dji RONIN 4D FLEX Faq

FAQ
How long is the extension cable of Ronin 4D Flex?
2 m.
Can I use the extension cable of Ronin 4D Flex in series?
No. Using the cable in series will destabilize the camera link and may lead to frame drops.
What product is Ronin 4D Flex applicable to?
Ronin 4D Flex is only applicable to DJI Ronin 4D. It enables the X9 gimbal camera to be used
independently from the Ronin 4D main body.
You can mount accessories like the left and right Hand Grips of Ronin 4D, the Ronin 4D High-Bright Main
Monitor, and the DJI RS Focus Motor (2022) to the extended gimbal connector module.
Does Ronin 4D Flex support dual focus motors?
Yes. Ronin 4D Flex supports up to three focus motors.
To use the DJI RS Focus Motor (2022) for controlling zoom, focus, or aperture, mount the DJI RS Focus
Motor (2022) to the extended gimbal connector module, update the focus motor to the latest firmware,
and connect it to the USB-C port on the bottom of the gimbal. <br>
Focus motors can be used in series.
How do I mount the High-Bright Main Monitor onto Ronin 4D Flex?
1. Remove the main monitor from the Ronin 4D main body. Loosen the screws of the main monitor
pivot using a hex key. Attach the pivot to the lower mounting ports of the monitor, and fasten the
screws.
2. Connect the main monitor cable to the Display Port on the gimbal connector module of Ronin 4D Flex.
Attach the main monitor to the cold shoe of the gimbal connector module and tighten the screw.
3. Connect the Hand Grip Adapter to the CAN ports of Ronin 4D Flex.
4. Press and hold the power button on the gimbal connector module to turn on/off Ronin 4D. After
powering on, press the power button on the gimbal connector module once to start/stop recording.
