Installation - Graco PRO 5500HC Instructions-Parts List Manual

Non-Hazardous Area
solenoid
solenoid
bleed-type
air shutoff
valve
solenoid
Air Regulator
Fig. 1
Non-Hazardous Area
24V Power
Supply
P/N 235–301
KV
4-20 mA
Outputs
A
85.0 KV
Fig. 2

Installation

Hazardous Area
Hose Ground
Wire
TURBINE AIR–TA
KV HI/L0–KV*
ATOM AIR–A1
FAN AIR–A2
CYLINDER AIR–CYL
True
Earth
FLUID IN–P1
Ground
Hazardous Area
Full Feature
ES Display Module
P/N 224–117
Bulkhead
P/N 189–870
F.O. Cable
P/N 224–680/686
F.O. Cable
P/N 224–670/676
KV Only
Display Module
(battery operated)
P/N 189–762
AIR PILOT
1/4" O.D.
FLUID IN
3/8" O.D.
DUMP TRIGGER
5/32" O.D.
FLUID RETURN
1/4" O.D.
Graco Grounded
Air Hose (see pg. 10 for P/Ns)
1/4" O.D.
3/8" O.D.
3/8" O.D.
1/4" O.D.
1/4-18.6 npsm
Fluid Connector
*KV air line connection is optional. Plug if not used.
FIBER OPTIC–F.O.
P1
P2
Dump Valve
P/N 236–853
BASIC SYSTEM
PRO 5500HC Spray Gun
Mount for 1/2" rod
with keyed slot for positioning
SYSTEM OPTIONS
Spraying Voltage
Display Module
PRO 5500HC SPRAY GUN
Air Pilot Fluid Regulator
Dump Valve
Air Pilot Fluid Regulator
P/N 236–854
PRO 5500HC
SPRAY GUN
TOP VIEW
Fluid Recirculation Kit
P/N 237–302
1.
