  • Page 1 BSW116 Smart Watch User Manual...
  • Page 3 Downloading and connecting of smart watch with Da Fit APP 1.Download and install Da Fit APP. 2.Scan QR code with mobile phone to down- load APP. 3.For IOS system, select APP Store,search for Da Fit App. Android system, select Google Play to down- load and install Da Fit App.
  • Page 4 Download APP Download Da Fit From Watch QR APP in Smartphone Code or UM Open Da Fit APP Connect smart watch with Da Fit APP Fulfill your data when first Click “To ADD” to search use Da Fit App...
  • Page 5 Click on your device in the Successfully connected Device List with APP If watch is connected with APP successfully, the Bluetooth icon in control center will light up...
  • Page 6 How to connect Step 1: As BSW116 smawatch is a single chipset smart watch,so you only need to connect smart watch with APP.Then the watch will connect with phone bluetooth automatically.Then you can use...
  • Page 7 Please check the following steps for iOS and Andr- oid based on the system of your phone. For iOS After connecting with APP, it will remind you to connect phone BT call function by connecting mobile phone bluetooth in phone setting menu.
  • Page 8 Please check your iOS After connecting with iOS bluetooth setting list to bluetooth,it will show search and connect “Audio-FireBoltt 116” in “Audio-FireBoltt 116” “MY DEVICE” list After successfully connecting with phone bluetooth,the watch Phone Call interface will display as above If you can not connect with phone bluetooth,please check as below: Checking the setting list to make sure “Phone”...
  • Page 9 Then try to connect with phone bluetooth as above steps After connecting with APP, APP will show a “Bluetooth Pairing Request”,you just need to click to “Pair”...
  • Page 10 After confirming to pair with phone bluetooth,APP will ask “Allow FireBoltt 116 to Receive Your iPhone Notification”,please click to allow After successfully connecting with phone bluetooth,the watch Phone Call interface will display as above...
  • Page 11 If you can not connect with phone bluetooth,please check as below: Checking the setting list to make sure “Phone” is on Then try to connect with phone bluetooth as above steps...

  • Page 12: For Android

    For Android After connecting watch with Da Fit APP,it will ask you to “Allow access to your contacts and call history”,please allow to pair Step 2: Go back to watch and enter Phone Call interface to make phone calls,check records and contacts.
  • Page 13 Phone Call Interface Part A - Making Bluetooth Phone Calls Tap “Dial pad” icon to enter into Dial pad. Then you can make bluetooth phone calls via smartwatch.
  • Page 14 Part B - Add Frequent Contacts Click “My device” in Da Fit APP to check device settings of smart watch,then tap “Frequent Cont- acts” to add frequent contacts from phone cont- acts to watch.
  • Page 15 Part C - Check and Sync Recent Calls Tap Recent Call from Bluetooth Calling inter- face to check recent calls. Part D - Switch Calls between Phone or Watch Switch Between Watch or Phone during an active call: If your watch is connected to the Phone via Blue- tooth,all calls will come on the watch by default.
  • Page 16 Part E - How to Disconnect If you want to disconnect watch with APP and Phone Bluetooth.You could turn off your phone bluetooth function directly. Or,you can enter into Setting Center,then tap “Phone Call” icon to turn off.
  • Page 18 Charge The Battery And Battery Advisory BSW116 charger is a 2-pin magnetic charger. If you need to charge smartwatch,you can just put the 2-pin charger on the charging port of the smart watch. There is a heart rate sensor protector on the sensor,you...
  • Page 19 It takes about 2 hours to 2.5 hours to fully charge the battery.For first using,please charge the battery for 2.5 hours before using. The battery lifetime depends on your usage of the smartwatch.The below lifetime is only for your reference. General standby time is 25 Days(Not with Screen Always-on function).

  • Page 20: Functions Navigation

    Functions Navigation The screen can be navigated by swiping left/right or swiping up/down. Control Center Swipe Down Swipe Up Swipe Swipe Left Left Swipe Swipe Right Right Hot Key Main Interface Basic Function Interface Swipe Down Swipe Up Message Part A - Control Center Swipe down to view watch control center.
  • Page 21 ● Bluetooth Reminder ● Vibration Setting ● Flash Light ● Theater Mode ● Brightness Setting ● Weather ● Settings Bluetooth Reminder: Instruct the bluetooth connect- ion status. Vibration Setting: You can turn or turn off vibration by tapping the icon. Flashlight: You can turn on or turn off the smart watch flashlight by tapping the icon.
  • Page 22 Part C - Split Hot Key Interface Swipe right to enter into Split Hot Key Interface. You can quick check Steps,Weather,Heart Rate, Spo2,BT Call,and Sports Mode functions here. Part D - Basic Function Interface Swipe left or right to enter into basic functions interface.
  • Page 23 Button Functions and Wearing Part A - Side Button BSW116 is with two buttons. Two Buttons functions are as following: Up Button: 1.Functions Button-To enter into all functions interface directly. 2.Sports Mode Hot Key-Long press the down button for 5 seconds to enter into Sports Mode.
  • Page 24 Part B - Watch Wearing For accurate testing data,we recommend to wear the watch with a moderate tightness at a gap of two fingers from your wrist to ensure that the sensor can work properly. Please do not wear too loose when using the heart rate monitoring and Spo2 functions.
  • Page 25 Functions Part A - Main Interface Functions Bluetooth Phone Call - After watch connecting with APP and phone Bluetooth.You can make or receive phone calls,check call records, check contacts.
  • Page 26 Steps - You can check your activity data including steps data,calories data.7 days data will be rema- ined.And swipe up to check more data. Sleep Monitoring - You need to wear the watch while sleeping.It will provide the hours slept and quality of sleep stats.Swipe up to check more data.
  • Page 27 Heart Rate Monitoring - The watch will record your heart rate all day. You can also tap on the page to start measuring.24 hours data will be remain- ed.Swipe up to check more data. Spo2 Monitoring - The watch can test your Spo2 date.You can also tap on the page to start measur- ing.7 latest values will be remained.Swipe up to check more data.
  • Page 28 Voice Assistant - Tap “Click” to use phone Voice Assistant.Please ensure the watch is connecting with phone bluetooth,before using Voice Assist- ant function. Weather Forecast - You can know the current weather and the forecast for tomorrow, this information is synced from your APP. Scroll up to see the forecast weather.
  • Page 29 Part B - Other Functions You can add other main functions to the main function interfaces.The main functions includes: Breathing,Stopclock,Alarm,Shutter,Exercise Record,Flashlight,Calculator,Period,Timer, Message,Music Player. Breathing - Enter into breathing to take breath- ing and relax.
  • Page 30 Stopclock - This helps to track the time frame for any given activity. Alarm - Set alarms and let your watch vibrate to remind you of the alarm. Shutter - After watch connecting with APP.Tap the shutter icon to remote control the camera of your phone to take photos.
  • Page 31 Flashlight - Never be scared in the dark again. The watch supports a flashlight. Calculator - This new feature lets you access the calculator on the watch itself. Period - If you set Lady Period on Da Fit APP,watch will remind you based on what you set via Da Fit APP.
  • Page 32 You can clear the message record by tapping “Clear All”. Music Player - BSW116 smart watch supports mobile music player.The watch will play the phone music after you connect the watch with APP and phone bluetooth.(Please note,the wa- tch must be both connected with APP and ph- one Bluetooth).
  • Page 33 Settings - Swipe down from main interface to enter into Control Center and tap “Setting” icon to enter into setting list to set the watch system. Display Setting Tap “Display” to enter and set display.Set Auto Sleep time,Menu View,Brightness,Watch Face. Call Alert Setting Tap “Call Alert”...
  • Page 34 Low Power Mode Setting Tap “Low Power Mode” to open or close Low Power Mode. Theater Mode If you tap to turn on the Theater Mode,the brightness will dim and vibration will shut. Phone Mode Setting Tap “Phone” to open or close bluetooth phone call function.
  • Page 35 Always-on Screen - You can turn Always-on screen function to set always-on screen. System Setting Tap “System” to restart watch,shut down watch or reset watch data. About Tap “About” to check watch version and QR Code.
  • Page 36 Part C - Featured Functions Watch Face - There are 10 in-built watch faces, you can download watch face from Da Fit APP, and you can DIY the watch face via Da APP as well.
  • Page 37 You can download watch face and do DIY watch face via Da Fit APP Dial setting.
  • Page 38 Exercise - Swipe right to enter into Hot key,then tap Sports Mode icon to enter into sports mode interface.There are more 110 sports modes for your exercise selections.
  • Page 39 You can add any sport mode to Popular Sports for quick view. You can select any of the sports modes to start your exercise.
  • Page 40 Games - There are 2 in-built games,you could enjoy the happy time when take rest.
  • Page 41 Watch Reminders Sedentary Reminder If you set Sedentary function on Da Fit APP,watch will remind you to move if you have not moved up for a long time. Drink Water Reminder If you set Drink Water Reminder function on Da Fit APP,watch will remind you to drink water based on what you set via Da Fit APP.
  • Page 42 Wearing Reminder Watch will remind to wear the watch well,when you do testings. Gold Achieved Reminder Watch will remind you the goal you set via Da Fit APP has been finished.
  • Page 43 Low power and charging reminder If the watch runs out of power,it will remind you to charge.And when you charge the watch,the watch will display charging icon.
