BO600RP/BO600RH
Vertical & Horizontal retrofi t housing
Bandeau architectural vertical & horizontal
P300RP/P600RP
Retrofi t handle
Poignées ventouse
BO600RH
P300RP
The installer's choice
cdvigroup.com
ENGLISH
ENGLISH
EN
FRANCAIS
FRANCAIS
FR
BO600RP

Advertisement

loading
Need help?

Need help?

Do you have a question about the BO600RP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CDVI BO600RP

  • Page 1 ENGLISH ENGLISH FRANCAIS FRANCAIS BO600RH P300RP BO600RP/BO600RH BO600RP Vertical & Horizontal retrofi t housing Bandeau architectural vertical & horizontal P300RP/P600RP Retrofi t handle Poignées ventouse The installer’s choice cdvigroup.com...
  • Page 2: Products Overview

    Dimensions (L x W x D): - BO600RH = 925 x 105 x 62mm, ALMA - BO600RPSTD = 2190 x 105 x 63mm, - BO600RP = 2500 x 105 x 63mm. Magnet housing for frame mount. MOUNTING Recommended Armature housing with end caps Power supplies for door mount.
  • Page 3 INSTALLATION MANUAL BO600RP - BO600RH Vertical & Horizontal retrofi t housing Product Details BO600RP BO600RP BO600RPSTD 2500MM 2190MM 925 MM Number of 300Kg magnets Lock section with cover Architectural handle with fi xing cover End caps for handle End caps for lock section...
  • Page 4 INSTALLATION MANUAL BO600RP - BO600RH Vertical & Horizontal retrofi t housing 4] ASSEMBLY BO600RH Position the box-section backplate, complete with With the door closed, position the architectural pre-fi tted electro-magnetic locks, on to the door handle onto the edge of the opening leaf of the door, frame - ensure the positioning will allow for the ensuring the handle covers the box-section.
  • Page 5 INSTALLATION MANUAL BO600RP - BO600RH Vertical & Horizontal retrofi t housing BO600RP Position the box-section backplate, With the door closed, position the Cut the top cover unit into 2 complete with pre-fi tted electro- architectural handle onto the edge pieces. Double check the length of...
  • Page 6 INSTALLATION MANUAL BO600RP - BO600RH Vertical & Horizontal retrofi t housing 5] WIRING 12Vdc 24Vdc Example N°1: Exit button only (VHLD timer optional) 5-WAY TERMINAL STRIP NON MONITORED VERSION + 12Vdc or 24Vdc positive * - 12Vdc or 24Vdc negative * * Voltage: 12Vdc or 24Vdc.
  • Page 7 INSTALLATION MANUAL BO600RP - BO600RH Vertical & Horizontal retrofi t housing 6] NOTES cdvigroup.com...
  • Page 8: Présentation Du Produit

    43,4 43,4 - BO600RH = 925 x 105 x 62 mm - BO600RPSTD = 2190 x 105 x 63 mm, - BO600RP = 2500 x 105 x 63 mm. OUVRANT Poteau technique sur le dormant prévu DORMANT pour l’installation des ventouses.
  • Page 9: Éléments Fournis

    MANUEL D’INSTALLATION BO600RP - BO600RH Bandeau architectural Détail produits BO600RH 925 MM BO600RP 2500 MM BO600RPSTD 2190 MM Ventouse(s) 300 Kg avec Contreplaque(s) Support mural avec Capot Poignée bandeau avec Cache vis Bouchons Poignée bandeau Bouchons Support mural Possibilité de teinte...
  • Page 10 MANUEL D’INSTALLATION BO600RP - BO600RH Bandeau architectural 4] MONTAGE BO600RH NON CONFORME NFS 61-937. Positionnez le support mural avec ses ventouses Positionnez la poignée bandeau munie de ses sur le fi xe ou semi fi xe. Prenez les marques dans contreplaques sur l’ouvrant.
  • Page 11 MANUEL D’INSTALLATION BO600RP - BO600RH Bandeau architectural 5] MONTAGE BO600RP CONFORME NFS 61-937. Positionnez le support mural avec Positionnez la poignée bandeau Coupez le cache vis en deux ses ventouses sur le fi xe ou semi munie de ses contreplaques sur...
  • Page 12: Schémas De Raccordement

    MANUEL D’INSTALLATION BO600RP - BO600RH Bandeau architectural 6] SCHÉMAS DE RACCORDEMENT (USAGE GÉNÉRAL HORS CONFORMITÉ NFS 61-937) 12 V DC 24 V DC Montage N°1 : Bouton poussoir intérieur (+ Carte TPV en option) + Alimentation 12 V ou 24 V DC * - Alimentation 12 V ou 24V DC * * Alimentation : 12 V DC ou 24 V DC.
  • Page 13 MANUEL D’INSTALLATION BO600RP - BO600RH Bandeau architectural 7] SCHÉMAS DE RACCORDEMENT (CONFORMES NFS 61-937 - PV n°15/12966) MONTAGE VERTICAL Montage N°1 : Alimentation 24 V DC VENTOUSE N°1 Alimentation 24 V DC VENTOUSE N°2 ARD212 Alimentation : 24 V DC.
  • Page 14 Reference : G0301FR0387V06 Extranet : EXE-CDVI_IM BO600RP-BO600RH-P300RP-P600RP CMYK A5 EN-FR 04 *G0301FR0387V06* CDVI Group FRANCE (Headquarter/Siège social) Phone: +33 (0)1 48 91 01 02 Fax: +33 (0)1 48 91 21 21 CDVI CDVI FRANCE + EXPORT IBÉRICA Phone: +33 (0)1 48 91 01 02...
