THULI TABLES
Owner's Manual

Table of Contents

Introduction & Warranty . . . . . . . . . . . . . . . 2
Identification of Parts . . . . . . . . . . . . . . 3 - 5
Table Set-Up . . . . . . . . . . . . . . . . . . . . . . 6 - 8
Heapiece Operation . . . . . . . . . . . . . . . 9 - 12
Table Operation . . . . . . . . . . . . . . . . . 12 - 14
Table Fold-Down . . . . . . . . . . . . . . . . . . . 15
office@ thulitab les.co m
youtube.com/thulit ables
facebook.com/thu litab les
The Junior Portable
Accessories . . . . . . . . . . . . . . . . . . . . 16 - 17
Care & Maintenance . . . . . . . . . . . . . . . . . . 18
Office Art . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Overview of Products . . . . . . . . . . . . . Back
800-458-4854
www.thulitables.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the The Junior Portable and is the answer not in the manual?

Questions and answers

Related Manuals for Thuli Tables The Junior Portable

Summary of Contents for Thuli Tables The Junior Portable

  • Page 1: Table Of Contents

    Owner's Manual The Junior Portable Table of Contents Introduction & Warranty ....2 Accessories ....16 - 17 Identification of Parts .

  • Page 2: Introduction & Warranty

    Our products are covered by a one year warranty, which includes any defect in workmanship, function and materials under normal wear and tear conditions. If you have any questions or comments, please contact us. We look forward to speaking with you! Sincerely, Rick Thuli, D.C. President Dodgeville Wisconsin USA Thuli Tables...
  • Page 3 Identification of Table Parts Ankle Rest Pelvic Section Extension Thoracic Section Ankle Rest Locking Knob Note: Place weights over the back leg crossbrace Prone Arm Rest for counterbalance. (adjustable) Pelvic Cocking Lever & Tension Control Piston Folding Support Brace Thoracic Cocking Lever (Left) &...
  • Page 4 Identification of Table Parts in Folded Position Folding Support Brace Remote Control Headpiece Paper Ankle Rest Thoracic Cocking Bar Thoracic Cocking Bar Thoracic Cocking Bar Extension Paper Tear-Off Bar Thoracic Cocking Bar Pelvic Cocking Bar Piston Ankle Rest Thoracic Front Legs Extension Slant Bar Remote Control...

  • Page 5: Identification Of Parts

    Identification of Headpiece Parts Tension Control Knob (not visible) Paper Hold-Down Wire Paper Tear-Off Bar Pivot Block Straight Drop/ Pivot Pin Forward Motion Knob Base Block Cocking Lever Paper Hanger T-Bar Remote Control Lever Piston Pin Piston Head Lowering Lever Adjustable Buckle for Prone Arm Rest Pin to close table &...
  • Page 6 Table Set-Up REMOVE ANKLE REST EXTENSION INSTALL ANKLE REST EXTENSION Lay the table onto its cushions. Remove the ankle rest Insert the ankle rest rods into their brackets and tighten down extension from its storage postion by slightly raising the with the locking knob (on the side of the table).
  • Page 7 Table Set-Up HEADPIECE ATTACHMENT (cont.) FRONT LEG SET-UP 5. Before raising the front legs from their folded position, 1. Raise the front legs from their folded position by grasping disengage the piston head from its locked position. Squeeze the horizontal crosspiece. the remote control lever and retract the piston head from the hole in the frame.
  • Page 8 Table Set-Up REMOTE CONTROL LEVER ATTACHMENT PISTON ATTACHMENT 1. Swing the headpiece flexion/extension piston down toward the Install the black remote control lever into the bottom of the off-centered slot in the headpiece base block. base block by inserting the cable into the narrow slot and tilt 2.
  • Page 9 Table Set-Up & Headpiece Operation CORRECT TABLE POSITIONING BEFORE SETTING UPRIGHT SET THE TABLE UPRIGHT: Tilt the table away from you and onto its feet. HEADPIECE PAPER 1. Install a standard 8.5" roll of headpiece 4. To advance the headpiece paper, raise 5.

  • Page 10: Heapiece Operation

    Headpiece Operation FLEXION AND EXTENSION Flex and extend the headpiece by grasping the front end of the headpiece and operating the remote control lever on the underside of the headpiece with your fingertips. VERTICAL ELEVATION 2. Raise the front end of the headpiece by 3.
  • Page 11 Please note that it will not raise up/down or flex/extend when not mounted to the table. Note: A stabilization base for the portable headpiece is available from Thuli Tables to distribute the drop forces over a broader surface. HEADPIECE CUSHION ADJUSTABILITY The headpiece cushions are adjustable in width for patient comfort.
  • Page 12 Headpiece & Table Operation STRAIGHT DROP FORWARD MOTION DROP Knob pulled out BEFORE cocking Knob pushed in BEFORE cocking PRIOR to cocking the headpiece, set for straight drop by pulling PRIOR to cocking the headpiece, set for forward motion drop out the headpiece straight drop/forward motion knob until you by pushing in the headpiece straight drop/forward motion knob.
  • Page 13 Table Operation THORACIC SLANT SECTION If you haven't already done so, release the thoracic section by unfastening the Velcro on the underside of the table. Swing down the metal slant bar and engage the ends into the holes in the leg blocks. Cervical palpation and adjusting (shown on Tour) Anterior thoracic adjusting (shown on Tour) THORACIC DROP...
  • Page 14 Table Operation SIDE POSTURE POSITIONING Side posture support of the patient's head for lumbo-pelvic adjusting or toggle recoil adjusting. ANKLE REST EXTENSION The ankle rest can be extended up to 8" and locked into position by tightening the tension knob on the side of the table.
  • Page 15 Table Fold-Down WHEN FOLDING THE TABLE, REVERSE THE SEQUENCE OF TABLE SET UP. 1. Return the ankle rest extension, drop sections and headpiece to their neutral positions. 2. Tip the table onto its cushions. 3. Fold the back legs down into the table. Be sure to slide the black brace locks completely down to where the braces are riveted to the table frame.

  • Page 16: Accessories

    Accessories PROTECTIVE COVER Provides excellent protection when traveling by car. With the folded table in its upright position, place the cover over the top of the table. Lean the table forward and tuck the flap under the table. Lean the table back and pull the flap from under the table and secure with Velcro.
  • Page 17 The base of the Comfort Pillow quickly inserts into place between the base, allowing for width the headpiece cushions. The width of the opening is adjustable. adjustability. Use with Thuli tables or any other manufacturer’s table! Pillow Base BOLSTERS CARRYING BAG FOR ACCESSORIES 2.75"...

  • Page 18: Care & Maintenance

    “backing out" while using washed frequently. Remove stains immediately to prevent the the drop. possibility of them becoming permanent. In the event of damage, Decrease resistance: Turn the set screw counter-clockwise. pre-sewn replacement upholstery is available from Thuli Tables.

  • Page 19: Office Art

    QUOTATION PLAQUES (set of three) VERY SOPHISTICATED Recognizing the need for distinctive, contemporary graphics for chiropractic offices and reception areas, Thuli Tables has com- missioned two fine sets of plaques. Unmatched in visual appeal and content, these plaques are perfect for your consultation and adjusting rooms.
  • Page 20 youtube.com/thulitables www.thulitables.com Tour Portable Sport Portable 300 Stationary 500 Stationary Lumbo-Pelvic Drop Portable Headpiece Extremity Drop Speeder Board Elevation Tables Portable Drops...
