ENVIO Luna Series Manual

Luna Series | IESS-DFM110SF800
IESS-DFM110SF800
8MP 4K UHD Dome Network Camera
TECHNICAL SPECIFICATIONS
CAMERA
Image Sensor 1/2.7" Cmos Sensor
Max. Resolution 8 MP / 3840 (H) × 2160 (V)
Electronic Shutter Speed 1/50(1/60)s to 1/10.000s
Min. Illumination 0.0001Lux@F1.2
Illumination 36 IR Led / 30 m
Illuminator On/Off Control Auto/Manual
PTZ -
LENS
Lens Type Fixed focal
Focal Length/Angle of View 3.6 mm / 80°
Iris Control -
VIDEO
Main stream: 8MP 3840*2160@15fps, 5MP
2880*1616@25fps, 4MP 2560*1440@25fps,
Video Frame Rate
2MP 1920*1080@25fps
sub-stream: 800*448@25fps;
Smart Function Video Analysis
Illumination Mode IR Mode
Smart Codec H.264 / H.265 / H.265+
AUDIO
Built-in MIC -
Two-way audio -
Audio Compression -
ALARM
Alarm -
NETWORK
Network Interface 1*RJ45 10/100M adaptive Ethernet port
IPv4, https, TCP/IP, FTP, NTP, RTSP, UDP,
Protocol
SMTP, DNS, DDNS
ONVIF Yes
P2P XMEye - XMEye Pro
IE Browser Edge, Chrome, Firefox
WiFi/SD-Card - / -
POWER
Power Supply/Consumption 12V DC/PoE (802.3af) / < 5W
STRUCTURE
Material/Protection Metal / IP65
Dimensions/Weight Ø140mm x 125mm / 1.0 kg
1 Warnings & Precautions
ear Customer, we thank you for choosing one of our products whose correct use guarantees solutions of the
highest quality and reliability over time. This manual provides instructions for using the product.
2 Connections
Connect the camera to the router and plug in the power cable (12V at least 1A). You can also power the cam
with POE (IEEE.802.3af)
3 Installation
The bullet cameras are equipped with an integrated bracket for wall mounting, specially designed to allow the
passage of cables inside it and protect them from tampering attempts. The camera is generally mounted at
the cable outlet so as not to leave exposed cables. However, the fixing base also has a lateral cable outlet slot
if the cables come from the side in the external duct. The bracket must be fixed to the wall or ceiling with the
plugs provided
Main Features
8MP 1/2" Cmos Sensor (3840x2160)
ONVIF 2.4
3.6 mm Fixed Lens
Max distance IR Led 30m
Video Analysis
36 IR LED
IP65
PoE IEEE802.3af / DC12V
4 Framing adjustment
Once fixed correctly to the wall / ceiling, point it in the desired direction and lock it (may vary from model to
model) by tightening the screws with the Allen key provided. Fixed lens cameras do not require focusing as
they are factory set for most applications. To ensure optimum image quality, do not install the camera too
close to strong light sources or in places subject to light reflections that could compromise the correct view of
the camera.
5 Configuration
Connect the camera to the router and plug in the power cable (12V at least 1A). You can power the camera in
POE (IEEE.802.3af), if the camera model is equipped with POE.
Download the "Device Manager" software from the website www.enviosecurity.com and install it on the PC.
Once the software is open, press the "IP Search" button (1). Select the IP address shown by the software (2),
and modify the IP address of the camera (3), taking care to enter an IP address with the same subnet as your
router, enter the relevant network mask and IP address of the gateway.
Finally, press the "Modify" button (4) to save the settings. The software will show a "successful change"
message.
Open Internet Explorer (we suggest using I.E. starting from version 10)
Set up ActiveX controls before accessing the camera (Go to Internet option, select
Security tab, select custom level and configure the ActiveX control settings as shown in the figure.
In the Internet Explorer address bar, enter the IP address of the camera http://192.168.1.10
Select "Allow", when Internet Explorer asks for permission to install ActiveX controls
Enter your login credentials:
user: admin
password: (no password)
For the full manual visit www.enviosecurity.com
Web: www.enviosecurity.com
EN
