Summary of Contents for Fire Boltt BSW114

  • Page 1 BSW114 Smart Watch User Manual...
  • Page 3 Downloading and connecting of smart watch with Da Fit APP 1.Download and install Da Fit APP. 2.Scan QR code with mobile phone to down- load APP. 3.For IOS system, select APP Store,search for Da Fit App. Android system, select Google Play to down- load and install Da Fit App.
  • Page 4 Download APP Download Da Fit From Watch QR APP in Smartphone Code or UM Open Da Fit APP Connect smart watch with Da Fit APP Fulfill your data when first Click “To ADD” to search use Da Fit App...
  • Page 5 Click on your device in the Successfully connected Device List with APP If watch is connected with APP successfully, the Bluetooth icon in control center is displayed...
  • Page 6 How to connect Step 1: As BSW114 smartwatch is a single chipset smart watch,so you only need to connect smart watch with APP.Then the watch will connect with phone bluetooth automatically.Then you can use...
  • Page 7 Please check the following steps for iOS and Andr- oid based on the system of your phone. For iOS After connecting with APP, it will remind you to connect phone BT call function by connecting mobile phone bluetooth in phone setting menu.
  • Page 8 Please check your iOS After connecting with iOS bluetooth setting list to bluetooth,it will show search and connect “Audio-FireBoltt 114” in “Audio-FireBoltt 114” “MY DEVICE” list After connecting with APP, APP will show a “Bluetooth Pairing Request”,you just need to click to “Pair”...
  • Page 9 After confirming to pair with phone bluetooth,APP will ask “Allow FireBoltt 114 to Receive Your iPhone Notification”,please click to allow After successfully connecting with phone bluetooth,the watch Phone Call interface will display as above If you can not connect with phone bluetooth, please check as below: Checking the setting Then try to connect...

  • Page 10: For Android

    For Android After connecting watch with Da Fit APP,it will ask you to “Allow access to your contacts and call history”,please allow to pair Step 2: Go back to watch and enter Phone Call interface to make phone calls,check records and contacts.
  • Page 11 Phone Call Interface Part A - Making Bluetooth Phone Calls Tap “Dial pad” icon to enter into Dial pad. Then you can make bluetooth phone calls via smartwatch.
  • Page 12 Part B - Add Frequent Contacts Click “My device” in Da Fit APP to check device settings of smart watch,then tap “Frequent Cont- acts” to add frequent contacts from phone cont- acts to watch.
  • Page 13 Part C - Check and Sync Recent Calls Tap Recent Call from Bluetooth Calling inter- face to check recent calls. Part D - Switch Calls between Phone or Watch Switch Between Watch or Phone during an active call: If your watch is connected to the Phone via Blue- tooth,all calls will come on the watch by default.
  • Page 14 Part E - How to Disconnect If you want to disconnect watch with APP and Phone Bluetooth.You could turn off your phone bluetooth function directly. Or,you can enter into Setting Center,then tap “Phone Call” icon to turn off.
  • Page 16 Charge The Battery And Battery Advisory BSW114 charger is a 2-pin magnetic charger. If you need to charge smartwatch,you can just put the 2-pin charger on the charging port of the smart watch. There is a heart rate sensor protector on the sensor,you...
  • Page 17 It takes about 2 hours to 2.5 hours to fully charge the battery.For first using,please charge the battery for 2.5 hours before using. The battery lifetime depends on your usage of the smartwatch.The below lifetime is only for your reference. General standby time is 25 Days(Not with Screen Always-on function).

  • Page 18: Functions Navigation

    Functions Navigation The screen can be navigated by swiping left/right or swiping up/down. Control Center Swipe Down Swipe Up Swipe Swipe Left Left Swipe Swipe Right Right Menu List Main Interface Basic Function Interface Swipe Down Swipe Up Message Part A - Control Center Swipe down to view watch control center.
  • Page 19 ● Do Not Disturb Mode ● Brightness ● Timer ● Shutter ● Flash Light ● Settings Do Not Disturb Mode: If open DND Mode,Call, Notifications and Alarm will be silent. Brightness Setting: Adjust the brightness of the screen. Timer: You can use Timer function here directly. Shutter: You can use Shutter function here directly.
  • Page 20 Part C - Menu List Swipe right to enter into Menu List Interface.You can check all watch functions here,such as Activ- ity,Phone Call,Sleep,Heart Rate,SPO2,Exercise, Weather,Messages,Shutter,Timer,Relex,Alarm, Player,Stopwatch,Flashlight,Find Phone,Games, AI Voice,Setting. Part D - Basic Function Interface Swipe left or right to enter into basic functions interface.
  • Page 21 Button Functions and Wearing Part A - Side Button BSW114 is with one button. One Buttons functions are as following: 1.Turn on and Turn off Button-To turn on and turn off smart watch. 2.Light up Button-To light upthe smart watch display.
  • Page 22 Part B - Watch Wearing For accurate testing data,we recommend to wear the watch with a moderate tightness at a gap of two fingers from your wrist to ensure that the sensor can work properly. Please do not wear too loose when using the heart rate monitoring and Spo2 functions.
  • Page 23 Functions Part A - Main Interface Functions Bluetooth Phone Call - After watch connecting with APP and phone Bluetooth.You can make or receive phone calls,check call records, check contacts.
  • Page 24 Steps - You can check your activity data including steps data,calories data.7 days data will be rema- ined.And swipe up to check more data. Sleep Monitoring - You need to wear the watch while sleeping.It will provide the hours slept and quality of sleep stats.Swipe up to check more data.
  • Page 25 Heart Rate Monitoring - The watch will record your heart rate all day. You can also tap on the page to start measuring.24 hours data will be remain- ed.Swipe up to check more data. Spo2 Monitoring - The watch can test your Spo2 date.You can also tap on the page to start measur- ing.7 latest values will be remained.Swipe up to check more data.
  • Page 26 Music Player - BSW114 smart watch supports mobile music player.The watch will play the phone music after you connect the watch with APP and phone bluetooth.(Please note,the wa- tch must be both connected with APP and ph- one Bluetooth). Voice Assistant - Tap “Click” to use phone Voice Assistant.Please ensure the watch is connecting...
  • Page 27 Add Menu Interface - At this interface,you can tap “+” icon to add other functions to main function interface.And long press the main function interface to remove the menu from the main function interface. Part B - Other Functions You can add other main functions to the main function interfaces.The main functions includes: Breathing,Stopclock,Alarm,Shutter,Exercise Record,Flashlight,Calculator,Period,Timer,...
  • Page 28 Shutter - After watch connecting with APP.Tap the shutter icon to remote control the camera of your phone to take photos. Timer - This sets a preset timer for the user to track and given time line. Relax - Enter into breathing to take breath- ing and relax.
  • Page 29 Alarm - Set alarms and let your watch vibrate to remind you of the alarm. Stopwatch - This helps to track the time frame for any given activity. Flashlight - Never be scared in the dark again. The watch supports a flashlight.
  • Page 30 Find Phone - The watch will help you find your sm- art phone.Please note,the smart watch must be connected with Da Fit APP,when you use this function. Period - If you set Lady Period on Da Fit APP,watch will remind you based on what you set via Da Fit APP.
  • Page 31 Settings - Swipe down from main interface to enter into Control Center and tap “Setting” icon to enter into setting list to set the watch system. Display Setting Tap “Display” to enter and set display.Set Auto Sleep time,Menu View,Brightness,Watch Face. Call Alert Setting Tap “Call Alert”...
  • Page 32 DND Mode Setting Tap “DND” to open or close Low Do Not Disturb Mode. Low Power Mode Setting If you tap to turn on the Low Power Mode,the brightness will dim,and vibration and view will shut. Phone Mode Setting Tap “Phone” to open or close bluetooth phone call function.
  • Page 33 About Tap “About” to check watch version and QR Code. Part C - Featured Functions Watch Face - There are 10 in-built watch faces, you can download watch face from Da Fit APP, and you can DIY the watch face via Da APP as well.
  • Page 34 You can download watch face and do DIY watch face via Da Fit APP Dial setting.
  • Page 35 Exercise - Swipe right to enter into Hot key,then tap Sports Mode icon to enter into sports mode interface.There are more 110 sports modes for your exercise selections.
  • Page 36 You can add any sport mode to Popular Sports for quick view. You can select any of the sports modes to start your exercise.
  • Page 37 Games - There are 4 in-built games,you could enjoy the happy time when take rest.
  • Page 38 Watch Reminders Sedentary Reminder If you set Sedentary function on Da Fit APP,watch will remind you to move if you have not moved up for a long time. Drink Water Reminder If you set Drink Water Reminder function on Da Fit APP,watch will remind you to drink water based on what you set via Da Fit APP.
  • Page 39 Wearing Reminder Watch will remind to wear the watch well,when you do testings. Gold Achieved Reminder Watch will remind you the goal you set via Da Fit APP has been finished.
  • Page 40 Low power and charging reminder If the watch runs out of power,it will remind you to charge.And when you charge the watch,the watch will display charging icon.
