- Page 1 Model PM-17SA User Guide Integrated Amplifire...
-
Page 2: Equipment Mains Working Setting
Connection of speaker cord storm, to disconnect the equipment from the mains supply. Strip coating from extermity. To ventilae the unit, do not install the unit in a rack or bookshelf, and note the followings. Twist conductors. - Do not touch the top of the enclosure during operation. - Page 3 - It is also possible to connect a BS tuner, LV player, TV or other component to LINE1-LINE3 jacks. - The audio input/output jacks of VCR or other component can be connected to CD-R and TAPE as their program sources.
- Page 4 OUT jack and MAIN IN jack. SEPARATE/COUPLED switch When this switch is set to COUPLED, the PRE OUT jack and MAIN IN jack are connected internally, allowing the PM-17SA to be used as a pre-main amp. When the switch is set to SEPARATE, the PRE OUT jack and MAIN IN jack are internally disconnected, allowing the PM-17SA to be used as a pre-amp or main amp.
-
Page 5: Names Of Controls And Indicators
LINE 1 – LINE 3 INPUT jacks For the best audio quality, we recommend that you plug your These are LINE 1 – LINE 3 input jacks which can be used to CD player, MD player, or other digital audio component into a... - Page 6 The meter positions immediately after turning power on and at the end of warming up and the time taken for warming up are variable depending on the temperature, ventilation and other conditions of the listening room where the unit is located.
- Page 7 3. Operate the CD recorder or the tape deck to start recording. - Do not turn power of the turntable off while the stylus is placed on a disk. Recording of a source connected to one of LINE 1 to LINE 3 1.
-
Page 8: Remote Control Operation
*1 Pressing one of these buttons (CD, CD-R,TUNER, TAPE OPEN/CLOSE Open/close DECK, etc., except for PHONO and LINE3) change the func- tions of the buttons in groups x, c and v according to the Disc Up (changer-equipped model only) selected source component. –... -
Page 9: How To Use The Remote Control Unit
Amplifier volume Down Remote control unit (RC-17mk2PM) Button functions when the LINE2 button is pressed: 2. Loading batteries The service life of the batteries used in the remote control unit Button Function is about 1 year under normal use. VCR play... -
Page 10: Troubleshooting
2. Connect the grounding wire of the turntable to the GND terminal on the rear panel of the amplifier set. If it has al ready been connected, try removing it. 3. Check that the cartridge is attached properly to the tone arm. - Page 11 TECHNICAL SPECIFICATIONS (DIN) Rated power output (20Hz to 20 kHz, 2ch simultaneous drive) ........ 60 W x 2 (8 Ω load) 80 W x 2 (6 Ω load) 100 W x 2 (4 Ω load) Total harmonic distortion (20Hz to 20 kHz, 2ch drive, 8 Ω load) ............ 0.01 % Cross-modulation distortion (SMPTE) ...................
- Page 12 SPEAKERS SPEAKERS IMPEDANCE L+R:4-8 OHMS BTL:8-16 OHMS SEPARATE PHONO 1 / TUNER MAIN COUPLED AC IN LINE CD-R TAPE 1.0A 120W MAX TOTAL 1.0A 120W MAX SWITCHED UNSWITCHED 120V 60HZ AC OUTLETS SERIAL NO. REMOTE CONTROL PHONO INPUT SELECTOR VOLUME...
- Page 13 PASCO GmbH PO BOX 1280, Sandhausen 69200, Germany NETHERLANDS Marantz Domestic Sales A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands NEW ZEALAND Wildash Audio Systems 14 Malvern Road, Mt. Albert, Auckland, New Zealand...
