- Page 1 Multi Variable Air Conditioners Console Type Indoor Unit Owner's Manual Air Conditioners Models: AFKMI-22VRDC1A AFKMI-28VRDC1A AFKMI-36VRDC1A AFKMI-50VRDC1A Thank you for choosing Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference.
- Page 2 Preface For correct installation and operation, please read all instructions carefully. Before reading the instructions, please be aware of the following items: (1) For the safe operation of this unit, please read and follow the instructions carefully. (2) During operation, total capacity of indoor units should not exceed the total capacity of outdoor units.
-
Page 3: Table Of Contents
Content 1 Safety Precautions ....................1 2 Installation of Indoor Unit ..................3 2.1 Indoor Unit ........................3 2.2 Refrigerant Piping ......................5 2.3 Drain Piping ......................... 6 2.4 Installing Indoor Unit ....................7 3 Constitutes and Names of Every Part of Indoor Unit ..........13 4 Working Temperature Range ................ -
Page 4: Safety Precautions
Multi Variable Air Conditioners Console Type Indoor Unit 1 Safety Precautions means items that must be forbidden! Otherwise, it may lead to personal injury or death or serious damage. means items that must be followed! Otherwise, it may lead to personal injury or property loss. - Page 5 Fault service may main power supply, and then cause electric shock or fire immerdiately contact AlpicAir accidents. Please contact service center.If abnormality AlpicAir service center for keeps going, theunit might be help. damaged and lead to electric shock or fire.
-
Page 6: Installation Of Indoor Unit
Multi Variable Air Conditioners Console Type Indoor Unit 2 Installation of Indoor Unit Selection of Installation location . （1）Such a place where cool air can be distributed throughout the room. （2）Such a place where condensation water is easily drained out. （3）Such a place that can handle the weight of indoor unit. - Page 7 Multi Variable Air Conditioners Console Type Indoor Unit Location for securing the installation pane Schematic drawing of hooks.
-
Page 8: Refrigerant Piping
Multi Variable Air Conditioners Console Type Indoor Unit 2.2 Refrigerant Piping （1）Drill a hole ( 65mm in diameter ) in the spot indicated by О the symbol in the illustration ad below. （2）The location of the hole is different depending on which side of the pipe is taken out . （3）For piping ,see Connecting the refrigerant pipe ,under Indoor Unit Installation. -
Page 9: Drain Piping
Multi Variable Air Conditioners Console Type Indoor Unit （1）Bore a feed-through hole of 65mm in the wall so it has a down slope toward the outside. （2）Insert a wall pipe into the hole. （3）Insert a wall cover into wall pipe. （4）After completing refrigerant piping, wiring, and drain piping, caulk pipe hole gap with putty. -
Page 10: Installing Indoor Unit
Multi Variable Air Conditioners Console Type Indoor Unit 2.4 Installing Indoor Unit 2.4.1 Preparation （1）Open the front panel, remove the 4 screws and dismount the front grille while pulling it forward. （2）Follow the arrows to disengage the clasps on the front case to remove it. （3）Follow the procedure below when removing the slit portions. - Page 11 Multi Variable Air Conditioners Console Type Indoor Unit 2.4.2 Installation Secure using 6 screws for floor installations.(Do not forget to secure to the rear wall.) For wall installations, secure the mounting plate using 5 screws and the indoor unit using 4 screws.
- Page 12 Multi Variable Air Conditioners Console Type Indoor Unit pipe. （3）Fit the flare nut on the pipe. （4）Flare the pipe. （5） Check that the flaring is properly made. Warning ①. DO not use mineral oil on flared part. ②. Prevent mineral oil from getting into the system as this would reduce the lifetime of the units.
- Page 13 Multi Variable Air Conditioners Console Type Indoor Unit Caution on piping handling: （1）Protect the open end of the pipe against dust and moisture. （2）All pipe bends should be as gentle as possible. Use a pipe bender for bending. (Bending radius should be 30 to 40mm or larger.) Selection of copper and heat insulation materials: ...
- Page 14 Multi Variable Air Conditioners Console Type Indoor Unit Cautions ①. Insulate the joint of the pipes securely.Incomplete insulation may lead to water leakage. ②. Push the pipe inside so it does not place undue force on the front grille. Connecting the drain hose Insert the supplied C drain hose into the socket of the drain pan.
- Page 15 Multi Variable Air Conditioners Console Type Indoor Unit Notes: The power of every indoor unit should be unity power supply. （1） The power connection cord have been inserted on the mainboard through the piping hole of the chassis.Please connect the power connection cord with the breaker. If the power cord is not long enough,please prolong it with terminal block.
-
Page 16: Constitutes And Names Of Every Part Of Indoor Unit
Multi Variable Air Conditioners Console Type Indoor Unit Install the connection pipes Connect the connect pipe with the two relative leading pipe, tie the nut on tie in of the connect pipe tightly. Notes: ①. Be careful in bending the connection pipes, or you will damage the pipes. ②. - Page 17 Multi Variable Air Conditioners Console Type Indoor Unit • When the unit receives a signal, you will hear a short beep. • Settings changed beep. （16）Air outlet selection switch. • It senses the air temperature around the unit. Notes: ①. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
-
Page 18: Working Temperature Range
Multi Variable Air Conditioners Console Type Indoor Unit 4 Working Temperature Range Indoor side state Outdoor side state Dry bulb temp℃ Wet bulb temp℃ Dry bulb temp℃ Wet bulb temp℃ Rated Cooling Max. cooling Min. cooling — Rated Heating Max. heating —... -
Page 19: Preparation Before Operation
Multi Variable Air Conditioners Console Type Indoor Unit Button name Function ON/OFF Turn on or turn off the unit TURBO Set turbo function MODE Set operation mode Set up&down swing status I FEEL Set I FEEL function TEMP Switch temperature displaying type on the unit’s display Set health function and air function LIGHT Set light function... - Page 20 Multi Variable Air Conditioners Console Type Indoor Unit Notes: When operation mode changes, fan speed is memoried; Under dry mode, fan speed is low and can not be adjusted. Setting swing function Setting left&right swing Under simple swing status, press button to adjust left&right swing status;...
- Page 21 Multi Variable Air Conditioners Console Type Indoor Unit In cool or dry mode, press X-FAN button to set X-FAN function. When is displayed, X-FAN function is on. When is not displayed, X-FAN function is off. When X-FAN function is on, the water on the evaporator will be blown away until turning off the unit to avoid mildew.
-
Page 22: Introduction Of Special Functions
Multi Variable Air Conditioners Console Type Indoor Unit ④. Press TOFF button again to cancel timer and OFF is not displayed. 2). Setting timer on ①. Pressing TON button, “ON” is blinking and time displaying zone displays the timer time of last setting. -
Page 23: Maintenance Method
Multi Variable Air Conditioners Console Type Indoor Unit Fig.1 Fig.2 Notes: ①. The remote controller should be placed 1m away from the TV set or stereo sound sets. ②. The operation of remote controller should be performed within its receiving range. ③. - Page 24 Multi Variable Air Conditioners Console Type Indoor Unit Cautions ①. Don’t touch the metal parts of the indoor unit. If you touch those parts, this may cause an injury. ②. When removing or attaching the front panel, use a robust and stable stool and watch your stepscarefully.
-
Page 25: Filters
Multi Variable Air Conditioners Console Type Indoor Unit 6.3 Filters （1）Open the front panel. （2）Remove the air filter. · Press the claws on the right and left of the air filter down slightly, then pull upward. （3）Take off the Titanium Apatite Photocatalytic Air-Purifying Filter. ·... -
Page 26: Titanium Apatite Photocatalytic
Multi Variable Air Conditioners Console Type Indoor Unit 6.4 Titanium Apatite Photocatalytic Air-Purifying Filter The Titanium Apatite Photocatalytic Air-Purifying Filter can be renewed by washing it with water once every 6 months. We recommend replacing it once every 3 years. （1）Vacuum dusts, and soak in warm water or water for about 10 to 15 minutes if dirt is heavy. -
Page 27: Function Description Of Functional Dial Switch S7
Multi Variable Air Conditioners Console Type Indoor Unit 7 Function Description of Functional Dial Switch S7 （1）The 3-bit dial switch must be set before energizing the main board and it determines running state of indoor unit. （2）Function of it is as follow: Dial switch Function Dial ON... -
Page 28: Service Center
Multi Variable Air Conditioners Console Type Indoor Unit Under the circumstance of changed batteries, the wireless remote controller sometimes would appear the phenomena of couldn’t control. Take out the back cover and press ”ACL” button to make it normal. The air conditioner is under abnormal disturbance or changing function too Wireless remote controller frequently, to make wireless remote controller cannot control. - Page 29 _______________________________________________________________________________________ WWW.ALPICAIR.COM...
