II
Power Outputs
Using 1.3mm DC plug to plug lead(s) (supplied), connect
the V-PSU 12VDC OUTPUTS to the V-series units as
II
required.
Use
Connect up the V-series components audio inputs and
outputs as required.
Switch on the V-PSU using the rocker switch next to the
II
mains input socket.
The three individual output LEDs should light indicating
presence of power at the respective output.
Switch on attached components (amplifiers etc).
Turn the volume on amplifier to normal listening levels, sit
back and enjoy the music.
These products have been designed so that it may be left
on indefinitely, but please note that the V-PSU
II
become warm to the touch - this is normal.
Note: The V-PSU can also be used to power older V-series
II
components.
may
Introduction
Thank you for purchasing the V-PSU power
II
supply unit. We sincerely hope that it will
bring you many years of outstanding
listening pleasure.
Installation Precautions
Your new V-PSU is designed and built to
II
provide trouble-free performance, but as with
all electronic devices, it is necessary to
observe a few precautions:
Do not use the V-PSU near water. The unit
II
must not be exposed to dripping or splashing
and no objects filled with liquids, such as
vases, must be placed on the unit.
Keep the V-PSU away from heat such as
II
radiators. No naked flame sources, such as
lighted candles, should be placed on the
unit.
Front and back connections
Power output sockets
and indicator LEDs
This product has been tested to ensure that
its operation is not adversely affected by
normal background levels of Radio
Frequency Interference (R.F.I.), and that it
does not itself generate excessive amounts
of interference. However, if a problem
persists, please contact your Musical Fidelity
agent.
Never open the case of the V-PSU
yourself, as this will invalidate the guarantee.
Place all connecting cables where they are
not likely to be walked on or trapped by
items placed on them.
The V-PSU will operate in accordance with
II
its specifications within the following
environmental range:
Temperature 5 to 45 degrees Celsius
Humidity 10 to 90% non condensing
There are no user adjustments inside.
Please refer all service work to
authorised Musical Fidelity agent.
Power switch
Power input socket
II
