  • Page 1 RoboMaster Expansion Module User Manual v1.0 2022.04...
  • Page 2 Quick Keyword Search Use the Find function to search a keyword. If you are using Adobe Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to start a search. Navigating to a Topic View a complete list of the topics in the table of contents. Click on a topic to navigate to that section.
  • Page 3: Table Of Contents

    Contents Introduction Component Descriptions Dimensions Using the Module Installation Acquiring and Saving AI Core Module Video Streams Firmware Update Specifications © 2022 DJI All Rights Reserved.
  • Page 4: Introduction

    ROBOMASTER EP in conjunction with the AI Education Set. Users can program blocks with the Rogram platform on the DJI Education Hub or program codes using the Python SDK to enable a wide range of AI applications on the RoboMaster EP.
  • Page 5 RMEP using a CAN cable to power up the Expansion Module and communicate with the CAN on RMEP. When used with the AI module, this port must also be connected for the AI module functions to be accessible on RMEP. See the AI Education Set User Manual for details. © 2022 DJI All Rights Reserved.
  • Page 6: Dimensions

    See the “Acquiring and Saving AI Core Module Video Streams” section for details. 8. 100-Pin Expansion Port Reserved expansion port. Dimensions 58.00 58.00 40.00 40.00 5.20 5.20 4-M2 4-M2 24.00 24.00 48.00 48.00 2-M3 3.20 2-M3 3.20 15.00 15.00 Unit: mm © 2022 DJI All Rights Reserved.
  • Page 7: Using The Module

    (M3) at the bottom of the Module. After the devices are connected, the user can acquire AI recognition results and program robot controls with the Python SDK or the Rogram editor of the DJI Education Hub, to run AI-related applications. Acquiring and Saving AI Core Module Video Streams Users can acquire images from the AI core module through the micro USB port of the Expansion Module.
  • Page 8: Specifications

    Button × 2, indicator × 4, SD card slot × 1 Operating Temperature 0° to 45° C * Tested in a well-ventilated lab environment at a room temperature of 25° C (77° F). WWW.ROBOMASTER.COM are trademarks of DJI. Copyright © 2022 DJI All Rights Reserved.
