Peak Silicone Plus PSH201 Installation Instructions

WARNING: Failure to properly install wiper blades may cause the blades to not work properly or detach. Follow all instructions
carefully and use only the correct adapter for your vehicle. After installation, check to ensure the blades are securely attached.
Identify your vehicle's wiper arm and follow the instructions. Remember to remove the plastic rubber protector before installation.
1. Pull the adapter latch up to open.
HOOK
Rotate the back of the adapter upward.
Push the wiper arm end through the
hole in front of the adapter.
1. Rotate the back of the adapter
SIDE LOCK
upward and insert wiper arm into the
1/4" & 3/16"
matching hole size in the wiper frame.
1. Rotate the back of the adapter
BAYONET
upward and push blade onto wiper arm.
1. Remove the pre-attached adapter by
PINCH TAB
rotating the blade upside down, pinching
the clips on both sides of the blade, and
pulling the adapter downward.
To determine the size of your Push Button wiper arm, use a penny or ruler below to measure. A penny will fit firmly into the end of the 22mm wiper arm but will not fit into the end of the 19mm wiper arm.
1. Remove the pre-attached adapter by
PUSH BUTTON
rotating the blade upside down, pinching
(22mm)
the clips on both sides of the blade, and
pulling the adapter downward.
PRODUCT QUESTIONS OR COMMENTS CONTACT TECHNICAL SUPPORT:
WIPER BLADE INSTALLATION INSTRUCTIONS
2. Pull wiper blade past the front tabs of
the adapter until you feel the blade lock
into place. Push the adapter latch down
to lock into place. After installation, tug
firmly on the blade to ensure it is
securely attached.
2. Push adapter down until it locks on
the inserted wiper arm pin.
2. Dimple on wiper arm must lock firmly
into the hole in the top of the adapter.
2. Rotate the blade upright and lock the
long base adapter into the blade by
snapping clips fully into place.
2. Rotate the blade upright and lock the
long base adapter into the blade by
snapping clips fully into place.
(800) 477-5847 • owitech@owi.com
Scan for PEAK
and installation videos or visit PEAKauto.com
To Activate Water Repellency
1. Run wipers at medium speed on a
clean, dry windshield for 3 to 5 min.
2. Spray washer fluid and allow
blades to clear windshield.
3. Slide adapter with arrow onto the
wiper arm end until it locks into place.
3. Fold wings on adapter "3H-2" forward
so they lock into place at the front of the
adapter. Insert the back end of the adapter
into the wiper arm opening. The button in
the middle of the adapter must lock into
the hole in the top of the wiper arm.
wiper blade product information
®
4. Snap wiper arm with connected
adapter onto base adapter.
4. Snap wiper arm with connected
adapter onto base adapter.
