- Page 1 ENGLISH ADH10 ATRIUM Schlage Integration Module The installer’s choice cdvigroup.com...
-
Page 2: Table Of Contents
7] WARRANTy - TERMS & CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Copyright (C) 2011 CDVI. All rights reserved. ATRIUM Access Control is protected by copyright law and international treaties. -
Page 3: Product Presentation
Schlage Integration Module (Control up to 10 Schlage Door Handles) 1] PRODUCT PRESENTATION One ATRIUM ADH10 controller has the capacity to control ten NDE, AD300 and/or AD400 SCHLAGE door handles. ATRIUM ver. 3.1 (or higher) multi-account software supports up to 500 door handles per account (site). This is accomplished by using fifty ADH10 controllers connected to an IP network. -
Page 4: Notes And Recommendations
UL 294 COmPLIANCE NOTICE • Use only UL 294 listed power supply • Connect CDVI LED status indicator, part number 7020-0001-0000, to the DC Input gray terminals of the ADH10. Note: Backup battery provides operation of up to 12 hours but has been tested for 4 hours per Section 33 of UL 294, fifth edition. -
Page 5: Recommended Wiring
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) RECOMMENDED WIRINg maximum Equipment Wire Type Size Length Power Supply 3 conductors, solid copper 18AWG (1.02mm) 14AWG (1.63mm)* 8m (25ft.) Ethernet CAT 5/5e 100m (300ft) CAT 5/5e or 4 pairs 24AWG (0.51mm) - Page 6 Battery Backup 12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12 Battery Capacity recommended, Europe: CDVI B7AH recommended). Ensure proper polarity. 250mA (default), 320mA, 500mA, or 1A. Refer to the ATRIUM user interface instruction manual Charging Current for more information on how to modify the battery charging current.
-
Page 7: Package Contents
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) 3] PACKAGE CONTENTS This chapter details how to install and setup the ATRIUM ADH10 . The ADH10 contains: • One ADH10 module in its cabinet with connection diagram label • AC power cord • Metal Box kit (See below) • Installation kit (See below) -
Page 8: Location And Mounting
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) LOCATION AND MOUNTING The cabinet is designed to be installed indoors, in a safe and secure location. Suggested locations include electrical rooms, communication equipment rooms, closets or in the ceiling. To save time, wiring and facilitate testing, install the cabinets at an equal distance between its controlled doors. Normal temperature and humidity levels should be maintained. Please note that other approved cabinets with approved tamper switch on the front cover and rear surface can be used. Cabinet Dimensions: 29 cm (11.4”) high, 28 cm (11”) wide, 8 cm (3.15”) deep The Cabinet Can Accommodate: One 12Vdc @ 4.5AH or 7AH, gel cell type batteries and wiring connections (15cm (6”) high, 6cm (2.5”) wide, 9 cm (3.54”) deep) Battery Model Voltage Capacity Length Width Height YUASA #NP7-12 12 Volt 7 Ah 151mm (5.94”) 65mm (2.56”) -
Page 9: Mounting Instructions
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) 4] MOUNTING INSTRUCTIONS The box needs to be prepared before fixing it to its location. INSTALLING THE TAMPER SWITCHES Installing tamper switches allows the ADH10 to detect when the cabinet door is opened and/or when the cabinet is removed from the wall. If needed install the tamper switch(es) as follows: Metal box holes where to fix the wall tamper switch cdvigroup.com... - Page 10 INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) Install the wall tamper switch using the supplied bolts and nuts as shown in the following picture. Install the tamper switch plastic spacer on the back at bottom left side of Cabinet Side View the box as show in the following picture. Spacer Cabinet Door Spacer Screw Spacer cdvigroup.com...
- Page 11 INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) Install the door tamper switch by aligning the switch holes to the pre-installed plastic bracket pins. Press firmly to secure the tamper switch in position, then fix the bracket to is mounting flange. Refer to page 14 for wiring diagram. Fix the tamper switch to the bracket then mount the bracket on the mounting flange Bracket Door Tamper Switch Door Tamper Switch Mounting Flange...
-
Page 12: Installing The Box Lock
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) INSTALLING THE BOx LOCK Installing the box lock allows to secure the box from unauthorized access. Installation procedure: Remove the box door knock-out. Insert the lock in the hole. Slide the “U” metal part into the lock groove to secure the lock in place. Alternatively or complementary to the box lock, the box may be secured by fixing the cover to its base using screws. However this should be done only once the installation is completed. Use the 4 screws supplied to secure the box cover to its base as shown in the following picture. cdvigroup.com... -
Page 13: Fixing The Box To Its Location
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) FIxING THE BOx TO ITS LOCATION Install the box to its location using 4 screws (not supplied) as shown in the following picture. If the wall tamper switch is used, make sure that the tamper switch arm moves freely and is completely pushed in when the enclosure is installed on the wall. cdvigroup.com... -
Page 14: Installing The Adh10 Pc Board
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) INSTALLING THE ADH10 PC BOARD Install the 5 fasteners (PCB holder) supplied respectively to the box holes identified in red in the following picture. Install the ADH10 PCB by aligning the fasteners with the corresponding PCB holes and pressing firmly to secure the PCB in place. cdvigroup.com... -
Page 15: Wiring Diagram
RDA- TDA- Once the connection is properly done as shown above, the ATRIUM ADH10 will automatically detect the Allegion GWE gateway, AD-300 or PIM400-485 on power on. The ADH10 can provide power to up to three GWE Gateways and/or PIM400-485. -
Page 16: Box Tamper Switches
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) BOx TAMPER SWITCHES Connecting the tamper switches allows the ADH10 to detect when the cabinet door is opened and/or when the cabinet is removed from the wall. To install the tamper switches, see “Installing the Tamper Switches”. -
Page 17: Power Supply
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) POWER SUPPLy Do not power up the ADH10 until all connections are completed. The module operates from any 120/240 Vac sources using the supplied AC/DC power supply and provides fully monitored power solutions using: •... - Page 18 INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) The Minimum Size Equipment Conductors for the AC mains required are 14 AWG if made of Copper or 12 AWG if made of Aluminium or Copper-Clad Aluminium. Do not use any switch-controlled outlets to power the system.
-
Page 19: Battery Backup
12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12 recommended, Europe: CDVI B7AH recommended). Ensure proper polarity. Various (means any type, from any manufacturer that complies with the “Technical Data and securement means” and meets the “Mark of conformity”... -
Page 20: Led Indicators
The ATRIUM ADH10 has several status LEDs that are very useful to diagnose problems when using or installing the ATRIUM system. Refer to the following picture to locate the LEDs on the ATRIUM ADH10. All LEDs are explained in the following pages. -
Page 21: Ethernet Network Connection & Rs485 Bus
The ATRIUM ADH10 provides a 10/100Mbps Ethernet port to allow direct connection from a local PC or interconnect to an existing LAN/WAN. Connect the Ethernet 10/100 Mbps port of the ATRIUM ADH10 to a LAN or WAN network using an UTP cable (maximum 100m (300ft)). Connect expansion modules on a 3 conductor RS485 communication loop in daisy chain configuration up to 1220m (4000 ft) from the ATRIUM controller. -
Page 22: System Overview
Schlage Integration Module (Control up to 10 Schlage Door Handles) SySTEM OvERvIEW One ATRIUM ADH10 controller has the capacity to control ten AD300 and/or AD400 SCHLAGE door handles. ATRIUM ver. 3.1 (or higher) multi-account software supports up to 500 door handles per account (site). For increased flexibility, the system also supports proximity or magnetic stripe card readers. -
Page 23: Programming
INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) 6] PROGRAMMING Refer to the ADH10 Schlage Integration Quick Guide, available on our Web site, to configure GWE and Schlage locks. Typical ADH10 & GWE wiring diagram... - Page 24 INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) Typical ADH10 & GWE wiring diagram (2 GWE managing 5 NDE wireless locks each) ADH10 Door Handle Controller RS485 : Up to 4000 ft. (1220 m)
- Page 25 INSTALLATION MANUAL ATRIUM ADH10 Schlage Integration Module (Control up to 10 Schlage Door Handles) Typical ADH10 & GWE wiring diagram (10 GWE managing 1 NDE wireless locks each) GWE #1 ADH10 Address & Door Range GWE #1 Door Handle Controller...
-
Page 26: Warranty - Terms & Conditions
The transport fees shall be paid by the customer and the package must be returned to CDVI or to a CDVI authorized repair centre. - Page 27 • Any product which has undergone even the slightest modification or change; • Any product which has been installed and/or used with any auxiliary device not supplied by CDVI; • Any product which has been used for demonstrations or display;...
- Page 28 Reference : Extranet : EXE-CDVI_IM ADH10 CMYK A4 EN 03 *G0301EN0413V01* CDVI Group FRANCE (Headquarter/Siège social) Phone: +33 (0)1 48 91 01 02 Fax: +33 (0)1 48 91 21 21 CDVI CDVI FRANCE + EXPORT IBÉRICA Phone: +33 (0)1 48 91 01 02...
