Summary of Contents for Satel ASW-200
- Page 1 ASW-200 Smart plug Firmware version 1.00 asw-200_en 11/21 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 20 www.satel.eu...
- Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
- Page 3 CONTENTS Features ........................... 2 Description ........................2 Radio communication ....................... 3 Operating modes ......................3 Protection against overload and overheating ..............3 LED indicator ........................4 Start-up ..........................4 Configuring the LED indicator settings ................5 Starting configuration mode ....................5 Configuring ........................
- Page 4 ASW-200 SATEL The ASW-200 smart plug is used to remote control electrical appliances. The device is available in two versions: ASW-200 E with E type socket (EURO), ASW-200 F with F type socket (SCHUKO). The plug is designed for operation within the ABAX 2 / ABAX two-way wireless system.
- Page 5 The button is also used to configure the LED indicator (see “Configuring the LED indicator settings”). LED indicator. Radio communication The ASW-200 plug connects to the controller / control panel at regular time intervals to provide information about its state (periodical communication). Additional communication takes place when: the plug button is pressed, ...
- Page 6 LED indicator configuration mode. 3. Start-up The ASW-200 plug should be used indoors, in spaces with normal air humidity. When in use, the plug must be located within the radio range of the controller / control panel. Thick walls, metal partitions, etc.
- Page 7 SATEL ASW-200 4. Configuring the LED indicator settings You can configure the LED indicator by using the button on the plug enclosure. The LED indicator can: indicate the current consumption by the appliance when it is turned on: – the indicator color changes smoothly from blue to green – current consumption by appliances up to 300 W (current consumption up to 1.3 A), where: blue –...
- Page 8 ASW-200 SATEL Dimensions: ASW-200 E ....................ø45 x 67 mm ASW-200 F ....................ø45 x 70 mm Weight: ASW-200 E ......................... 60 g ASW-200 F ......................... 61 g...
