L I B E R T Y 3
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIBERTY 3 and is the answer not in the manual?

Questions and answers

Related Manuals for Anchor LIBERTY 3

Summary of Contents for Anchor LIBERTY 3

  • Page 1 L I B E R T Y 3 OWNER’S MANUAL...

  • Page 2: Table Of Contents

    - and ears - are 110% committed to delivering reliable battery-powered portable sound systems for you. The Liberty 3 is one step beyond with our new Series 3 technology that includes enhanced sound, microphones, battery performance, and range.

  • Page 3: Quick Look

    QUICK LOOK Your Liberty 3 was built to thrill crowds of 1500+ with an enormous 123 dB of crystal-clear sound output from a 200- watt amplifier/mixer with vanishingly low distortion. A full battery will give you approximately 7 hours of playtime, and the optional external PowerPack, if purchased separately, will extend your playtime by 50%.
  • Page 4 • Two universal wired mic inputs Features Overview Click to watch...

  • Page 5: Getting Started

    • LINK refers to joining Anchor Wireless microphone with your Liberty 3 audio unit. • CONNECT refers to joining other Anchor Audio units with your Liberty 3 audio unit. Note that your Liberty 3 system is a series 3 system. You can only connect with other Anchor Audio series 3 speakers.

  • Page 6: Arranging Your Speakers

    With your Liberty 3, connected speakers can be placed within 300+ feet of the main unit without experiencing latency and/or breaking the wireless connection. When setting up your Anchor systems make sure to place the Main Unit in the center with Companion Units on either side.

  • Page 7: Basic Operation

    BASIC OPERATION Before using your Liberty 3 with battery power, please ensure your unit is charged before you begin. To charge your internal battery, plug the power cord into the Power Outlet on the speaker, and plug the other end into an AC outlet.
  • Page 8 BACK PANEL This is the back panel of your Liberty 3 SCAN CODE WITH YOUR SMARTPHONE CAMERA FOR USER GUIDE ANCHORFLEX MAIN POWE CONTAINS TRANSMITTER MODULES BLUETOOTH FCC ID: 2AMWO- FSCBT1026 IC: 23872-FSCBT1026 DECT FCC / IC ID: Y82-DA14AVD / 9576A-...

  • Page 9: Using Bluetooth

    Now you can play audio from your Bluetooth device on your Liberty 3. You can adjust the volume by using the Main Volume knob on the speaker, as well as the volume control on the Bluetooth device.
  • Page 10 Bluetooth. To avoid interrupting your audio stream, set your device in airplane mode, then enable Bluetooth. When you are connected to the Anchor Audio speaker, you will not encounter any interruptions in your audio stream. *Your Bluetooth connection and behavior may depend on your device settings and capabilities. Our testing was done...

  • Page 11: Linking Your Wireless Microphones

    LINKING YOUR WIRELESS MICROPHONES Your Liberty 3, if equipped with AnchorLink 3, can link up to four Anchor Audio Series 3 Wireless Microphones. To Link your microphones, follow the steps below. GET YOUR MICS READY TO LINK 1. Before you turn your mic on, press and hold the MUTE Click to watch button on the belt pack or the wireless handheld mic..
  • Page 12 TO UNLINK WIRELESS MICROPHONES This process unlinks all microphones from the speaker. Once unlinked, a microphone will have to repeat the link steps to be used with that speaker. 1. Start with the speaker On and AnchorLink 3 Off. (The AnchorLink 3 Status LED will be off.) 2.
  • Page 13 Q: Can I control the volume on the AnchorLink mic and/or belt pack? A: Yes! Anchor Audio’s Series 3 microphones feature both volume and mute buttons, so you can mute and even adjust the volume of the microphone or belt pack to fit your needs.
  • Page 14 CONNECTING SPEAKERS TOGETHER AnchorFlex 3 is the transceiver technology that allows you to connect multiple Anchor Audio speakers together for greater area coverage. This unique feature allows you to change the speaker to a transmitting speaker or a receiving speaker, configuring systems for your current needs on the fly.
  • Page 15 CONNECT COMPANION UNITS Once your Main Unit is set to transmit, you can designate and connect your Companion Units. 5. Power off the Companion Unit(s). Then power it/them up. 6. Once the speaker is powered up, rotate the AnchorFlex Power/Volume knob clockwise to turn AnchorFlex on. The Status LED will turn red.
  • Page 16 ANCHORFLEX FREQUENTLY ASKED QUESTIONS Q: How does the AnchorFlex wireless connection work? A: Simple! AnchorFlex 3 can operate as a transmitter or receiver. When one unit is set as a transmitter, and one or more units are set as receivers, and those units are connected, the transmitter will send audio to the receivers, and all will play the same sound.

  • Page 17: Anchorpower Information

    ANCHORPOWER INFORMATION Your Liberty 3 comes with two internal Lithium-Ion batteries, which give it approximately 8-10 hours of playtime when fully charged. There is also an optional PowerPack external battery that can be plugged into the speaker for an additional 50% more power.
  • Page 18 PowerPack. AC OPERATION AND CHARGING YOUR BATTERIES Your Anchor Audio system includes an automatic charging system designed to properly charge and maintain the built-in Lithium-Ion battery. To charge your internal batteries, follow the steps below: 1. Plug one end of the power cord that came with your speaker into the plug port on the lower right corner of the back panel.
  • Page 19 BATTERY WARRANTY • All Lithium-Ion batteries come with a standard four-year warranty. However, Anchor Audio provides the option to purchase an additional two-year extended warranty within the first 30 days of purchase of your Anchor Audio sound system. • With the extended battery warranty, your battery will match the six-year warranty of your Anchor Audio portable sound system.

  • Page 20: Technical Specifications

    TECHNICAL SPECIFICATIONS Rated Power Output 200 watts Max SPL @ Rated Power 123 dB @ 1 meter Frequency Response 40 Hz ~ 20 kHz ± 3dB AC Power Reqs 100~240 VAC, 50/60 Hz, 2A Charger/Power Inlet PC-2 Battery Two 12.8V Lithium Iron Phosphate rechargeable (LiFePo4), 10.2 Full recharge: ~ 5 hours AnchorLink 3 Wireless Frequency 1920~1930 MHz USA/CAN;...

  • Page 21: Model Numbers

    MODEL NUMBERS...
  • Page 22 If you need a member of our service team to assist, you can submit a support ticket here: https://www.anchoraudio.com/technical-support You can also reach Anchor Audio’s technical support team by phone at (800) 262-4671 x2 or email: techsupport@anchoraudio.com You may also find these videos helpful:...

  • Page 23: Important Safety Instructions

    European Union (CE) regulations and recommendations. On Symbol The On Symbol in the figure to the left represents a power switch position on the Anchor Audio product. This symbol represents a Power On condition.
  • Page 24 Do not attempt to operate this equipment if there is evidence of shipping damage or you suspect the unit is damaged. Damaged equipment may present additional hazards to you. Contact Anchor Audio Technical Support for advice before attempting to plug in and operate damaged equipment.
  • Page 25 IMPORTANT SAFETY INSTRUCTIONS (CONT.) 1. Read Instructions – All the safety and operation instructions should be read before the product is operated. 2. Retain Instructions – The safety and operating instructions should be retained for future reference. 3. Heed Warnings – All warnings on the product and in the operating instructions should be adhered to. 4.
  • Page 26 IMPORTANT SAFETY INSTRUCTIONS (CONT.) 16. Lightning – For added protection, unplug this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

  • Page 27: Anchor Audio Warranty

    BATTERIES PERIPHERALS Anchor Audio products are warranted to be free from defects in materials and workmanship for the period of SIX (6) YEARS from the date of original purchase unless listed below. Warranted for a period of FOUR (4) YEARS: •...

  • Page 28: Anchor Audio Return Authorization Procedures

    C.O.D. shipments and shipments without an RA number will be refused and returned at your expense. • In all cases, dealers and end users must first obtain approval from Anchor Audio for any product they are attempting to return to Anchor Audio. Upon approval, a Return Merchandise Authorization (RMA) number will be issued by the Anchor Audio Customer Service Department and must accompany all products returned.
  • Page 29 CONTACT US 5931 Darwin Court Carlsbad, CA 92008 USA | anchoraudio.com Technical Support Team 800.262.4671 x2 techsupport@anchoraudio.com Sales Team 800.262.4671 x1 sales@anchoraudio.com LIB3-02.23.24-rev A.1...
