Roger Technology BH30 Series Instructions And Recommendations For The Installer
Hide thumbs
Also See for BH30 Series:
- Instruction manual (73 pages) ,
- Instructions and recommendations for the installer (65 pages) ,
- User manual (12 pages)
Advertisement
IS118 Rev.09 07/06/2021
Serie BH30
Automazione per cancelli scorrevoli
Sliding gates automations
Automatisierung für Schiebetore
Automatisme pour portails coulissants
Automatismos para cancelas correderas
Automações para portões deslizantes
Istruzioni originali
ISTRUZIONI E AVVERTENZE PER L'INSTALLATORE
INSTRUCTIONS AND RECOMMENDATIONS FOR THE INSTALLER
ANWEISUNGEN UND HINWEISE FÜR DEN INSTALLATEUR
INSTRUCTIONS ET AVERTISSEMENTS POUR L'INSTALLATEUR
INSTRUCCIONES Y ADVERTENCIAS PARA EL INSTALADOR
INSTRUÇÕES E AVISOS PARA O INSTALADOR
Advertisement
Table of Contents
Related Manuals for Roger Technology BH30 Series
Summary of Contents for Roger Technology BH30 Series
- Page 1 IS118 Rev.09 07/06/2021 Serie BH30 Automazione per cancelli scorrevoli Sliding gates automations Automatisierung für Schiebetore Automatisme pour portails coulissants Automatismos para cancelas correderas Automações para portões deslizantes Istruzioni originali ISTRUZIONI E AVVERTENZE PER L’INSTALLATORE INSTRUCTIONS AND RECOMMENDATIONS FOR THE INSTALLER ANWEISUNGEN UND HINWEISE FÜR DEN INSTALLATEUR INSTRUCTIONS ET AVERTISSEMENTS POUR L’INSTALLATEUR INSTRUCCIONES Y ADVERTENCIAS PARA EL INSTALADOR...
-
Page 2: Useful Information
Dangerous voltage risk. Hot surfaces risk. Useful information. Refer to the Installation and use instructions. Product description ROGER TECHNOLOGY cannot be held responsible for any damage or injury due to improper use or any use other than Motor Code Description type... -
Page 3: Technical Data
CONTROL UNIT FORCE TO BE APPLIED ON THE MECHANICAL RELEASE Product label (example) Labels must not be removed, damaged, dirty or concealed. ROGER TECHNOLOGY S.R.L. Via S. Botticelli 8 - 31021 Bonisiolo di Mogliano MADE IN ITALY Veneto (TV) - ITALIA BH30/603/HS P.CODE:... -
Page 4: Typical Installation
Typical installation DESCRIPTION RECOMMENDED CABLE double insulated cable Cable Cable Cable Cable a LED Flashing light Cable Cable Cable board DECODER Cable Dimensions 329mm 83mm 165,8 mm 315 mm... - Page 5 Preliminary checks and installation of the foundation plate PRELIMINARY CHECKS BEFORE INSTALLATION • • • • • • INSTALLING FOUNDATION PLATE • • • • • • Fig. 1 Fig. 2 Installation drive unit • • • • • • •...
- Page 6 Fixing The Rack N.B.: • User Guide • • • • • • • R = RIGHT; L = LEFT • ATTENTION ATTENTION • ~40÷80 • MICROSWITCH MECHANICAL LIMIT SWITCH Fig. 1 MAGNETIC LIMIT SWITCH N.B.: the magnet can be adjusted to a maximum of 8 mm in relation to the rack mounting bracket.
-
Page 7: Electrical Connections
Electrical connections to the electrical panel must be on an independent path and separate from the connections to the command and The electrical connections and the gear motor BH30 testing operations are described in the installation manual of the control unit B70/1DC 3x2,5 mm²... - Page 8 24V~/ ROSSO / RED MARRONE / BROWN BLU / BLUE NERO / BLACK 24V~/ FCA (OPEN COLLECTOR) FCC (OPEN COLLECTOR) Start-up • • the manufacturer’s declaration of conformity for all connected devices, the instructions manual of each device and • •...
- Page 9 Additional information and contact details ROGER TECHNOLOGY CUSTOMER SERVICE: 23 23...
- Page 10 DECLARATION OF INCORPORATION (Directive 2006/42/CE - Annex II B) Roger Technology - Via Botticelli 8, 31021 Bonisiolo di Mogliano V.to (TV) Description of the device: Built-in control unit model: Product code See the P.CODE Serial Number • • • •...
