Service Manual_2018-V2.0
Service Manual
COMPACT SERIES
Applicable Models
Model Code
Applicable Models
HS-173FN
CE-BC133CM-SQ
22031010003102
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea COMPACT HS-173FN
Summary of Contents for Midea COMPACT HS-173FN
- Page 1 Service Manual_2018-V2.0 Service Manual COMPACT SERIES Applicable Models Model Code Applicable Models HS-173FN CE-BC133CM-SQ 22031010003102 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer to accumulate through the daily work.
- Page 2 Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof. Midea Refrigerators Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Refrigerators.
-
Page 3: Table Of Contents
Service Manual_2018-V2.0 Contents 1. SIGNIFICANT UPDATE NOTES (NONE) ......................5 2. SAFETY WARNING CODE ............................6 2.1 W ARNING FOR OPERATION SAFETY ........................... 6 2.2 S AFETY INSTRUCTION FOR REFRIGERANT ......................... 8 3. TRANSPORT ................................9 3.1 H ANDLING ................................... 9 4. INSTALLATION AND COMMISSIONING ......................10 4.1 D ISASSEMBLY AND SSEMBLY... - Page 4 Service Manual_2018-V2.0 10.4 D ............................27 EFROSTING FUNCTION 10.5 B （N ） ......................27 ACKUP DATA FOR POWER FAIL 11. COMPRESSOR ..............................28 11.1 C OMPRESSOR ON AND OFF ONTROL SPECIFICATIONS ..................28 12. TROUBLESHOOTING METHOD ........................29 12.1 N OT COOLING ..............................
-
Page 5: Significant Update Notes (None)
Service Manual_2018-V2.0 1. Significant update notes (None) -
Page 6: Safety Warning Code
Service Manual_2018-V2.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. - Page 7 Service Manual_2018-V2.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
-
Page 8: Safety Instruction For Refrigerant
Service Manual_2018-V2.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance. -
Page 9: Transport
Service Manual_2018-V2.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: Installation And Commissioning
Service Manual_2018-V2.0 4. Installation and commissioning 4.1 Door Disassembly and Assembly The refrigerator door needs to be dismantled if it cannot enter the room in the whole. 4.2 Installation location Installation location Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption. -
Page 11: Left Or Right Open Door Reversal
Service Manual_2018-V2.0 4.4 Left or right open door reversal Door reversal Unscrew the top cover screws Remove the top cover 3) Remove the hinge cover. Unscrew screws. Remove the upper hinge. Remove the door. Unscrew screws and levelling feet. Remove the lower hinge adjust feet assembly. Fix the levelling feet, lower hinge adjust feet assembly and screws in the opposite side. -
Page 12: Installation Of Handle（None
Service Manual_2018-V2.0 Place the door stopper and axle sleeve in the opposite side. Place the F door. Place and fix the upper hinge. Fix the hinge cover. Place the top cover. 4.5 Installation of handle（None） 4.6 Installation of door lock（None）... -
Page 13: Product Configuration And Dimension
Service Manual_2018-V2.0 5. Product configuration and dimension 5.1 Main parts and their names (The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber None 1. Temperature control box 2. Screen printing knob 3. -
Page 14: External Dimension
Service Manual_2018-V2.0 5.2 External dimension Code Size (mm) Description Height to Top of Case Width Depth w/Cabinet Depth w/Door Depth w/Handle Depth (Door open 90 deg. w) 1078 Depth (Door open 135 deg. w) Width (Door open 135 deg. w) (The picture is only for reference) -
Page 15: Location Of S/N
Service Manual_2018-V2.0 5.3 Location of S/N Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 16: Product Specification
Service Manual_2018-V2.0 6. Product specification 6.1 Electrical parameters Applicable Models HS-173FN Product Name CE-BC133CM-SQ Product Code 22031010003102 Item Specification Specification Refrigerant R600a Compressor SZ45Y1J Starter(PTC) QPS2-B15MG1 Overload protector(OLP) DRB12N61A1 Integrate PTC+OLP ZHB31-120P15 Variable frequency driver board None Capacitor None Power filter None Rmc：51.5±7%Ω... -
Page 17: Circuit Diagram
Service Manual_2018-V2.0 6.3 Circuit diagram Thermostat Overload Protector Power Plug Compressor... -
Page 18: Refrigerating Piping System And Circulating Route Of Cooling Air
Service Manual_2018-V2.0 7. Refrigerating piping system and circulating route of cooling air 7.1 Refrigerating piping system Compressor---Left condenser----Right condenser---Dry filter---Capillary tube---evaporator---Suction tube---Compressor (The picture is only for reference, and specific appearance and configuration are subject to the real product) -
Page 19: Dismantling Of Parts
Service Manual_2018-V2.0 8. Dismantling of parts 8.1 Parts on the door Door seal Door seal is installed into door liner groove. 1） Open the refrigerator door; Take the door seal ①out of door liner; Door tray Lift up the bottle frame and take it out from the door liner of the refrigerator. -
Page 20: Light System
Service Manual_2018-V2.0 Drawer The drawer is located at the bottom of refrigerating chambers; 1） Pull the drawer out completely; Lift it up slightly and take it out from the refrigerator. 8.3 Light system Light • The light at the left of refrigerator chamber 1、Remove the light cover 2 、... -
Page 21: Evaporator And Defrost System (None)
Service Manual_2018-V2.0 Light switch There is a light switch on the side wall of the refrigerating chamber. Loosen the hook with small normal screwdriver and pull out the switch until the wire connector reveals. 8.4 Evaporator and Defrost system (None) 8.5 Compressor case Rear cover and compressor case None... - Page 22 Service Manual_2018-V2.0 4-1）Remove the screws(for some models) -Two screws outside -One screw inside 4-2）Remove the metal clamp(for some models) -Disassembly the metal clamp that is fix the electric appliance shield 5）Remove the clipping strip Slowly pull it out 6）Remove the protective cover -Pry the protective cover slowly from the upper part, -Pull it out and remove it.
- Page 23 Service Manual_2018-V2.0 8）Loosen the screw of the compressor bottom plate, remove the floor together with the compressor from the box. 9）Use the wrench to remove the bolts by steps❹❺❻❼, replace the compressor and reverse process can complete installation. 10）Use Pipe cutter cut off the condenser tube❽, then Shear off capillary ❾...
- Page 24 Service Manual_2018-V2.0 12）Replace the filter, Cu-Fe tubes welding ⓭ used Ag welding rod, Cu-Cu tubes welding ⓮ used Cu welding rod. 13）Vacuum system,The degree of vacuum below 6Pa. 14）Perfusion refrigerant. 15）Use the vise grip pliers clamp the middle of the process pipe, then seal welding process tube⓯⓰.
- Page 25 Service Manual_2018-V2.0 Drain tray...
-
Page 26: Temperature Sensing System
Service Manual_2018-V2.0 9. Temperature sensing system 9.1 Thermostat Thermostat 1. Remove the screw on the thermostat assembly thermostat Loosen the knob and fastening thermostat screw, and remove the box assembly Remove the connector and replace the thermostat. -
Page 27: Function And Operation
Service Manual_2018-V2.0 10. Function and operation 10.1 Operation panel Direct cooling mechanical refrigerator, through the thermostat knob to adjust the stalls. 10.2 Temperature setting Turn the temperature control knob to MAX, the internal temperature of the refrigerator becomes lower. Turn the temperature control knob to MIN, the internal temperature of the refrigerator becomes higher. 10.3 Open door alarm（None）... -
Page 28: Compressor
Service Manual_2018-V2.0 11. Compressor 11.1 Compressor on and off Control specifications 1.1 When one of the following conditions is met, the compressor stops: 1) Tr ≤ Trt； 2) The compressor runs continuously for more than 3 hours (Stop 5 minutes); 1.2 When all the following conditions are met, the compressor starts up: 1) Tr ≥Trk;... -
Page 29: Troubleshooting Method
Service Manual_2018-V2.0 12. Troubleshooting Method 12.1 Not cooling... -
Page 30: No Working Of Compressor
Service Manual_2018-V2.0 12.2 No working of compressor 12.3 Thermostat malfunction-Undercooling... -
Page 31: Inside Frosting, No Defrosting
Service Manual_2018-V2.0 12.4 Inside frosting, no defrosting 12.5 Inside frosting, no defrosting-Maintenance guidelines... -
Page 32: Light Is Not On
Service Manual_2018-V2.0 12.6 Light is not on... -
Page 33: Noise
Service Manual_2018-V2.0 12.7 Noise... -
Page 34: Figures And Details Of Repair Parts
Service Manual_2018-V2.0 13. Figures and details of repair parts See this section in the TSP. - Page 35 MIDEA appliances after sales website tsp.midea.com For more information about Midea appliances after sales, please visit the tsp.midea.com For more information about the service manual, please visit the tsp.midea.com For more information about the EV and SBOM, please visit the...
