G-Series Micro NVR Quick Start Guide
Introduction
The exacqVision G-Series Micro is part of the Built By Exacq (BBE) line of network video recorders (NVR). The server is pre-installed with
exacqVision video management software and can connect to 8 IP cameras.
Installation and safety requirements
Before you turn on the exacqVision G-Series Micro, ensure that you meet the following requirements.
• Mount the G-Series Micro in a dust-free and climate-controlled location where the temperature is between 40°F and 95°F (4.5°C to 35°C), and
the humidity level is less than 80% non-condensing.
• Do not use this product near water or a heated source, such as a radiator.
• Set up the system on a stable surface.
• Openings on the chassis are for ventilation. Do not block or cover these openings. Ensure that you leave sufficient space around the system
for ventilation. Never insert objects into the ventilation openings.
• If you use an extension cord, make sure that the total ampere rating of the devices plugged into the extension cord does not exceed its
ampere rating.
• Do not mount the product at a height of more than two meters.
• When you have affixed the VESA display mounts, you must secure the display to prevent instability.
• Do not walk on the power cord or allow anything to rest on it.
• Do not allow liquids to enter the G-Series Micro.
• When the system is turned OFF, a small amount of electrical current still flows. Always unplug all power, modem, and network cables from
the power outlets before cleaning the system.
• If you encounter the following technical problems with the product, unplug the power cord and contact a qualified service technician or your
retailer:
- The power cord or plug is damaged.
- Liquids enter into the system.
- The system does not function correctly.
- The system is dropped or the cabinet is damaged.
- The system performance changes.
Network connection requirements
• If the video surveillance system does not have a physically isolated network, connect all IP cameras and one server network interface
card (NIC) to a dedicated camera VLAN or dedicated physical camera network. For information on suggested configurations, see
support.exacq.com/#/knowledge-base/article/868
• Install the camera manufacturer's software on a PC in this subnet or configure the router to connect a client computer in the camera
subnet. For information on how to configure the network, see
Note: A configuration that isolates the camera traffic reduces the chances of conflicts with other network traffic and unauthorized access
to cameras.
500-00122 Rev A
2024-07-09
Configuring the server.
