Peak OPTIX OTV281 Installation Instructions

WARNING: Failure to properly install wiper blades may cause the blades to not work properly or detach. Follow all instructions
carefully and use only the correct adapter for your vehicle. After installation, check to ensure the blades are securely attached.
Identify your vehicle's wiper arm and follow the instructions. Remember to remove the plastic rubber protector before installation.
1. Position the
HOOK
wiper blade
parallel to the
wiper arm.
1. Lift up the
SIDE LOCK
back of the
1/4" & 3/16"
pre-attached
adapter.
1. Lift up the
back of the
PINCH TAB
pre-attached
adapter.
To determine the size of your Push Button wiper arm, use a penny or ruler below to measure. A penny will fit firmly into the end of the 22mm wiper arm but will not fit into the end of the 19mm wiper arm.
1. Lift up the
PUSH BUTTON
back of the
(22mm)
pre-attached
adapter.
PRODUCT QUESTIONS OR COMMENTS CONTACT TECHNICAL SUPPORT:
WIPER BLADE INSTALLATION INSTRUCTIONS
2. Pull the blade 3. Continue to pull pass
into the wiper
the front adapter tabs
arm hook.
until you hear the blade
lock into place. After
installation, tug firmly
on the blade to ensure
it is securely attached.
1/4''
3/16''
2. Pull out 3. Align the "F3"
adapter to adapter with the
remove and corresponding
discard. hole size on the
coupler.
2. Pull out 3. Install the "M"
adapter by
adapter to
aligning the arrow
remove and
on the adapter
discard.
with the arrow on
the base of the
wiper blade.
2. Pull out 3. Install the "M"
adapter by
adapter to
aligning the arrow
remove and
on the adapter
discard.
with the arrow on
the base of the
wiper blade.
(800) 477-5847 • owitech@owi.com
Scan for PEAK
and installation videos or visit PEAKauto.com
3/16''
1/4''
4. Snap down the 5. Insert wiper
"F3" adapter onto arm into the
the plastic pin in correct size hole
the blade. in wiper frame
until it locks in
place.
4. Snap the 5. Attach the "A"
adapter down in adapter onto the
the back to "M" adapter.
engage onto the
base.
4. Snap the 5. Attach the "A"
adapter down in adapter onto the
the back to "M" adapter.
engage onto the
base.
wiper blade product information
®
6. Insert the tip 7. Rotate the
blade into the
of the wiper arm
wiper arm until
into the front of
the tabs in the
the adapter.
back of the
adapter lock into
the wiper arm.
6. Insert the 7. The button in
back end of the the middle of the
adapter into the adapter must
wiper arm lock into the
opening. hole in the top of
the wiper arm.
