Parts Included
6
Lag Screw
SS-10.1006
Wall Anchor
6
SS-10.1002
6
Spacer
SS-10.1007
Bolt (M10-1.5 x 55)
4
SS-10.1077
Washer
4
SS-10.1009
1
Rail
SS-10.1146
Recommended Tools
Wrench/Socket
1/2" (13mm)
9/16" (14mm)
11/16" (17mm)
● READ ALL INSTRUCTIONS AND CHECK PARTS BEFORE STARTING INSTALLATION
Planning
● RETAIN ALL PACKING MATERIALS UNTIL INSTALLATION IS COMPLETE
NOTE: This kit is best suited for doors up to 1-
150 pounds.
Before installing the Rail, identify secure points to attach the Rail.
For most wall installations, it is necessary that the Lag Screws are secured to wall studs.
96" [2040mm]
A
A
B
Door
Height
(H)
A - 16" [406mm]
3
/
B - 8" [204mm]
Barn Door Rail Kit
Installation Manual
Nut (M10-1.5)
4
SS-10.1010
Floor Anchor
4
SS-10.1011
4
3/4" Screw
2
SS-10.1075
Drill Bit
Allen Wrench
3/32"
3/8"
7/32"
7/16"
1/4"
A
A
A
" [9.5mm] Gap
8
2
Door Guide
SS-10.1013
2
1-1/4" Screw
SS-10.1012
2'-3' Level
3mm
3
/
" thick, up to 44" wide, and no more than
8
For Lag Screws that cannot be secured to a
wall stud, it will be necessary to use the
Wall Anchors to secure the Lag Screws
into the wall.
B
Home construction varies; holes may be
added to the Rail to allow Lag Screws
to attach to wall studs.
IMPORTANT:
(H)
plus
If at least FOUR Lag Screws cannot
1-
5
/
"
8
be secured to wall studs or other
[41.5mm]
structural points, DO NOT INSTALL
THIS RAIL KIT.
W-KIT-2-BK-1PC-96
2
Door Stop
SS-10.1005
Anti-Jump Pad
SS-10.1076
Power Drill
4310487
Iron Black
2
Marion
Trolley
SS-20.1078
Tape Measure
12'
