7. Plug the vent fuel line opening with the clevis pin
(P/N 8153). Secure the vent fuel line and clevis pin
with a zip tie and the factory clamp.
FACTORY
CLAMP
ZIP
TIE
FACTORY
FILTER VENT
FUEL LINE
Figure 13. Plugging Factory Vent Fuel Line
FACTORY FILTER AND BRACKET REMOVAL
1. Using a 10mm socket, remove and discard the factory
fuel filter bracket and hardware as shown in Figure 14.
10mm
SOCKET
Figure 14. Factory Fuel Filter
and Bracket Removal
DA/DAC7000 SERIES — MQPILHEATER KIT INSTRUCTIONS P/N 59037 — REV. #1 (04/13/15) — PAGE 5
CLEVIS
PIN
FACTORY FUEL
FILTER BRACKET
FACTORY FUEL
FILTER
FACTORY FUEL
FILTER HARDWARE
INSPECTION
1. Connect the negative cable (BLACK) to the negative
terminal on the battery first, then connect the positive
cable (RED) to the positive terminal on the battery.
2. Test the unit for any leaks and proper operation.
3. Check that your installed MQPILHEATERKIT appears
similiar to the correctly installed MQPILHEATERKIT as
shown in Figure 15.
Figure 15. Correctly Installed
MQPILHEATERKIT
