THULI TABLES

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 2
Identification of Parts . . . . . . . . . . . . . . . 3 - 4
Headpiece Operation . . . . . . . . . . . . . . . . 5 - 8
500 Owner's Manual
office@ thulita b les.co m
youtube.com/thulit ables
facebook.com/thu litab les
Table Operation . . . . . . . . . . . . . . . . . . . 9 - 11
Care & Maintenance . . . . . . . . . . . . . . . 12-13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 14
800-458-4854
www.thulitables.com
Videos & Manuals
Crescent Arm Rest
(optional)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thuli Tables 500

Summary of Contents for Thuli Tables 500

  • Page 1: Table Of Contents

    THULI TABLES youtube.com/thulit ables facebook.com/thu litab les 500 Owner’s Manual Videos & Manuals Crescent Arm Rest (optional) Table of Contents Introduction ......2 Table Operation .

  • Page 2: Introduction

    Introduction Thank you for your purchase of a 500 Stationary table. We are pleased to provide you with an adjusting table that is versatile, extremely durable and skillfully designed. It has been thoroughly inspected and tested right down to the smallest detail before leaving our shop.

  • Page 3: Identification Of Parts

    Identification of Parts Fixed Section Ankle Rest Pelvic Section Thoracic Section Extension / Elevation Pelvic Thoracic Tension Control Tension Control Headpiece Ankle Rest Locking Knob Pelvic Lowering Lever Crescent Arm Rest (optional) Thoracic Lowering Foot Cocking Pedal Lever...
  • Page 4 Identification of Headpiece Parts Tension Control Knob (other side) Paper Tear-Off Bar Paper Hold-Down Wire Straight Drop / Forward Pivot Block Motion Knob Cocking Lever Slide Block T-Bar Paper Hanger Remote Control Lever Piston Pin Locking Link Adjustable Buckle for Remote Control Cable Prone Arm Rest Flexion / Extension...

  • Page 5: Headpiece Operation

    Headpiece Operation HEADPIECE PAPER 1. Attach a 8.5” roll of paper. 4. To advance the headpiece paper, 5. To tear off used headpiece paper, 2. Raise the paper hold-down wire raise the tear-off bar, hold your use an upward motion while holding and tear-off bar.
  • Page 6 Headpiece Operation VERTICAL ELEVATION 1. Raise the back end of the headpiece 2. Raise the front end of the headpiece 3. With practice, steps 1 and 2 can be by lifting it up. by operating the remote control combined to vertically raise the lever.
  • Page 7 Headpiece Operation LATERAL FLEXION LEVER FLEXION / EXTENSION LATERAL FLEXION For lateral motion, lift the lateral flexion The position of the lateral flexion lever Flex and extend the headpiece by grasping the front end of the head- lever in a counterclockwise direction, can be changed.
  • Page 8 Headpiece Drops STRAIGHT DROP FORWARD MOTION DROP Knob pulled out PRIOR to cocking Knob pushed in PRIOR to cocking PRIOR to cocking the headpiece, set for straight drop PRIOR to cocking the headpiece, set for forward by pulling out the headpiece straight drop/forward motion drop by pushing in the headpiece straight motion knob until you feel it is “set”...
  • Page 9 Table Operation PELVIC DROP THORACIC DROP The pelivc section both elevates and drops. The drop When using the thoracic drop, position the patient suf- ficiently forward with their arms outstretched and can be used in any elevated position. However, there is wrists resting on the prone arm rest.
  • Page 10 Table Operation THORACIC SECTION: RAISING & LOWERING The front end of the thoracic section can be raised to a height of 0”- 9 1/2” from horizontal (0 - 30 degrees), and is intended to be used with the patient in the supine position only. LOWERING the thoracic section: RAISING the thoracic section: Ask your patient to assist you 1.
  • Page 11 Table Operation PELVIC SECTION: RAISING & LOWERING The front end of the pelvic section can be raised to a height of 0”- 6 1/2” from horizontal (0 - 22 degrees), and is intended to be used with the patient in the prone position only. RAISING the pelvic section: Use only when the patient LOWERING the pelvic section: Ask your patient to briefly is in the prone position Ask the patient to assist you by...

  • Page 12: Care & Maintenance

    3. Lubricate with 3-IN-ONE oil: Apply oil into the hole. Allow a few minutes for the oil to penetrate before using. Lubricate every month or 500 adjustments. THORACIC & PELVIC DROPS: SYRINGE USE To access the thoracic and pelvic plungers, use a small syringe (provided).
  • Page 13 3. Water Rinse: It is important to follow any cleaning with a thorough, clear water rinse to minimize premature deterioration of the vinyl from extended exposure to chemicals. VINYL REPLACEMENT In the event of wear or damage, pre-sewn replacement vinyl is available from Thuli Tables.

  • Page 14: Warranty

    Warranty WARRANTY Our tables are designed and built to high standards. We are proud to offer a limited lifetime warranty against manufacturing defects, with the exception of the headpiece piston and the motor (on elevation tables), which are covered by a one year warranty. This warranty is valid to the original owner if the table has not been altered in any way.
