Mirka
LEROS(-S)
950
230V
CV - Models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEROS 950 and is the answer not in the manual?

Questions and answers

Related Manuals for MIRKA LEROS 950

Summary of Contents for MIRKA LEROS 950

  • Page 1 ® Mirka LEROS(-S) 230V CV - Models...
  • Page 2 Exploded view LEROS 950CV Handle Mirka® LEROS(-S) & 950...
  • Page 3 Mirka® LEROS(-S) & 950...

  • Page 4: Exploded View

    Exploded view LEROS 950CV Grinding head Mirka® LEROS(-S) & 950...
  • Page 5 Mirka® LEROS(-S) & 950...
  • Page 6 Screw M4 x 50 mm 1,4 Nm/1,0 ft-lb Joint Fork Lock Nut M4 NOTE! Repairs done by non-authorized repairer will breach the Mirka warranty. Electrical tools must be serviced by a qualified repair person and in accordance with national requirements. Mirka® LEROS(-S) & 950...
  • Page 7 Fan Washer M5 MIW9513511 Dynamic Weight MIW9513711* Motor Assembly 230V* Lock Nut M3 1,4 Nm/1,0 ft-lb MIW9513911 Fairing Screw STS 2,5 x 8 mm T+/-8 0,8 Nm/0,6 ft-lb Screw M3 x 12 mm MIW9514211 Brake Seal Mirka® LEROS(-S) & 950...
  • Page 8 O-Ring 7,65 x 1,78 mm Joint Screw M5 x 8 mm 4 Nm/3 ft-lb Screw M4 x 50 mm 1,4 Nm/1,0 ft-lb Joint Forks Lock Nut MIW9525711 Spindle + Bearing Assembly Spare parts only available to authorized repairers. Mirka® LEROS(-S) & 950...
  • Page 9 Exploded view LEROS-S 950CV Handle Mirka® LEROS(-S) & 950...
  • Page 10 Mirka® LEROS(-S) & 950...
  • Page 11 Exploded view LEROS-S 950CV Grinding head Mirka® LEROS(-S) & 950...
  • Page 12 Mirka® LEROS(-S) & 950...
  • Page 13 4 Nm/3 ft-lb MIW9525411 Joint Fork kit with Handle Screw 3 x 14 mm 0,8 Nm/0,6 ft-lb Screw M4 x 50 mm 1,4 Nm/1,0 ft-lb Lock Nut M4 Joint Fork with Handle Right Joint Fork with Handle Left Mirka® LEROS(-S) & 950...
  • Page 14 NOTE! Repairs done by non-authorized repairer will breach the Mirka warranty. Electrical tools must be serviced by a qualified repair person and in accordance with national requirements. Mirka® LEROS(-S) & 950...
  • Page 15 Screw STS 2,5 x 8 mm T+/-8 0,8 Nm/0,6 ft-lb Screw M3 x 12 mm MIW9514211 Brake Seal MIW9514312 Backing Pad 225mm (Grip & Screw Mounting of Interface) MIW9514411 Pad Screw 10 Nm/7,4 ft-lb Cover Cap Mirka® LEROS(-S) & 950...
  • Page 16 MIW9525711 Spindle + Bearing assembly Type Label Power Socket assembly MIW9519411 Tube (Short) MIW9519511 Power and Signal Cable (Short) Joint Fork with Handle, right Joint Fork with Handle, left Spare parts only available to authorized repairers. Mirka® LEROS(-S) & 950...
  • Page 17 Button plate Gripping surface Power cord Hose connection Pad Medium Code 225 mm (9") Grip MIW9514312 Break seal Backing pad Figure 2 Multi purpose LED On/off button Speed indication (rpm) Speed – Speed + Start / Stop Mirka® LEROS(-S) & 950...

  • Page 18: Declaration Of Conformity

    Mirka Ltd, 66850 Jeppo, Finland declare under our sole responsibility that the Mirka® products (listed below and see "Technical data" table for particular model) to which this declaration relates are in conformity with the following standards or other normative documents: EN 62841-1:2015, EN 62841-2-4:2014, EN 55014-1:2017, EN 55014-2:1997 + A1:2001 + A2:2008, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 300 328 V2.2.2, EN 301 489-1 V2.1.1,...

  • Page 19: General Power Tool Safety Warnings

    Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. Mirka® LEROS(-S) & 950...

  • Page 20: Additional Safety Warnings

    Always refit the cover cap after installing the backing pad. The power supply socket and connector are non-IEC appliance couplers. Only use an original Mirka power supply cable. The Mirka power supply cable can be bought from your Mirka Dealer.

  • Page 21: Work Stations

    (220 240 VAC, 50 60Hz). In order to get the maximum power from this tool it is recommended to use it with the Mirka dust extractor (or other suitable dust extraction unit) and Mirka net sanding products. The combination of Mirka sanders, Mirka net sanding products and Mirka dust extractor are the basis of Mirka dust-free sanding solutions.

  • Page 22: Maintenance

    ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Mirka Ltd is under license. Other trademarks and trade names are those of their respective owners. Maintenance Always disconnect the power before maintenance!

  • Page 23: Troubleshooting Guide

    Servicing must always be performed by trained personnel. To keep the tool warranty valid and ensure optimal tool safety and function, servicing must be carried out by a Mirka authorized service centre. To locate your local Mirka authorized service centre, contact Mirka Customer Service or your Mirka dealer.
  • Page 25 Russia Mirka Rus LLC Singapore Mirka Asia Pacific Pte Ltd Spain Mirka Ibérica S.A.U. Sweden Mirka Scandinavia AB Turkey Mirka Turkey Z mpara Ltd Şirketi United Kingdom Mirka (UK) Ltd United Arab Emirates Mirka Middle East FZCO USA Mirka USA Inc.

This manual is also suitable for:

Leros-s 950Leros 950cvLeros-s 950cvMiw95021baan
