- Page 1 Smart Watch User Manual...
- Page 2 Downloading and connecting of smart watch with Da Fit APP Download and install Da Fit APP Scan QR code with mobile phone to download APP. Android system, select Google Play to download and install Da Fit App. Or scan QR code to download Connect smart watch with Da Fit APP Click on "Add Device"...
- Page 3 Click on your device in the device list scanned. Connect it directly to Android system. Successfully connected For both android & iOS click on Enable all the notifications Notifications Tab in the Dafit for the ease of use...
- Page 4 BLUETOOTH CALLING FUNCTION This watch comes with a special feature of Bluetooth calling. The user can make calls without having to open the phone. You can also view the call history of the watch. You need to keep the connection between the watch and the phone stable when using the Phone Call function.
- Page 5 For iOS Ａｆｔｅｒ ｔｈｅ ｗａｔｃｈ ｉｓ ｃｏｎｎｅｃｔｅｄ， ｔｈｅ ｐｒｏｍｐｔ ｆｏｒ ｐａｉｒｉｎｇ ｗｉｔｈ ｔｈｅ ｍｏｂｉｌｅ ｐｈｏｎｅ ｗｉｌｌ ｐｏｐ ｕｐ ｆｏｒ ｔｈｅ ｆｉｒｓｔ ｔｉｍｅ ａｆｔｅｒ ３ ｓｅｃｏｎｄｓ， ａｎｄ ｔｈｅ ｐｒｏｍｐｔ ｆｏｒ ｃｏｎｎｅｃｔｉｎｇ ｔｈｅ ｐｈｏｎｅ ａｎｄ ｐｕｓｈｉｎｇ ｉｎｆｏｒｍａｔｉｏｎ ｗｉｌｌ ｐｏｐ ｕｐ ｆｏｒ ｔｈｅ ｓｅｃｏｎｄ ｔｉｍｅ ａｆｔｅｒ ３ ｓｅｃｏｎｄｓ It shall show Connected...
- Page 6 For Android Accept the Bluetooth Pairing Request Once accepted you can see the following screens saying - "Connected for calls & audio"...
- Page 7 Step 2: Go to the watch and press the home button to view the menu to see calls option After successfully connecting the bluetooth you will get this screen. Upon clicking on the call record you can see the recent calls of your device When you click on the dial pad you shall get this screen on your watch.
- Page 8 You click the dial button, you can see that the number is dialling Through the microphone available in the watch you can talk through the watch and adjust the speaker volume by the + & - sign on the watch and disconnect the call. Part B - How to disconnec To disconnect the bluetooth calling the user simply has to go to the phone's bluetooth setting and "unpair"...
- Page 9 Part C - Add contact You can add upto 8 contacts - Add the contacts from the Da Fit App. Go to "Frequent Contacts" and add contacts. The selected contacts will get synced to your watch. Click on Favorite Contact to add the contacts Select the contacts you The contacts will get added.
- Page 10 Part D - Switch between Phone / Watch Switch Between Watch / Phone During an Active Call : If your watch is connected to the Phone via Bluetooth, all calls will come on the watch by default. If you want to change the call to the phone, during an active call, simply click on Handset earpiece icon to select it.
- Page 11 Part E - Battery Advisory Battery The battery lasts for 3 to 5 days with bluetooth calling mode enabled. If the bluetooth calling mode is disabled then the battery can last for 7 days. On standby the battery can stay for as long as 20 days. Advisory- To conserve battery, It is advised to turn off the bluetooth when not in use.
-
Page 12: Functions Navigation
Functions Navigation The screen can be navigated by sliding left/right or sliding up/down Control Center Swipe Swipe Down Swipe Swipe Left Left Swipe Swipe Right Right Shortcut Menu Feature Pages Swipe Swipe Down Messages... - Page 13 Watch Face Functions Navigation and Button Instructions The watch features a full touch control screen with a reflective display and two buttons Functions Navigation The screen can be navigated by sliding left/right or sliding up/down By default, the watch face page displays, and on the watch face page, you can: Slide down to view control centre.
- Page 14 Slide right to view shortcut menu, which allows you to go to any function with a single click. a) Slide left to view Activity, Sleep, Heart Rate, SpO2, Weather, Add component...
- Page 15 Touch Button Operations Short press from the side button To unlock the screen in the lock screen status To return to the watch face page from the first-level menu entry in the unlocked status Long press from the side button To turn on the watch in the power off status Watch Wearing and Charging...
-
Page 16: Use Of Functions
Charging Plug the charger's USB port into a mobile phone charger or a computer USB port to charge the watch. This is a wireless charging USB simply place the watch on the port The charging icon will appear on the screen, indicating that the watch is being charged. - Page 17 Steps - The watch automatically tracks the step taken on the screen. Note: Your movement stats reset to 0 at midnight. Sleep - You need to wear the watch while sleeping, it will provide the hours slept and quality of sleep stats. Note: Sleep Detection starts from 8pm to 10 am the next day Alarm - You can set alarms on the watch as per your need and the watch will vibrate, you can set the day as well...
- Page 18 Activity - This feature comprises of 100+ exercise modes. Track your fitness goals in a tap. You can view the following activities: Running, Walking, Cycling, Skipping, Football, Basketball, Badminton, Cricket, Kabbadi etc Messages - This feature allows you to view your notifications and other messages...
- Page 19 Heart Rate - The watch will record your heart rate all day. You can also tap on the page to start measuring AI - Click the icon to wake up the phone smart assistant, and you can control the smartphone smart assistant through the watch voice.
- Page 20 Phone - The watch supports bluetooth calling i.e it enables you to make calls from the watch and even talk through the watch Timer - Set realistic goals and put on a timer to track it within its limit. Female - You can track your menstrual cycle on the watch itself...
- Page 21 Weather - You can know the current weather and the forecast for next 5 days, this information is synced from your app. Scroll Up to see the forecast weather. It will not be updated if the phone is disconnected for a long time. Shutter - You can remote control the camera of your phone once the watch is connected with your device.
- Page 22 Stopwatch - You can use the stopwatch to track any activity you are doing Flashlight - Use this feature when in darkness, it will flash the light from the watch screen. Find Phone- Use this feature to find the mobile phone when connected with app via bluetooth.
- Page 23 Setting - Check out other features through this tab.
-
Page 24: Other Settings
Other Settings Watch Face Replace the Watch Face on the Watch Long Press the screen, you shall get the options to change the watch face, scroll left and click on the watch face you want to select. The watch face will set. Replace the Watch Face on the App: Tap the Watch face settings entry in the "Device"... - Page 25 Notifications Enable Notifications During use, you need to enable the corresponding "App alerts" on the Da Fit App, and keep the watch and the mobile phone connected. If you are using an iOS device, you need to pair the watch with the Bluetooth of the mobile phone before use.
- Page 26 Weather In the weather page, you can view the weather for the day and the weather information for the next 5 days. You can change location in the app. The weather displayed by the watch comes from the server. Therefore, you need to keep the Bluetooth of your mobile phone on and connect it with the watch to keep abreast of the latest weather information changes.
- Page 27 No Disturb: This puts the watch to DND mode, there will be no notifications Low Power Mode: This will dim the brightness and shut the vibration Phone: This function will tell you if the phone connection is on Phone Reset: This will reset the bluetooth calling function System: This feature will show you options to reset, restart and shut down the device...
- Page 28 Watch Status Reminder Incoming Call When the watch receives incoming calls in no bluetooth calling mode, it will vibrate to remind you, also you can silent or reject the call. Idle alerts When you are sitting for a long time, the watch will vibrate to remind you to get up for a while.
- Page 29 Introduction to the Training Function Start Workouts There two approaches to starting a workout: Select a workout type in the Activity entry and enable it; Short Press the functions button to enable GPS exercise...
