Installation Manual
Flow logic IV
DC Inv erter R410A
Multilingual Manual
(English -
FRANÇAIS
VVTA-250R-01T32
VVTA-280R-01T32
VVTA-335R-01T32
VVTA-400R-01T32
VVTA-450R-01T32
VVTA-504R-01T32
VVTA-560R-01T32
VVTA-615R-01T32
VVTA-680R-01T32
VVTA-735R-01T32
IMPORTANT NOTE:
Read this manual carefully before installing or operating your new air conditioning unit. Make sure to
save this manual for future reference.
23.AW.VVTA.250-735.R410A.IM.EN.FR.DE.IT.SP.POR.07.17
- Deutsch - Italiano - Español - Português )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VVTA-250R-01T32 and is the answer not in the manual?

Questions and answers

Related Manuals for Airwell VVTA-250R-01T32

Summary of Contents for Airwell VVTA-250R-01T32

  • Page 1 Installation Manual Flow logic IV DC Inv erter R410A Multilingual Manual (English - - Deutsch - Italiano - Español - Português ) FRANÇAIS VVTA-250R-01T32 VVTA-280R-01T32 VVTA-335R-01T32 VVTA-400R-01T32 VVTA-450R-01T32 VVTA-504R-01T32 VVTA-560R-01T32 VVTA-615R-01T32 VVTA-680R-01T32 VVTA-735R-01T32 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
  • Page 3 EUROPEAN REGULATIONS CONFORMITY FOR THE MODELS: DISPOSAL REQUIREMENTS: All the products are in conformity with the following European Your air conditioning product is marked with provision: this symbol. This means that electrical and - Low Voltage Directive electronic products shall not be mixed with - Electromagnetic CompatibilitY unsorted household waste.
  • Page 4 ÜBEREINSTIMMUNG MIT DEN EUROPÄISCHEN RICHTLINIEN FÜR DIE MODELLE: HINWEISE ZUR ENTSORGUNG: Alle Produkte erfüllen die folgenden europäischen Richtlinien: Das Klimagerät ist mit diesem Symbol - Niederspannungsrichtlinie gekennzeichnet, das darauf hinweist, dass - EMV-Richtlinie Elektro- und Elektronikgeräte getrennt vom Hausmüll entsorgt werden müssen. Verschrotten Sie die Anlage nicht selbst: die Verschrottung von Klimaanlagen, sowie die Rückgewinnung des Kältemittels, des Öls und aller sonstigen Teile...
  • Page 5 Contains fluorinated greenhouse gases covered by the Kyoto Protocol IMPORTANT INFORMATION REGARDING THE REFRIGERANT USED This product contains fluorinated greenhouse gases covered by The filled out label must be adhered in the proximity of the product the Kyoto Protocol. Do not vent into the atmosphere. charging port (e.g.
  • Page 6 Contains fluorinated greenhouse gases covered by the Kyoto Protocol WICHTIGE INFORMATIONEN HINSICHTLICH DES VERWENDETEN KÄLTEMITTELS Dieses Produkt enthält fluorierte Treibhausgase, die durch das Das ausgefüllte Etikett muss in der Nähe der Kältemittel-Einfüllöffnung Kyoto-Proto-koll abgedeckt werden. Lassen Sie Gase nicht in die angehängt werden (z.
  • Page 7 Installation Manual Flow logic IV DC Inve rte r R41 0A English Manual VVTA-250R-01T32 VVTA-280R-01T32 VVTA-335R-01T32 VVTA-400R-01T32 VVTA-450R-01T32 VVTA-504R-01T32 VVTA-560R-01T32 VVTA-615R-01T32 VVTA-680R-01T32 VVTA-735R-01T32 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.

  • Page 8: Table Of Contents

    User Manual Contents Safety ....................................1 Installation instruction ................................3 Installation procedure ..............................13 Electric wiring and the application ...........................23 Electric wiring and the application ...........................24 Failure code ..................................35 Trial operation and the performance ..........................40 Move and scrap the air conditioning ..........................41 F l o w l o g i c I V adopts "simultaneous control" type, all indoors Operating Range of Air Conditioner should be heating or cooling simultaneously.

  • Page 9: Safety

    Safety • If the air conditioner is transferred to the others, this manual should be tranferred together. • Before installation, please read "Safety precaution" carefully to confirm the correct installation. • The mentioned precaustion includes " WARNING" and " CAUTION". The precausion caused death or heavy injury for faulty installation will be listed in "...
  • Page 10 Safety CAUTION • Execute earthing for the unit. But the earthing wire can not be connected to the gas pipe, water pipe, lightening rod or the telephone earthing wire. Improper earthing will cause electric shock. • Don't install the unit at the place where leaks the flammable gas. Or it will cause fire. •...

  • Page 11: Installation Instruction

    Installation instruction In installation, please check specially the below items: • If the connected units quantity and the total capacity is in the allowable range? • If the refrigerant pipe length is in the limited range? • If the pipe size is proper? And if the pipe is installed horizontally? •...
  • Page 12 Installation instruction Indoor Combined The most Allow the most Gather pipe capacity Capacity recommended Total indoor Combination Type connected range indoor unit capacity(100W) indoor units number 162400 combination(18+20+20) 812~2111 168000 combination(20+20+20) 840~2184 173500 combination(20+20+22) 868~2256 179000 combination(20+22+22) 895~2327 184500 combination(22+22+22) 922~2398 191000 combination(22+22+24)
  • Page 13 Installation instruction The unit should be installed at the • • The unit is better not be installed place where the cold/hot air or at the below places, or it will cause noise will not interfere the neighbours. • The place where no other heat damage.
  • Page 14 Installation instruction Outline and installation dimensions Fixed hole distance VVTA-250~450R-01T32 800mm Drain hole 980mm 750mm 70mm Exhaust duct connection position Power line outlet (According to the choice of the power line diameter size. The export, use the attached wire into the sheath) Signal line and Line protection Signal wire hole diameter...
  • Page 15 Installation instruction Outdoor unit installation Standard accessories Please check the attachment is complete, please be sure to use. Graphic Quantity Remarks Place position Installation Accessory bag instruction Rubber Signal line Accessory bag plug protection Power line Sheath Accessory bag protection (8HP)(Ø22.22) 8HP:3 Reducing...
  • Page 16 Installation instruction Combination installation dimensions • There should be no obstacles in 2000mm above the top of outdoor unit; • Obstacles around outdoor should be less than 900mm to the bottom of unit. • When multiple modules are installed, the outdoor should be in ranked as the capacity, the larger capacity is closer to the main pipe of gather pipe.
  • Page 17 Installation instruction ˃300mm ˃200mm ˃300mm ˃1000mm 3. Wall higher than the outdoor condenser Place with air inlet hole Notes: a. Fan speed Vs at air inlet is 1.5m/s or below. b. Air outlet height HD=H-h and below 1m. ˃300mm ˃200mm ˃300mm ˃1000mm External air...
  • Page 18 Installation instruction Place without air inlet hole Notes: a. Set a 500~1000mm bracket. b. Air outlet height HD=H-h and below 1m. ˃300mm ˃300mm ˃200mm ˃1000mm External air duct 4. The outdoor machine installation should consider the impact of seasonal wind, don't let the wind directly into the unit return air, otherwise it will affect the unit defrosting and related functions 5.
  • Page 19 Installation instruction install snow cover Outlet snow cover Snowfall area, please install snow cover, see the right picture,To be unaffected by the snow, it is important to set Inlet snow cover up a high platform, which is calculated according to the maximum amount of snow in the area.
  • Page 20 Installation instruction Install air ducting There are no obstacles in the 2000mm above the outdoor unit; When there are obstacles in the outer plane, there must be a pilot channel, and the wind will be free, the wind will not beshort-circuited, and the external static pressure will be 110Pa.

  • Page 21: Installation Procedure

    19.05 is O-type, the pressure preservation will be bad, thus it must be 1/2H type and over the min. thickness. 3. The branch pipe and the gather pipe must be from Airwell. 4. When installing the stop valve, refer to the relative operation instruction.
  • Page 22 Installation procedure Outdoor Indoor Liquid pipe Gas pipe Liquid pipe Gas pipe Gas pipe Liquid pipe Liquid pipe pipe outdoor gather pipe 1. Pipe "A" diameter (between indoor and branch pipe) (depends on indoor pipe) Indoor (x100W) Gas pipe Liquid pipe 18~28 Ø9.52 Ø6.35...
  • Page 23 Installation procedure 3. Pipe “c” diameter (main pipe, between outdoor gather pipe and the first branch pipe) Main pipe Enlarged main pipe Main pipe Enlarged main pipe Outdoor Outdoor capacity capacity Liquid Liquid Gas pipe Gas pipe Liquid pipe Gas pipe Gas pipe Liquid pipe pipe...
  • Page 24 Installation procedure Allowable piping length and drop between indoor and outdoor 1. Pipe length between outdoors Outdoor outdoor gather pipe 1. L1≤10m; L2≤10m; L3≤10m; L4≤10m; L5≤10m; L6≤10m; L1+L3+L5≤10m. 2. Height difference between outdoors: h≤5m. 3. The piping connecting outdoor unit must be placed horizontally or in accordance with the installation of a certain angle (level angle less than 15 degrees), connected with a concave not allowed.
  • Page 25 Installation procedure Proper installatio Wrong installation Oil return bend The height of the vertical Compressor oil will flow into section see schedule the lowest unit requirements In order to avoid damage to the pipe, the size of the return bend is referred to as the drawing. Pipe diameter Bending radius Vertical heigh...
  • Page 26 Installation procedure Allowable Pipe length and drop (m) For example Remarks value L1+(L2+L3+L4+L5+L6+L9+L25+L13+L15+L16+L18 Total pipe length ≤1000 +L22)x2+…L24 Actual length ≤220 Outdoor to the farthest L1+L2+L3+L6+L8 indoor length Equivalent length ≤260 ≤130 length (main piping) ≤90 L2+L3+L6+L8 unit pipe length The distance between the nearest indoor ≤40 L2+L3+L6+L8-L2-L5-L10...
  • Page 27 Installation procedure Pipe installation Important • Please don't let the pipe and the parts in the unit collide each other. • When connecting the pipes, close the valves fully. • Protect the pipe end against the water, impurity into the pipes (welding after being flat, or being sealed with adhesive tape).
  • Page 28 Installation procedure B. Leakage test 1. The outdoor unit has been executed the leakage test in the factory. The pipe should be executed leakage test individually and forbidden to test after connecting with stop valve. 2. Refer to the below figure to charge the nitrogen into the unit to take a test. Never use the chlorin, oxygen, flammable gas in the leakage test.
  • Page 29 Installation procedure D. Additional refrigerant charging Charge the additional refrigerant as liquid state with the gauge. If the additional refrigerant can not be charged totally when the outdoor stops, charge it at the trial mode. If the unit runs for a long period in the state of lack of refrigerant, compressor will occur failure. ( the charging must be finished within 30 minutes especially when the unit is running, meanwhile charging the refrigerant).
  • Page 30 Installation procedure Heat insulation • HP gas pipe, Suction gas pipe and liquid pipe should be heat insulated separately. • The material for HP gas pipe and Suction gas pipe should endure the high temperature over 120°C. That for liquid pipe should be over 70°C.

  • Page 31: Electric Wiring And The Application

    Circuit Each module Model load current (mA) sectional area of area of earthing source breaker circuit breaker response time(S) power line (mm line (mm 20.3 VVTA-250R-01T32 21.8 VVTA-280R-01T32 23.3 VVTA-335R-01T32 27.7 VVTA-400R-01T32 3N~, 32.4 VVTA-450R-01T32 30mA, below0.1s 380-415V, 36.1 VVTA-504R-01T32 50/60Hz 42.4...

  • Page 32: Electric Wiring And The Application

    Electric wiring and the application 2. If the power cord length is greater than 20m, please increase the cable cross-sectional area, so as to avoid overload caused by the accident. 3. When the voltage drop at the power supply line exceeds 2%, increase the wire diameter appropriately. 4.
  • Page 33 Electric wiring and the application Power line installation instructions Note: When connecting the power cord, please be sure to set aside enough length in the outdoor, which is convenient for turning over the electrical box. When connecting the power cord, please be sure electric appliance box body is lifted up slightly, and the box to set aside enough length in the outdoor, which is body is rotated to the left, and the steel wire rope in the...
  • Page 34 Electric wiring and the application Outdoor 1 Outdoor 2 Outdoor 3 Outdoor 4 IGU11 Indoor 1 Indoor 2 Indoor 3 Indoor 4 Indoor n IGU09 IGU10 IGU10 IGU10 IGU10 Note: If the system unit adopts Zigbee wireless communication,it must adopt wireless and wired hybrid mode. The PQ cable must be connected to the IDU which one with the smallest address number.
  • Page 35 Electric wiring and the application Internal layout of electric appliance box For example Compressor Fan drive drive module module (external or built-in motor) Capacitor plate Filter board Power Communication Main control board Reactance terminal terminal Outdoor dip switch introduction Identification: •...
  • Page 36 Electric wiring and the application ① BM1 introduction begin to search outdoor outdoor searching BM1_1 after startup stop searching outdoor and lock the quantity begin to search indoor indoor searching BM1_2 after startup stop searching indoor and lock the quantity allow(must be electrified for 6 hours) start up after pre- BM1_3...
  • Page 37 Electric wiring and the application ③ BM3 introduction BM3_1 BM3_2 BM3_3 Outdoor BM3_1 The outdoor Normal Outdoor machine model BM3_2 machine is Update use BM3_3 effective Low temperature heating BM3_5 BM3_6 BM3_7 BM3_8 Outdoor horse 10HP 12HP BM3_5 14HP BM3_6 16HP Outdoor horse power BM3_7...
  • Page 38 Electric wiring and the application Outdoor machine digital tube display settings The contents of the display are defined as follows: • Key parts: long press the left START (SW5) control to enter, short press above UP (SW4) data increase, short press down DOWN (SW7) data reduction, long press the right STOP (SW6) control exit •...
  • Page 39 Electric wiring and the application function Digital tube LD1 ~ 4 display (1) press START (SW5) for 2 seconds, to enter the instruction set state, flashing display instructions. Forced indoor mechanism (2) according to UP (SW4) or DOWN (SW7) () adjustment instructions (COOL/ 14（E）...
  • Page 40 Electric wiring and the application function Digital tube LD1 ~ 4 display Outdoor unit LEVa1 open degree 0---470pluse Press START (SW5) for 2 seconds, 1111, enter the Outdoor unit LEVa2 open degree set state: flashing, press UP (SW4) valve fully open, according to DOWN (SW7) 2min after the valve is fully Outdoor unit LEVb open degree closed;...
  • Page 41 Electric wiring and the application function Digital tube LD1 ~ 4 display Outdoor 14（E） 15（F） Frequency converter INV1 module temperature Unit: degree unit address 15（F） 15（F） Frequency converter INV2 module temperature Unit: degree ③ System status display and control (host) function Digital tube LD1 ~ 4 display Refrigerant type...
  • Page 42 Electric wiring and the application Control function Digital tube LD1 ~ 4 display range 0- machine automatic control according to the In the same machine drive group number, all within the machine with 15（F） off control selection 1- drive, 2- all in each machine control, drive off with ban Selection of low temperature 0- within the machine automatic control, 15（F）...

  • Page 43: Failure Code

    Failure code Failure code description: (failure code of the whole system is showed as 8 bits, so totally 256 codes. Indoor failure code should be judged by the table and the unit number) • Outdoor failure code exists in EEPROM, in which 5 failure codes can be kept. •...
  • Page 44 Failure code Digital tube indication Failure code definition Failure description Remarks on master unit Oil temp.too high 27-0 protection Toil ≧ 120℃ continuous 2sec exceeds the set value after Once shutdown alarm; the alarm condition after stopping the oil （Toil1） confirmation temperature below 10 degrees, automatic recovery after 2min50s.
  • Page 45 Failure code Digital tube indication Failure code definition Failure description Remarks on master unit Discharging temp. 43-0 sensor Tdi too low In normal operation,If Td ＜ CT+10℃ for continuous 5 minutes， Once protection the unit stops and alarms.2 minutes and 50 seconds later,resume confirmation Discharging temp.
  • Page 46 Failure code Digital tube indication Failure code definition Failure description Remarks on master unit Module rectifier side software transient overcurrent Module rectifier side current detection circuit anomaly Module hardware overcurrent In the process of starting or running, the rotor position can not Compressor out of step be detected for 6 times in a row, and the INV control board is automatically restored after stopping 5S...
  • Page 47 Failure code In the case of no fault, if the system does not meet the start-up conditions, the host digital display standby code: Indoor machine capacity beyond the outdoor Indoor machine capacity beyond the outdoor 555.0 machine capacity of 150% or less than 50%, machine capacity of 150% or less than 50%, standby standby system system...

  • Page 48: Trial Operation And The Performance

    Trial operation and the performance 5-minute delay function • If starting up the unit after being powered off, the compressor will run about 5 minutes later against being damaged. Cooling/heating operation • Indoor units can be controlled individually, but cannot run in cool and heat mode at the same time. If the cool mode and the heat mode are existing simultaneously, the unit set latter will be standby, and the unit set earlier will run normally.

  • Page 49: Move And Scrap The Air Conditioning

    Trial operation and the performance Trial operation • Before trial operation: Before being electrified, measure the resistor between power terminal block (live wire and neutral wire) and the earthed point with a multimeter, and check if it is over 1MΩ. If not, the unit can not operate. To protect compressor, electrify the outdoor unit for at least 12 hours before the unit runs.If the crankcase heater is not electrified for 6 hours, the compressor will not work.
