Avantree HT5009 User Manual

Wireless headphones and transmitter set
Hide thumbs Also See for HT5009:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

User Manual
Wireless Headphones
and Transmitter Set
HT5009
What's in the box? ·······················································································································································································1
Products overview ······················································································································································································1
LED indication & voice prompts ·····························································································································································2
Turn on HT5009 ····························································································································································································2
Use HT5009 with your TV ·········································································································································································3
Check your TVs output options before the set up ···················································································································3
TVs with OPTICAL audio out ····························································································································································4
TVs with AUX/3.5mm audio out ·····················································································································································4
Use HT5009 with your AV Receiver with 6.35mm PHONE jack ···································································································6
Use the headphones independently with cellphone ····················································································································6
pair of Bluetooth headphones ············································································································································7
Charging headphones ···············································································································································································7
Clear pairing history ···················································································································································································8
Troubleshooting ··························································································································································································8

Advertisement

Table of Contents
loading

Related Manuals for Avantree HT5009

Summary of Contents for Avantree HT5009

  • Page 1: Table Of Contents

    TVs with OPTICAL audio out ····························································································································································4 TVs with AUX/3.5mm audio out ·····················································································································································4 TVs with RCA Audio Out (Red/White ports labeled "AUDIO OUT")····················································································5 Use HT5009 with your AV Receiver with 6.35mm PHONE jack ···································································································6 Use the headphones independently with cellphone ····················································································································6 Add a 2 pair of Bluetooth headphones ············································································································································7...

  • Page 2: What's In The Box

    What’s in the box? 1. AS9S BT Headphones 2. Oasis Plus BT Transmitter 3. Optical Audio Cable 4. 3.5mm Audio Cable 5. 3.5mm to RCA Audio Cable 6. Micro USB Power Cable*2 Products overview...

  • Page 3: Led Indication & Voice Prompts

    Low battery LED flashes Low battery Turn on HT5009 1) Powering up the transmitter Power up the transmitter with the USB cable provided. Connect it to a TV USB port (TV needs to be turned on) or any other USB charger that supports 5V/500mA-2A.

  • Page 4: Use Ht5009 With Your

    2 seconds until you see the BLUE LED light. They will auto-reconnect, indicators are: 1) Headphones says” Welcome to Avantree. Connected”. 2) Transmitter says “Connected. Ready for use. ” The “TX” LED will stop flashing and “A” LED will light up. APTX...

  • Page 5: Tvs With Optical Audio Out

    TVs with OPTICAL audio out Now you should be able to use the headphone. IF there’s no sound: a. Ensure the transmitter LED “OPT” is on. If not, short press once. b. Ensure your TV speaker is set to “External Speaker”. c.

  • Page 6: Tvs With Rca Audio Out (Red/White Ports Labeled "Audio Out")

    Set up Oasis Plus using AUX/3.5mm audio out Set TV speaker to “Headset" a. Make sure the “AUX” LED is on. If not, short press once to select AUX audio. b. Now, you should be able to use the headphone. If no sound, please ensure your TV speaker is set to “Headset” TVs with RCA Audio Out (Red/White ports labeled "AUDIO OUT") Set up Oasis Plus using RCA audio out Now you should be able to use the headphones.

  • Page 7: Use Ht5009 With Your Av Receiver With 6.35Mm Phone Jack

    Use the correct RCA ports Set TV speaker to "External Speaker" Use HT5009 with your AV Receiver with 6.35mm PHONE jack Set up Oasis Plus using 6.35mm phone jack Make sure the “AUX” LED is on, if not, short press once to select AUX audio.

  • Page 8: Add A 2 Nd Pair Of Bluetooth Headphones

    Step 3: Turn on Bluetooth on your Bluetooth enabled device. Find & select “Avantree AS9S” to pair and connect. The next time, you would like to use your headphones this way you will need to select “Avantree AS9S” on your Bluetooth enabled device to reconnect.

  • Page 9: Clear Pairing History

    After turning on, press and hold both “+”and”-“ for 10 seconds until the LED turns PINK - now the pairing history of the headphone has been cleared, it will enter pairing mode automatically with the LED flashing alternately and BLUE. Hold for 10s Troubleshooting https://support.avantree.com/hc/en-us/sections/360003036792...
