Starting the server
About this task:
When you start the exacqVision server for the first time, you must create an operating system user name and password, then create an exacqVi-
sion user name and password.
1. Turn on the exacqVision server.
2. When the Log on dialog box appears, create a user name and password for the operating system.
3. Configure the operating system settings as required.
4. If prompted, log on to the operating system again with the operating system user name and password that you just created.
5. When you log on, an exacqVision dialog box appears on the desktop. Create the exacqVision user name and password.
Note: The credentials in step 5 are not the same as the credentials you created to log on to the operating system. Use these
credentials to log on to the Exacq Server.
Configuring the server
1. Open the Exacq client.
2. From the navigation tree, click Configure System > Network.
In the Network tab, choose one of the following options:
3.
- To install the server on a network that uses static IP addressing, click Static and enter the IP address.
- To install the server on a network using dynamic host configuration protocol (DHCP), click Dynamic. If the information does not
configure automatically, contact your network administrator.
4. Click Apply.
5. Repeat this procedure for any additional network ports. For more information about configuring the server, see
support/manspecs/.
Setting up remote access to the server
About this task:
You can configure the server through a remote exacqVision client.
1. Download the latest exacqVision Client software from the Exacq website at: https://www.exacq.com/support/downloads.php.
2. Install the client software on a system administrator computer.
3. Use the ping command and the server's IP address to confirm connectivity. If the client PC cannot communicate with the server, contact
your network administrator.
Remote access for administrative support
For administrative support to access to the server remotely, configure remote desktop for Windows, or SSH for Linux depending on the
computer operating system. For more information, refer to the following Exacq Knowledge Base articles:
• Using remote desktop to manage Windows-based exacqVision servers:
Enabling/Disabling SSH on exacqVision Linux Server:
•
Configuring the client
1. Start the Exacq client application.
2. When the local client is launched for the first time, enter the Exacq user name and password you created during initial startup.
Verify that the server appears in the Systems list and displays a Connected status.
3.
Note: If the server does not connect to the client, check the remote client machine for antivirus software that can block
communication between the server IP addresses and ports.
Connecting the cameras
About this task:
To determine the compatibility of a particular camera model and firmware combination with exacqVision servers, use the following link:
www.exacq.com/support/ipcams.php
1. Use the camera manufacturer's software to configure the IP addresses for each camera, and record this information for future reference.
