- Page 1 Corin TV Stand w/ Fireplace FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41007-HT The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 120 mins Weight limitations are as follows: Maximum Load Maximum Load 70 lb 30 lb Maximum Load 20 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS (A) CODE DESCRIPTION Top Panel Middle Shelf Panel Bottom Panel Short Crossbar Support Leg Top Shelf Divider Top Crossbar Middle Crossbar Top Back Panel Cabinet Door v.06 2022...
- Page 6 PACKAGE CONTENTS (B) CODE DESCRIPTION Left Panel Right Panel Left Medial Panel Right Medial Panel Storage Shelf Panel Side Back Panel Left Front Leg Left Back Leg Right Front Leg Right Back Leg...
- Page 7 PACKAGE CONTENTS Install all hardware perpendicular to the opening. v.06 2022...
- Page 8 Required tools for assembly (Not included) Attach cam bolts on the middle crossbar and the legs.
- Page 9 Attach the middle crossbar to the middle shelf panel. Attach cam bolts to the middle shelf panel. v.06 2022...
- Page 11 Attach the medial panels to the middle shelf panel. Secure the short crossbar to the middle shelf panel. v.06222022...
- Page 12 Attach the bottom panel to assembly. Attach support legs to the bottom panel and slide in the side back panels. Warning label should be facing outward.
- Page 13 Attach cam bolts to the side panels. Attach legs to the side panels. v.062 2022...
- Page 14 panels.
- Page 15 Rotate the unit and have it stands on its legs, then attach top shelf divider on the middle shelf panel. v.06222022...
- Page 16 Slide in the top back panel. Attach cam bolts to the top panel.
- Page 17 Assemble the top panel on top of the TV stand. v.06222022...
- Page 18 Secure the top crossbar to the top panel. Secure the back panels to the TV stand.
- Page 19 v.06222022...
- Page 20 Attach door hinges to the cabinet doors. Attach door handles to the cabinet doors.
- Page 21 Attach the cabinet doors to the TV stand. Concealed hinges are three-way adjustable. Up and down In and out Side to side adjustment by adjustment by adjustment using loosening the screws loosening the screws the front adjustment on the mounting on the hinge arm.
- Page 22 Insert shelf pegs inside the TV stand and put in the storage shelf.
- Page 23 device to prevent the furniture from tipping over. Mark the drill position on the wall with a pencil. Drill a small hole on the marked position. Insert a wall anchor into the drilled hole. Fixed the anti-tipping strap to the wall with provided screws. v.06222022...
- Page 24 Attach the wood strip on top of the TV stand. 0.2” / 5mm 2” / 50mm YOU’RE FINISHED!
-
Page 25: Fireplace Installation
FIREPLACE INSTALLATION Set the unit from the back of the replace mantel and center it in the opening. Check the alignment and attach the unit to the mantel by inserting screws through the drilled holes on the mantel. For the exact instruction, please refer to the user’s manual provided with the replace. - Page 26 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 27 WARNING instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
- Page 28 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
- Page 29 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.06222022...
-
Page 30: Warranty
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
