Summary of Contents for Thermokon JOY
- Page 1 Manual...
- Page 2 Manual Joy KNX Revision Revision Date Joy KNX So�ware Descrip�on Author 31.07.2024 SW-Ver. 1.0.x • First Release JD, NL, HoH Thermokon Sensortechnik GmbH 2 / 28...
-
Page 3: Table Of Contents
Manual Joy KNX Table of contents 1. General informa�on and safety instruc�ons ..............5 1.1. Intended use ..................................5 1.2. Non-intended use ................................. 5 1.3. Limita�on of liability ................................5 1.4. Support ....................................5 2. Func�onal descrip�on ......................6 2.1. Device versions ..................................6 2.1.1. - Page 4 Manual Joy KNX Table of contents 4.1.3. Outputs ..................................16 4.2. Regelung ..................................... 17 4.2.1. PI-controller .................................. 17 4.2.2. Two-point controller ..............................17 4.2.3. Valve protec�on func�on .............................. 17 4.3. Opera�ng modes ................................18 4.3.1. Room opera�ng mode Comfort (occupied) ........................18 4.3.2.
-
Page 5: General Informa�On And Safety Instruc�Ons
Manual Joy KNX 1. General informa�on and safety instruc�ons A prerequisite for safe working is compliance with the specified safety instruc�ons and handling instruc�ons. The installa�on and assembly of electrical devices (modules) may only be carried out by an authorised electrician. -
Page 6: Func�Onal Descrip�On
Ausführung, der Ansteuerung eines 3-stufigen Lü�ers bzw. eines EC-Fan Coils (0-10V). Die Variante ist für Gebläse Konvektoren mit 2- und 4- Rohrsystemen ausgelegt. Die HC-Variante ist ein reines Thermostat. Die Joy KNX Geräte sind mit einem Temperatur- und Feuchte-, sowie op�onal mit einem CO2-Sensor ausgerüstet. -
Page 7: Screen
Manual Joy KNX 2.2. Screen The Screen is divided into three areas: Header, Value Screen and Footer. Value Screen ECO-Func�on 13:41 06.08.25 GO 55 (Input), 54 (Output) Internal sensor values ECO inac�ve = 0 | ECO ac�ve = 1 23.3 External sensorvalues °C... -
Page 8: Header
Manual Joy KNX 2.2.2. Header The header is used to display the date and �me. An info symbol is also displayed here if required or depending on certain states/modes. Date & Time (General > Date & Time) The date and �me display can be switched on and the display format selected in drop-down menus. Synchroniza�on of the currently valid values (date & �me) can be ac�vated or deac�vated. -
Page 9: Bu�Ons
Manual Joy KNX 2.3. Bu�ons There are bu�ons on the touch surface for opera�ng the configured func�ons. Pressing the bu�on once triggers an ac�on. A long press of the bu�on causes a value to change cyclically at 0.5s intervals.Each �me the bu�ons are pressed, the ring on the power bu�on lights up as bu�on feedback. -
Page 10: Installa�On, Commissioning & Configura�On
KNX standard. The device starts a�er the power supply is switched on. Further Informa�on is documented in the applicable data sheet. Joy Fancoil 5DO KNX Joy Fancoil EC 3AO KNX Joy Fancoil EC AO2DO KNX ϑ... -
Page 11: Commissioning
Valid device so�ware file is recognized and the installa�on process is started (ring ligh�ng flashes at 300ms intervals) New device so�ware is started a�er installa�on (approx. 20-30 seconds). Remove the upper part to remove the MicroSD card from the device! Addi�onal informa�onen via www.thermokon.de Thermokon Sensortechnik GmbH 11 / 28... -
Page 12: Ets Applica�On Program
Manual Joy KNX 3.3.2. ETS Applica�on program The configura�on or parameteriza�on is carried out - as is typical for KNX - via ETS. (ETS5.0 or higher) When parameterizing/configuring the devices, you should always proceed “from top to bo�om” in the menu. -
Page 13: Parameter Menu
Manual Joy KNX 3.4. Parameter menu The parameter menu contains the basic se�ngs of the device. Configura�on is carried out directly on the device. 3.4.1. Access parameter menu The parameter menu is accessed via the following bu�on combina�on: center le�, up, center right Manual access to the parameter menu can be blocked via the ETS. -
Page 14: Forced Calibra�On Co2 Sensor
Manual Joy KNX Menu → Allg. Einstellungen Configura�on of the contrast values, as well as the factory se�ng op�on Menü Einstellungen Werkseinstellung Uhrzeit/Datum Werkseinstellung Kontrast Sensor Einstellungen Allg. Einstellungen 1.1.1 KNX-Adresse: Werkseinstellung Factory Reset When the factory se�ng is selected, the room thermostat performs a restart and is reset to the delivery status. -
Page 15: Func�Onal Descrip�On (Controller)
Manual Joy KNX 4. func�onal descrip�on (controller) 4.1. Device func�ons 4.1.1. Sensors Sensor measured values can be read out via KNX or shown on the display. A variant-specific configura�on corresponding to the hardware version is required via the ETS. Temperature By default, the value of the internal temperature sensor is used as the actual value for the internal controller. -
Page 16: Outputs
Manual Joy KNX 4.1.3. Outputs The outputs are assigned fixed func�ons. Depending on the device type, these can be manually overridden in different ways. For example, the digital outputs can only be manually overridden in conjunc�on with the controller mode or the fan speed. The analog outputs can be used freely. -
Page 17: Regelung
Joy KNX 4.2. Regelung The JOY has a PI or two-point controller for hea�ng and cooling. The control variable is output via the relays/outputs. The controller starts a�er a cold start (voltage on) of the device with a 30-second delay. -
Page 18: Opera�Ng Modes
Manual Joy KNX 4.3. Opera�ng modes The opera�ng modes are switched via communica�on objects (KO), opera�ng procedures, inputs or internal func�ons and are divided into two groups: Room opera�ng modes: Comfort (occupied) | Standby (unoccupied) | ECO | Building Protec�on (frost protec�on/heat protec�on) Device opera�ng modes: Sleep mode | Keycard mode... -
Page 19: Ets- Configura�On Parameter
Manual Joy KNX 5. ETS- Configura�on parameter The following parameters are shown/hidden depending on the version and configuration. 5.1. Configura�on parameter „General“ PARAMETERPAGE PARAMETER DESCRIPTION Device name Maximum 24 ASCII characters. Device type selec�on: - FC 5DO - HC AO2DO... -
Page 20: Configura�On Parameter „Hvac
Manual Joy KNX 5.2. Configura�on parameter „HVAC“ PARAMETERPAGE PARAMETER DESCRIPTION Output HVAC Mode Sets the room opera�on mode ouput. Sets the room opera�ng mode after a reset until the first HVAC general HVAC mode a�er reset communica�on with the building control system... - Page 21 Manual Joy KNX Xp (user defined) Tn (user defined) Digital output direc�on"Hea�ng" Analogue output direc�on "Hea�ng" Minimum controller value „Hea�ng“ Maximum controller value „Hea�ng“ Sets the actuating variable transmission behavior. Send controller value (Change of Value / cyclic / Change of Value & cyclic)
-
Page 22: Configura�On Parameter „Sensors
Manual Joy KNX 5.3. Configura�on parameter „Sensors“ PARAMETERPAGE PARAMETER DESCRIPTION Description Is displayed in the respective channel. Maximum 12 ASCII characters. Offset Sets the specific offset (sensor correction value). Internal temperature Determines whether the measured value is to be displayed with a specific... -
Page 23: Group Objects
6. Group objects The group object structure of all Joy KNX devices is uniform. Depending on the version and configura�on, certain group objects are hidden or not available. In the following the group objects are structured according to their func�on and described accordingly. -
Page 24: Group Object Descrip�On
Manual Joy KNX 6.2. Group object descrip�on The descrip�on contains the iden�fica�on (ID), the name and the object function, the data point type, the effective direction (IN = receive / OUT = send), the validity fort he respective device type (FC 5DO, FC EC AO2DO, HC AO2DO, FC EC 3AO), a description of the function, as well as the sowie parameter-specific dependencies. -
Page 25: Group Objects „Blind
Manual Joy KNX 6.2.6. Group Objects „Blind“ NAME OBJECT FUNCTION IN / OUT DESCRIPTION DEPENDENCIES Blind 1 Up / down (long press) 1.008 Lamella / stop (short Blind 1 1.009 press) Blind 1 Up / Down (relative) 3.008 Blind 2 Up / down (long press) 1.008... -
Page 26: Group Objects „Fan Control
Manual Joy KNX 6.2.8. Group Objects „Fan control“ NAME OBJECT FUNCTION IN / OUT DESCRIPTION DEPENDENCIES Object value = Fan stage Percentage value scaled to the parameterized Fan control Fan stage [%] 5.001 number of fan stages (2 fan stages: LS0 = General >... -
Page 27: Group Objects „Sensors
Manual Joy KNX Controller Input value 1.001 output cooling Controller Input value continous 5.001 output cooling Controller Output active 1.015 output cooling Controller Heating/cooling 5.001 output cooling Controller Change over input 1.001 output cooling 6.2.10. Group Objects „Sensors“ NAME OBJECT FUNCTION... -
Page 28: Knx Specifica�On
Manual Joy KNX 7. KNX Specifica�on The Joy KNX devcies have been developed in accordance with the current KNX specification v2.1. Further information can be found at: https://my.knx.org/ Thermokon Sensortechnik GmbH Platanenweg 1 35756 Mittenaar-Offenbach Germany www.thermokon.com Thermokon Sensortechnik GmbH...
