- Page 1 FWD Series Indoor Units Outdoor Units AWSI-FWD012-N11 GC 12 RC DCI 230V R410 AW AWSI-FWD018-N11 AWAU-YBD018-H11 AWSI-FWD024-N11 AWAU-YBD024-H11 REFRIGERANT R410A HEAT PUMP SM FWD 1-A.1 GB DECEMBER - 2010 Version:1...
- Page 2 LIST OF EFFECTIVE PAGES LIST OF EFFECTIVE PAGES Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page (when none indicates no changes in the relevant page). All pages in the following list represent effected/ non effected pages divided by chapters.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents INTRODUCTION ..........................1-1 PRODUCT DATA SHEET....................... 2-1 RATING CONDITIONS ........................3-1 OUTLINE DIMENSIONS......................... 4-1 ELECTRICAL DATA........................5-1 WIRING DIAGRAMS ........................6-1 REFRIGERATION DIAGRAMS ...................... 7-1 EXPLODED VIEWS AND SPARE PART LISTS................8-1 SM FWD 1-A.1 GB... -
Page 4: Introduction
INTRODUCTION INTRODUCTION General FWD series split celling mounted range comprise RC (heat pump) models, as follows: AWSI-FWD012-N11// GC 12 RC DCI 230V R410 AW AWSI-FWD018-N11// AWAU-YBD018-H11 AWSI-FWD024-N11// AWAU-YBD024-H11 Main Features The FWD series benefits from the most advanced technological innovations, namely: •... -
Page 5: Product Data Sheet
INTRODUCTION • Easily accessible, and re-usable pre-filters (mesh) Control The microprocessor indoor controller, and an infrared remote control, supplied as standard, provide complete operating function and programming. For further details please refer to the Operation Manual. Outdoor Unit The outdoor units can be installed as floor or wall mounted units by using a wall supporting bracket. - Page 6 INTRODUCTION Matching Table INDOOR UNITS OUTDOOR UNITS AWSI-FWD012-N11 AWSI-FWD018-N11 AWSI-FWD024-N11 √ GC 12 RC DCI 230V R410 AW √ AWAU-YBD018-H11 √ AWAU-YBD024-H11 SM FWD 1-A.1 GB...
-
Page 7: Product Data Sheet
PRODUCT DATA SHEET PRODUCT DATA SHEET AWSI-FWD012-N11// GC 12 RC DCI 230V R410 AW Model Indoor Unit AWSI-FWD012-N11 Model Outdoor Unit GC 12 RC DCI 230V R410 AW Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 11940(5120~13650) 14330(5120~17060) Capacity (4) 3.5(1.5~4.0) - Page 8 PRODUCT DATA SHEET AWSI-FWD018-N11// AWAU-YBD018-H11 Model Indoor Unit AWSI-FWD018-N11 Model Outdoor Unit AWAU-YBD018-H11 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 17000(5120~19790) 19110(4440~23200) Capacity (4) 5.0(1.5~5.8) 5.6(1.3~6.8) Power input (4) 1.51(0.4~2.0) 1.59(0.36~2.0) EER (Cooling) or COP(Heating) (4) 3.31 3.52 Energy efficiency class Extreme cooling capacity(12℃)
- Page 9 PRODUCT DATA SHEET AWSI-FWD024-N11 // AWAU-YBD024-H11 Model Indoor Unit AWSI-FWD024-N11 Model Outdoor Unit AWAU-YBD024-H11 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 23200(5120~25930) 25910(5460~29340) Capacity (4) 6.80(1.50~7.60) 7.60(1.60~8.60) Power input (4) 2.25(0.55~2.70) 2.105(0.45~2.55) EER (Cooling) or COP(Heating) (4) 3.02 3.61 Energy efficiency class...
-
Page 10: Rating Conditions
RATING CONDITIONS RATING CONDITIONS Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units). Cooling: Indoor: C DB 19 C WB Outdoor: 35 C DB Heating: Indoor: C DB Outdoor: 7 C DB 6 C WB Operating Limits R410A Indoor Outdoor... -
Page 11: Outline Dimensions
OUTLINE DIMENSIONS OUTLINE DIMENSIONS FWD012 FWD018/024 SM FWD 1-A.1 GB... - Page 12 OUTLINE DIMENSIONS Outdoor Unit: GC 12 RC DCI 230V R410 AW Outdoor Unit: YBD 018 SM FWD 1-A.1 GB...
- Page 13 OUTLINE DIMENSIONS Outdoor Unit: YBD 024 SM FWD 1-A.1 GB...
-
Page 14: Starting Current A
ELECTRICAL DATA ELECTRICAL DATA Single Phase Units MODEL FWD012 FWD018 FWD024 To indoor To indoor To indoor Power Supply 1PH-230V-50Hz 1PH-230V-50Hz 1PH-230V-50Hz Max Current, A Inrush Current A Starting Current A 10.5 10.5 10.5 Circuit Breaker A Power Supply Wiring 3x1.5 mm 3x2.5 mm 3x2.5 mm... -
Page 15: Wiring Diagrams
WIRING DIAGRAMS WIRING DIAGRAMS Indoor Unit: FWD012/018 SM FWD 1-A.1 GB... - Page 16 WIRING DIAGRAMS Outdoor Unit: GC 12 RC DCI 230V R410 AW SM FWD 1-A.1 GB...
- Page 17 WIRING DIAGRAMS Outdoor Unit: YBD018 SM FWD 1-A.1 GB...
- Page 18 WIRING DIAGRAMS Indoor Unit: FWD024 SM FWD 1-A.1 GB...
- Page 19 WIRING DIAGRAMS Outdoor Unit: YBD024 SM FWD 1-A.1 GB...
-
Page 20: Refrigeration Diagrams
REFRIGERATION DIAGRAMS REFRIGERATION DIAGRAMS Cooling Mode Heating Mode SM FWD 1-A.1 GB... -
Page 21: Exploded Views And Spare Part Lists
EXPLODED VIEWS & SPARE PART LISTS EXPLODED VIEWS AND SPARE PART LISTS Exploded view of Indoor unit: FWD012 SM FWD 1-A.1 GB... - Page 22 HPI FWD 9/12 Motor connective wire 17 465060005 Side Plate / Right /RAL9003AW 18 465160058 Linkage/ Veritcal Flap/RAL9003AW 19 465120035 Air Outlet Frame(Small)/RAL9003AW 20 465720811 Panel Assy./FWD(Wine Cellar)Display/Airwell 21 465160055 Horizonal Flap/Front (Small)/RAL9003AW 21 465160056 Horizonal Flap/Black (Small)/RAL9003AW 22 263034 SWING MOTOR 23 436665...
- Page 23 EXPLODED VIEWS & SPARE PART LISTS Exploded view of Indoor unit: FWD018 SM FWD 1-A.1 GB...
- Page 24 Air Intake Grille Assy.(Big)/RAL9003AW 17 465060005 Side Plate / Right /RAL9003AW 18 465160058 Linkage/ Veritcal Flap/RAL9003AW 19 465120036 Air Outlet Frame (Big)/RAL9003AW 20 465720811 Panel Assy./FWD(Wine Cellar)Display/Airwell 21 465160059 Horizontal Louver/Front (Big)/RAL9003AW 21 465160060 Horizontal Flap/Black (Big)/RAL9003AW 22 263034 SWING MOTOR 23 436665...
- Page 25 EXPLODED VIEWS & SPARE PART LISTS Exploded view of Indoor unit: FWD024 SM FWD 1-A.1 GB...
- Page 26 EXPLODED VIEWS & SPARE PART LISTS Spare part list of Intdoor Unit: FWD024 Part No Description 465800148 Air Intake Grille Assy.(Big)/RAL9003AW 221554 FILTER FWD (BIG) 465060005 Side Plate / Right /RAL9003AW 465020284 Front Panel(Big)/RAL9003AW 465020290 DISPLAY PANEL/RAL9003AW 462350113 Evaporatorassy./FWD 72 DCI 465120036 Air Outlet Frame (Big)/RAL9003AW 285032...
- Page 27 EXPLODED VIEWS & SPARE PART LISTS Exploded view of outdoor unit: GC 12 RC DCI 230V R410 AW SM FWD 1-A.1 GB...
- Page 28 EXPLODED VIEWS & SPARE PART LISTS Spare part list of Outdoor Unit: GC 12 RC DCI 230V R410 AW Part No Description 4522551 Grille A of GCN 4523441 Front panel A Painting assy 4519251 Axial Fan OD=400 Condenser Middle Temperature Sensor/OAT & OMT/DCR LC 467400040 25/35 CTT Compressor Top Temperature Sensor/10K/Resin-...
- Page 29 EXPLODED VIEWS & SPARE PART LISTS Exploded view of outdoor unit: YBD018 SM FWD 1-A.1 GB...
- Page 30 EXPLODED VIEWS & SPARE PART LISTS 8.10 Spare part list of Outdoor Unit: YBD018 Part No Description 1 433218 Front Panel A 2 4526340 Air inlet ring-420 3 433223 Painting Insulation Plate 4 464250118 Fireproofing plate/ONG3 DIC 5 4519251 Axial Fan OD=400 6 466100034R Metal Motor 7 4527203 Motor Support...
- Page 31 EXPLODED VIEWS & SPARE PART LISTS 8.11 Exploded view of outdoor unit: YBD024 SM FWD 1-A.1 GB 8-11...
- Page 32 EXPLODED VIEWS & SPARE PART LISTS 8.12 Spare part list of Outdoor Unit: YBD024 Part No Description 465100000 Outlet grid 4523652 PAINTED LEFT CABINET ASSY 4523758 Nut M8 left 452960400 OUTDOOR FAN 461600002 4-Way Valve Assy. 452956700 4-way valve coil 4526522 Four-Way Valve R410A 452855600...
