AEV FRONT SKID RAM HEAVY DUTY Installation Manual

PLEASE READ ENTIRELY BEFORE YOU START

To guarantee a quality installation, we recommend reading these instructions thoroughly

before beginning any work. These instructions assume a certain amount of mechanical

ability and are not written nor intended for someone not familiar with auto repair.

NOTE: 3500 Trucks require a supplemental hardware kit.

AEV Part Number: 110602112AA

AEV30440AA

Last Updated: 02/23/21

FRONT SKID

RAM HEAVY DUTY

TABLE OF CONTENTS

I. Disassembly

II. Installation

REQUIRED TOOLS

Common Hand Tools

Table of Contents

Do you have a question about the FRONT SKID RAM HEAVY DUTY and is the answer not in the manual?

Page 1 TABLE OF CONTENTS I. Disassembly II. Installation REQUIRED TOOLS Common Hand Tools NOTE: 3500 Trucks require a supplemental hardware kit. AEV Part Number: 110602112AA AEV30440AA Last Updated: 02/23/21...
Page 3 A M E R I C A N E X P E D I T I O N V E H I C L E S DISASSEMBLY If your vehicle is equipped with compatibility beams (fig. 1)., remove the four bolts securing them to the frame.
Page 4 E X P E D I T I O N V E H I C L E S II. INSTALLATION Loosely install the two AEV brackets using either the factory hardware saved in step one, or the AEV supplemental hardware kit PN: 110602112AA (fig. 3). Figure 3 With a helper or use of a floor jack, lift the tubular skid into position.
Page 5 A M E R I C A N E X P E D I T I O N V E H I C L E S Lift the Closeout Plate into place and loosely install the two M10 x 35 carriage bolts through the closeout bracket and the bottom of the compatibility beam brackets.
