User's Manual
Color LCD Monitor
Important
Please read this "User's Manual", and "PRECAUTIONS" (separate
volume) carefully to familiarize yourself with safe and effective
usage.
• See the Setup Guide for monitor installation and connection.
• For the latest product information including the "User's Manual", refer to
our web site:
www.eizoglobal.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexScan S2134 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eizo FlexScan S2134

Summary of Contents for Eizo FlexScan S2134

  • Page 1 User’s Manual Color LCD Monitor Important Please read this "User’s Manual", and "PRECAUTIONS" (separate volume) carefully to familiarize yourself with safe and effective usage. • See the Setup Guide for monitor installation and connection. • For the latest product information including the "User’s Manual", refer to our web site: www.eizoglobal.com...

  • Page 2: Location Of Caution Statement

    EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information.

  • Page 3: About This Product

    • The backlight of the LCD panel has a fixed lifetime. Depending on the usage pattern, such as usage for long continuous periods, the lifespan of the backlight may run out sooner, requiring replacement. When the screen becomes dark or begins to flicker, please contact your local EIZO representative.

  • Page 4: About The Installation

    About This Product • Do not press hard on the surface or outer frame of the LCD panel, as this may result in display malfunctions, such as interference patterns, etc. If pressure is continuously applied to the LCD panel surface, the liquid crystal may deteriorate or the LCD panel may be damaged.

  • Page 5: Table Of Contents

    CONTENTS CONTENTS Location of Caution Statement ................. About This Product ....................About the Usage of This Product ................ About the LCD Panel ..................About the Installation................... Cleaning ......................To Use the Monitor Comfortably ................. 1 Introduction ........................ Features ......................1.1.1 Reduction of Power Consumption ............
  • Page 6 CONTENTS Imaging Problems (Analog only) ................. 29 Other Problems ....................29 6 Reference ........................31 Attaching an Optional Monitor Arm ..............31 Connecting Multiple PCs..................33 Using the USB Hub Function ................33 Specifications ...................... 35 6.4.1 LCD Panel....................35 6.4.2 Video Signals ..................

  • Page 7: Introduction

    Introduction | 1 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1.1 Features 1.1.1 Reduction of Power Consumption This product provides a function that automatically adjusts the screen brightness to reduce power consumption . Power Reduction, CO Reduction, and Eco Performance Level can be checked on the "EcoView Settings"...

  • Page 8: Controls And Functions

    1 | Introduction 1.2 Controls and Functions 1.2.1 Front 1. Ambient light sensor Detects ambient brightness. If you use Auto EcoView, the screen brightness is automatically adjusted according to the ambient brightness (see Auto EcoView [} 13]). 2. Operation switches Displays menus (see 2.1 Switch Operation Method [} 11]).

  • Page 9: Rear

    Introduction | 1 1.2.2 Rear 1. Security lock slot Complies with Kensington’s MicroSaver security system. 2. USB-A connector Connects to a peripheral USB device (see 6.3 Using the USB Hub (downstream) Function [} 33]). 3. Protective earth terminal This terminal is used to connect the earth wire. Use an earth wire with minimum conductor size of 0.75 mm, and with a terminal of suitable material.

  • Page 10: Supported Resolutions

    1 | Introduction 1.3 Supported Resolutions The monitor supports the following resolutions: ✓: Supported, -: Not supported Resolution Vertical scan DisplayPort DVI-D D-Sub frequency (Hz) 640 x 480 59.940 ✓ ✓ ✓ 640 x 480 72.809 ✓ 640 x 480 75.000 ✓ 720 x 400 70.087 ✓...

  • Page 11: Basic Adjustment/Setting

    Basic Adjustment/Setting | 2 2 Basic Adjustment/Setting This product enables users to change the brightness according to personal preference or to suit the usage environment, and to reduce power consumption to conserve energy. This chapter describes the basic functions that can be adjusted and set by pressing the switches on the front of the monitor.

  • Page 12: Color Modes

    2 | Basic Adjustment/Setting By switching the color mode according to the purpose and contents of the display, you can display images in an appropriate manner. 2.3.1 Color Modes Color mode Purpose User 1 / User 2 Select either of these modes to set a user-defined display mode. sRGB This mode is suitable for matching color reproduction with peripheral devices that support sRGB, such as when printing photos taken using a digital...

  • Page 13: Adjusting Brightness

    Basic Adjustment/Setting | 2 Note • The power saving level (Power Reduction, CO Reduction, and Eco Performance Level) can be checked on the "EcoView Settings" menu. The more indicators that light up representing the Eco Performance Level, the higher the power saving level attained. –...
  • Page 14 2 | Basic Adjustment/Setting The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel).

  • Page 15: Advanced Adjustments/Settings

    Advanced Adjustments/Settings | 3 3 Advanced Adjustments/Settings This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see 2 Basic Adjustment/Setting [} 11]. 3.1 Basic Operation of the Setting Menu 1. Press any switch (except The operation guide appears. 2.

  • Page 16: Setting Menu Functions

    3 | Advanced Adjustments/Settings 3.2 Setting Menu Functions 3.2.1 Color The color mode settings can be adjusted according to personal preference. The adjusted settings are saved for each color mode. Functions that can be adjusted differ depending on the color mode. ✓: Adjustable, -: Not adjustable Function Color Mode User1...
  • Page 17 Advanced Adjustments/Settings | 3 Note • For details on the adjustment status of each color mode, see 2.3 Switching Display Modes (Color Modes) [} 11]. Brightness Settings: "0" – "100" The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel).

  • Page 18: Signal

    3 | Advanced Adjustments/Settings Note • If "sRGB" is selected for the color mode, "sRGB" is displayed for the gamma value. • If "Paper" is selected for the color mode, "Paper" is displayed for the gamma value. • If "DICOM" is selected for the color mode, "DICOM" is displayed for the gamma value. Advanced Settings - Overdrive Settings: "Enhanced"...
  • Page 19 Advanced Adjustments/Settings | 3 • For D-Sub input • For DisplayPort / DVI input Functions that can be adjusted differ depending on the input signal. ✓: Adjustable, -: Not adjustable Function Input Signal DisplayPort D-Sub Picture Expansion ✓ ✓ ✓ Sharpness ✓ ✓...
  • Page 20 3 | Advanced Adjustments/Settings Sharpness Settings: "-2" – "2" When a low-resolution image is displayed using picture expansion mode ("Full Screen" or "Aspect Ratio"), the text and lines of the image may appear blurry. This blurriness can be reduced by configuring the settings for sharpness. Note •...

  • Page 21: Preferences

    Advanced Adjustments/Settings | 3 Note • Flickering or bleeding may not fully disappear, depending on the PC and graphics board you are using. • If vertical stripes appear on the screen after completing the setting, adjust "Clock" again. Analog Adjustment - Hor. Position / Ver. Position The display position (horizontal, vertical) of the screen can be adjusted.

  • Page 22: Languages

    3 | Advanced Adjustments/Settings Note • At the time of shifting to power saving mode, a message that indicates the transition is displayed five seconds in advance. • When not using the monitor, you can disconnect the power plug so that the power is cut completely.
  • Page 23 Advanced Adjustments/Settings | 3 When is selected, the certification standard logo appears on the screen.

  • Page 24: Administrator Settings

    4 | Administrator Settings 4 Administrator Settings This chapter describes how to configure monitor operation using the "Administrator Settings" menu. 4.1 Basic Operation of the "Administrator Settings" Menu 1. Press to turn off the monitor. 2. While pressing the leftmost switch, press for more than 2 seconds to turn on the monitor.

  • Page 25: Functions Of The "Administrator Settings" Menu

    On-Screen Logo Settings: "On" / "Off" When the monitor is turned on, the EIZO logo and certification standard logo appears on the screen. When this function is set to "Off", the logos do not appear.
  • Page 26 4 | Administrator Settings • "Off" (default setting) Enables all switches. • "Menu" Locks the switch. • "All" Locks all switches except the power switch.

  • Page 27: Troubleshooting

    Troubleshooting | 5 5 Troubleshooting 5.1 No Picture Power indicator does not light up. • Check whether the power cord is connected properly. • Press Power indicator is lighting white. • Increase "Brightness", "Contrast", or "Gain" in the Setting menu (see Color [} 16]).

  • Page 28: Imaging Problems (Or Both Digital And Analog)

    [} 16]). (The LCD monitor backlight has a limited life span. If the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, try changing the Auto EcoView setting to "On". The monitor...

  • Page 29: Imaging Problems (Analog Only)

    Troubleshooting | 5 The positions of windows and icons are shifted when the monitor is turned off/on or when restored from power saving mode. • Turn the setting "On" for "Compatibility Mode" on the "Administrator Settings" menu (see Compatibility Mode [} 25]). Images are not displayed over the entire area of the screen. •...
  • Page 30 [} 25]). • If the peripheral devices work correctly when they are directly connected to the PC, contact your local EIZO representative. • Check the PC's BIOS (UEFI) setting for USB when using Windows. (See the manual of the PC for details.) •...

  • Page 31: Reference

    Reference | 6 6 Reference 6.1 Attaching an Optional Monitor Arm An optional arm (or optional stand) can be attached by removing the stand section. Please refer to our web site for optional arms (or optional stands) that are supported. (www.eizoglobal.com) When attaching an arm or stand, the installable orientations and movement range (tilt angle) are as follows: •...
  • Page 32 6 | Reference 3. Attach the arm or stand to the monitor. For installation, use commercially available screws that meet the following conditions: – Nominal diameter: M4 – Length: Between 7.7 mm and 10.5 mm (if using washers, add the washer thickness)

  • Page 33: Connecting Multiple Pcs

    Reference | 6 6.2 Connecting Multiple PCs This product can be connected to multiple PCs and allows you to switch between the connections for display. Connection Examples DisplayPort D-Sub DisplayPort cable DVI cable D-Sub cable (DisplayPort - DisplayPort) (DVI - DVI) (D-Sub - D-Sub) PP200 FD-C39D MD-C87...
  • Page 34 6 | Reference 1. Connect the USB cable. 2. If necessary, connect a mouse, keyboard, or other device to the USB downstream port. USB-A downstream USB-B upstream USB 2.0 cable (USB-B - USB-A) MD-C93 (Included) USB-A Attention • This function may not work depending on the PC you are using, your OS, and your peripheral devices.

  • Page 35: Specifications

    Reference | 6 6.4 Specifications 6.4.1 LCD Panel Type IPS (Anti-Glare) Backlight Size 21.3" (54.0 cm) Resolution 1600 dots x 1200 lines Display Size (H x V) 432.0 mm x 324.0 mm Pixel Pitch 0.270 mm x 0.270 mm Display Colors 8-bit colors 16.77 million colors Viewing Angle (H / V, typical) 178˚...

  • Page 36: Operating Environmental Requirements

    6 | Reference Dimensions (without stand) 465.0 mm x 361.0 mm x 64.0 mm (W x H x D) Net Weight Approx. 8.1 kg Net Weight (without stand) Approx. 5.1 kg Height Adjustment Range 82.0 mm Tilt Up 40˚, down 0˚ Swivel 70˚...

  • Page 37: Appendix

    ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries.
  • Page 38 03V60539B1 UM-S2134 Copyright © 2023 EIZO Corporation. All rights reserved. 2nd Edition – May, 2023...
