Summary of Contents for Avantree Avantalk Sky Eon
- Page 1 Sky Eon USER MANUAL Powered by Avantree Model No.: ATHT-2100...
-
Page 2: Table Of Contents
SKY EON User Manual Table of Contents Box Contents Product Introduction (Transmitter) Product Overview Button Functions LED Indicators Product Introduction (Headphones) Product Overview Button Functions LED Indicators Using the Headphones with Your Device Pairing & Connecting Con guring Audio Settings (only for PC) Use as Wired Headphones Use Sky Eon on an Airplane Connecting the Transmitter to an Audio Source... -
Page 3: Box Contents
SKY EON User Manual Box Contents Relay Transmitter Eon Headphones Dual 3.5mm Adapter Carrying Case AUX 3.5mm Audio Cable Type C Power Cable To view and purchase Sky Eon accessories, please visit avantalk.com/sky-eon/accessories... -
Page 4: Product Introduction (Transmitter)
SKY EON User Manual Product Introduction (Transmitter) Product Overview ON/OFF Volume adjustment Multifunctional button (MFB) Connection indicator Battery status indicator... -
Page 5: Button Functions
SKY EON User Manual Button Functions Button Functions Switch to turn the Relay on / o Press once or hold to adjust volume Press & hold both for 6 seconds to clear pairing history (will not clear the locked Eon headphones) Press &... -
Page 6: Product Introduction (Headphones)
SKY EON User Manual Product Introduction (Headphones) Product Overview ANC / Transparency / Normal mode button ON/OFF / Wired / PAIR Listening mode indicator Busy light EQ mode button Status indicator AUX 3.5mm jack... -
Page 7: Button Functions
SKY EON User Manual Button Functions Button Functions Switch to the “ON / OFF” position to turn the headphones on / o Switch to the “WIRED” position to use as wired headphones OFF/ Hold Wired to Pair Switch to the “HOLD TO PAIR” position & hold for 2 seconds to enter pairing mode Manually initiate reconnection to last-paired device - Slide the switch to “Hold to Pair“... -
Page 8: Led Indicators
SKY EON User Manual LED Indicators Indicator & Voice Prompt Status Solid red Charging Flashing red Low battery Flashing blue, “BATTERY HIGH / Power on MEDIUM / LOW” voice indicator Solid red for 1 second then o , Power o “GOODBYE”... -
Page 9: Using The Headphones With Your Device
“HOLD TO PAIR” and holding for 2 Wired to Pair seconds until the LED ashes red & blue. OFF/ Hold Hold for 2s Wired to Pair STEP 3 Turn on your device's Bluetooth and select "Avantree Eon" in the Bluetooth menu. - Page 10 If not, you can manually OFF/ Hold activate reconnection by sliding the switch to “HOLD TO PAIR” once, or Wired to Pair by selecting "Avantree Eon" in your device's Bluetooth menu.
-
Page 11: Con Guring Audio Settings (Only For Pc)
You may need to con gure your audio settings when using the Eon with your PC or laptop. STEP 1 Access your device’s audio settings and set “Avantree Eon” as the default in SOUND OUTPUT / PLAYBACK. Set “Avantree Eon” as the default in INPUT / MICROPHONE DEVICE. - Page 12 Avantree Eon (Hands Free) VOICE SETTINGS INPUT DEVICE OUTPUT DEVICE Avantree Eon (Hands Free) Avantree Eon (Hands Free) Settings INPUT VOLUME OUTPUT VOLUME NOTE: On Windows 11 / macOS, there is no “Hands Free” option; select “Avantree Eon”as the default instead.”...
-
Page 13: Use As Wired Headphones
SKY EON User Manual Use as Wired Headphones STEP 1 OFF/ Hold Slide the switch to “OFF / Wired. ” Wired to Pair STEP 2 Simply plug the AUX 3.5mm audio cable into both the headphones and your audio output device. NOTE: When in wired mode, listening modes (ANC, transparency, normal) and all other built-in buttons do not function. -
Page 14: Use Sky Eon On An Airplane
SKY EON User Manual Use Sky Eon on an Airplane Connecting the Transmitter to an Audio Source Plug the transmitter into an in- ight entertainment system (use the adapter if necessary) or any other audio source that has an AUX 3.5mm audio connector. Connecting the Headphones to Transmitter STEP 1 Switch the... -
Page 15: Connecting A 2Nd Pair Of Headphones To Transmitter
SKY EON User Manual NOTE: If you paired your Headphones with a di erent Bluetooth device, turn Bluetooth OFF on said device(s). The headphones may be connecting to that device instead of the Relay transmitter. Connecting a 2 Pair of Headphones to Transmitter STEP 1 Once the Eon headphones are successfully connected, put your Transmitter into PAIRING mode by pressing &... -
Page 16: Charging
SKY EON User Manual Charging Charging the Transmitter Double click the MFB of the Transmitter to check the battery level. It’s best to initiate charging when the Relay is at 25% battery level or below. 25% 50% 75% 100% Charging the Headphones If you hear a “BATTERY LOW”... -
Page 17: Speci Cations
SKY EON User Manual Speci cations Transmitter Bluetooth version v5.3 Operating range Up to 33ft / 10m Bluetooth pro les AVRCP, A2DP aptX Low Latency; aptX adaptive; Supported audio codecs aptX HD, aptX, SBC Rated input DC5.0V / 500Ma-2A Product dimensions 125mmx24mmx12mm Net weight... - Page 18 SKY EON User Manual Headphones Bluetooth version v5.0 Supported audio codecs AAC, SBC HSP v1.2, HFP v1.7, AVRCP v1.6 Bluetooth pro les and A2DP v1.3.1 Operating range Up to 50ft / 15m Drivers 40mm Impedance Frequency response 20Hz - 20KHz Charging time ~2.5hrs Total harmonic distortion (THD)
-
Page 19: Faq
SKY EON User Manual Below are some of the most common questions people have during setup. Can I use the transmitter with the GYM machine? Yes, it can be used on any audio devices with AUX 3.5mm output, even with a treadmill or TV. -
Page 20: Contact Us
SKY EON User Manual Contact Us Support Tickets avantalk.com/submit-a-ticket Support Email support@avantalk.com USA / CA +1800 232 2078 (9am-6pm PST, Mon-Fri ) +44 20 8068 2023 (9am-6pm, GMT, Mon-Sat) +49 32221097297 (11am-9pm, CET, Mon-Sat ) + 33 176340312 (11am-9pm, CET, Mon-Sat ) +39 06 9480 3330 (9am-6pm, CET, Mon-Sat ) + 34 931786261 (9am-6pm, CET, Mon-Sat ) + 61 2 8310 9897 (11am-7pm, AEST, Mon-Fri) - Page 21 Manufacturer: Avantronics Limited Address: Luohu District, Shenzhen 518000 China US Importer: Avantree Corporation San Jose, California 95119 USA UK Importer: Avantree Limited Watford, WD180 0HQ UK Servicer in Europe: Model No:ATHT-2100 Dispose of the packaging and this product in accordance with the latest provisions.
