Page 5: Prepare The Hood
PREPARE THE HOOD Unpack hood and check contents. You should receive: 1 - Hood 2 - Installation Instructions Aluminum Flex Duct - Parts Bag containing: Mounting bracket Hose clamp QTY:2 QTY:1 Explode screws M4*12 QTY:4 QTY:4... - Page 7 DUCT(for horizontal discharge) The hoods feature 1(8" top round) is opening .Run ducwork between the hood location and roof cap . For the results, use a minimum unmber of transitions and elbows. STEP 1: PROTECT THE COOK TOP Put a thick, protective covering over counter top, cook top or range to protect from damage or dirt. STEP 2: CREATE WORK STATION (OPTIONAL) Have 2 pieces of wood about 2”...
- Page 8 STEP 3: PREPARE DUCTWORK & SINGLE OUTLET Make sure you have a 15amp, 120V, 60Hz, single outlet on the left or right of the duct pipe (usually is on ¼ of cabinet width). diameter duct, and roof or wall cap, depending on where you will be venting your hood) STEP 4: ATTACH 2-INCH WIDE WOOD FILLER STRIPS ...
- Page 9 STEP 6: ATTACH THE HOOD Lift the hood up and have it placed below the cabinet. Make sure to center the hood beneath the cabinet and flush with the front of the cabinet. TIP (optional): since the hood is heavy, a cabinet or a car jack is highly recommended. STEP 7A: SECURE THE HOOD TO BOTTOM CABINET STEP 7A: SECURE THE HOOD TO BOTTOM CABINET From inside of the hood, use “hex bit extension”...
-
Page 10: Step 10: Install Baffle Filters
STEP 9: INSTALL OIL TUNNEL OR OIL CONTAINER (NOT AVAILABLE FOR ALL MODELS) Oil Tunnel Side View Drop oil tunnel into recess support near rear of hood. Refer to the left picture Step 10: Install baffle filters Baffle Installation Side View ... - Page 11 1.Push stop button, and the motor will stop. 2.Push the Low button, the buzzer will buzz once and the motor will run at low speed. 3.Push the Mid button, the buzzer will buzz once and the motor will run at mid speed. 4.Push the High button, the buzzer will buzz once and the motor will run at high speed.
- Page 13 EMPAVA APPLIANCES INC. 15253 DON JULIAN RD CITY OF INDUSTRY,CA 91745 TEL:888-682-8882 WWW.EMPAVA.COM...
