- Page 1 Installation Manual MICROWAVE OVEN www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS BEFORE INSTALLATION Electrical Connection � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9 Product Specifications �... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before operation, please read and follow these important instructions for the safety of your home and the people living in it. When using electrical appliances, basic safety precautions should be followed, including the following: • Install or locate this appliance only in accordance with the provided installation instructions. - Page 6 IMPORTANT SAFETY INSTRUCTIONS • If the oven is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the oven and lead to a dangerous situation. • Use this appliance only for its intended use as described in the manual.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • Do not store this appliance outdoors. Do not use this product near water — for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar location. • To reduce the risk of fire inside the oven: •...
- Page 8 IMPORTANT SAFETY INSTRUCTIONS • Liquids such as water, coffee, or tea may be heated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
- Page 9 IMPORTANT SAFETY INSTRUCTIONS • Do not clean with metal scouring pads. Pieces can burn off the pad and touch electrical parts, increasing the risk of electric shock. • Do not use paper products when appliance is operated in the convection or baking mode. •...
- Page 10 IMPORTANT SAFETY INSTRUCTIONS • Using metal, aluminum, or other non-microwave-safe objects with the microwave function can cause sparks. Sparks can irreparably damage the glass on the inside the of the door. • Never pour water inside the hot cooking compartment. This will cause steam.
- Page 11 g and For longer cooking times, you can switch the oven off ■ 10 minutes before the end of the cooking time and use the IMPORTANT SAFETY INSTRUCTIONS residual heat to finish cooking. Environmentally-friendly disposal in the ENVIRONMENTALLY-FRIENDLY DISPOSAL Dispose of packaging in an environmentally-friendly manner. Dispose of packaging in an environmentally- This appliance complies with European Directive 2002/ friendly manner.
-
Page 12: Before Installation
BEFORE INSTALLATION BEFORE INSTALLATION Gather the required tools before starting installation. Read and follow the instructions provided with any tools listed here. TOOLS AND PARTS NEEDED • Phillips-head screwdriver • 1/8” drill bit and drill • Measuring tape PARTS PROVIDED •... -
Page 13: Electrical Connection
BEFORE INSTALLATION ELECTRICAL CONNECTION WARNING ELECTRIC SHOCK HAZARD • Before you plug in an electrical cord or turn on power supply, make sure all controls are in the OFF position. • This appliance must be grounded. Connect only to properly grounded outlet. •... - Page 14 BEFORE INSTALLATION • Only a qualified electrician who takes the appropriate regulations into account may install the socket or replace the connecting cable. If the plug is no longer accessible following installation, an all-pole isolating switch must be present on the installation side with a contact gap of at least 1/8”...
- Page 15 BEFORE INSTALLATION ELECTRICAL REQUIREMENTS • A 3-prong grounded outlet • 120VAC, 60Hz, NEMA 5-20 plug • 20-amp electrical supply with a fuse or a circuit breaker ELECTRIC INSTALLATION • This product must be connected to a supply circuit of the proper voltage and frequency. Wire size must conform to the requirements of the National Electrical Code or the prevailing local code for this rating.
-
Page 16: Product Specifications
BEFORE INSTALLATION PRODUCT SPECIFICATIONS... -
Page 17: Cutout Specifications
BEFORE INSTALLATION ADDITIONAL SPECIFICATION NOTES FOR THE INSTALLER • The diagram on page 12 for the MWO-30 model is not 100% to scale and does not include additional measurements that are unique to the 30” model and are necessary for built-in installation. •... -
Page 18: Installation
INSTALLATION GENERAL CABINET REQUIREMENTS: • 1⁄4" (6 mm) space is required between the side of the appliance and an adjacent wall or cabinet door when installed at the end of a cabinet run. • The cabinet base must be flat and capable of supporting the weight (roughly 90 lbs, 41 kg) of your appliance when in use. - Page 19 INSTALLATION VENTILATED CABINET Flush installation • This appliance is only intended to be fully fitted in a kitchen. This appliance is not designed to be used as a tabletop appliance or inside a cupboard. Flush installation also requires: • The fitted cabinet must not have a back wall behind the appliance. two side cleats to be attached inside the cabinet frame, recessed from the front "...
- Page 20 INSTALLATION BUILT-IN MWO-24 MWO-30 • Carefully push the microwave into the cabinetry, making sure that it is in the center. • Do not kink the electrical cable. • Open the door and fasten the microwave with the screws that were supplied. WARNING: The gap between the worktop and the appliance must not be closed by additional battens.
-
Page 21: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath microwave parts will be warrantied for two years from the original purchase date for the original purchaser of the product. TERMS This warranty applies only to the original purchaser of the product installed for normal residential use. - Page 22 SERVICE For warranty service, please contact our Customer Service team at 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner.
- Page 23 3.8.0 www.zlinekitchen.com 1-614-777-5004 contact@zlinekitchen.com...
