ASKOMA ASKOHEAT-F+ 2.0 Installation Instructions And User Manual

ASKOHEAT
-F+ 2.0
Installation instructions, user manual and service
Please keep in a safe place
Flange heater Ø 240 mm & Ø 280 mm for drinking and heating water
AHF240-TI-plus-... / AHF280-TI-plus-...
•
...-TI-plus-9.5
•
...-TI-plus-11.9
•
...-TI-plus-15.8
•
...-TI-plus-10.0
•
...-TI-plus-15.0
•
...-TI-plus-20.0
Index
General safety and installation advice
Installation guidelines
Device description
Installation instructions for control unit ASKOHEAT
Installation instructions for flange heater
Connector and pin assignment
Start-up
Functional description
Electrical diagram 9.5 / 11.9 / 15.8 kW
Electrical diagram 10.0 / 15.0 / 20. kW
Service / Malfunction
MV-012-6841.2
Flange heater
Ø 240 mm & Ø 280 mm
-RC+
01.04.2024 www.askoma.com
Page 2
Page 3
Page 4 - 6
Page 7
Page 8 / 9
Page 10 - 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 1
