Summary of Contents for Zline RV-2400S
- Page 1 icrowave Installation Guide and Users Manual...
-
Page 4: Table Of Contents
CONTENTS PRODUCT SPECIFICATIONS PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS PARTS AND TOOLS ACCESSORIES INSTALLATION REQUIREMENTS OPERATION EXPERT COOKING GUIDE MAINTENANCE TROUBLESHOOTING... -
Page 5: Product Specifications
Before Calling Service See the Use and Care Manual for troubleshooting PRODUCT SPECIFICATIONS information. Refer to the “Statement of Limited Product Warranty” in the Use and Care Manual. To reach a service representative, see the contact information at the front of the manual or in the Rated Voltage: 120V - 60Hz following section. -
Page 6: Precautions
PRECAUTIONS Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 7: Important Safety Instructions
important safety instructions When using electrical appliances basic safety precautions should be followed, including the following: To reduce the risk of burns, electric shock, fire, personal injury, or exposure to excessive microwave energy, read all instructions before using the appliance. This appliance must be grounded or connected to a properly grounded outlet. - Page 8 important safety instructions When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition. Only use utensils that are suitable for use in microwave ovens. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
- Page 9 important safety instructions Visible bubbling or boiling when the container is removed from the microwave oven is not always present. This could result in very hot liquid suddenly boiling over when the container is disturbed. WARNING Creation of sparks: Metal e.g. a spoon in a glass must be kept at least 2 cm from the oven walls and the inside of the door.
- Page 10 important safety instructions Oversized food or oversized metal utensils should not be inserted in a microwave oven as they may create a fire or risk of electric shock. Do not clean with metal scouring pads. Pieces can burn off the pad and touch electrical parts involving a risk of electric shock.
- Page 11 USERS MANUAL...
- Page 12 GROUND INSTRUCTIONS Before you plug in an electrical cord or turn on power supply, make sure all controls are in the OFF position. WARNING Electric Shock Hazard Improper grounding can result in a risk of electric shock. Consult a qualified electrician if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.
-
Page 13: Grounding Instructions
grounding instructions This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. -
Page 14: Parts And Tools
PARTS AND TOOLS Before starting on the installation, prepare all the necessary tools and parts required to install the microwave. This will save installation time and simplify the installation process. Included Philips head screws Not Included Phillips screwdriver 1/8” drill bit Tape measure Electric drill... -
Page 15: Accessories 1
ACCESSORIES Accessories Turntab As a sur Food wh prepared The turn Place the compartm Never ■ The tu ■ The tu ■ Lower w Turntable For the m Food which particularly requires a lot of heat from underneath can be prepared directly Accessories on the turntable. -
Page 16: Installation Requirements
The outlet can be located anywhere within the shaded area. Anywhere within the shaded area, NOTICE: The cabinet base must be flat and the minimal distance between the appliance and capable of supporting a weight of at least 142 lbs the wall is 1¾... - Page 17 Model Connection Circuit grounde Requirements inside th 120 V, 20 Amps NEMA 5-20 Location RV-2400S 60 Hz circuit sh and conf Electrical Requirements: prevailin a three prong grounded outlet The volta ▯ this micr 120 V, 60 Hz, AC only ▯...
- Page 18 by the door handle. The door handle cannot support the weigh temperature change can cause damage. of the appliance and could break. Moist food: Do not store moist food in the closed cooking ■ Microwave popcorn: Never set the microwave power too high. ■...
-
Page 19: Outlet Area
Circuit grounded outlet. The outlet box sh Requirements inside the cabinet above the applia 120 V, 20 Amps RV-2400S NEMA 5-20 Location Requirements). The outle 60 Hz circuit should be installed by a qua and conform to the National Electri Electrical Requirements: prevailing local code. -
Page 20: Electrical Connection
Installation Requirements Building in Building In • Do not hold or carry the appliance by the door handle. The door handle cannot hold Carefully push the microwave into the cabinetry, making sure that it is in the center. the weight of the appliance and may break off. Do not kink the connecting cable. - Page 21 Installation Requirements tion Install Appliance This product must be connected to a supply circuit The appliance is heavy. It is advisable to install it with a second person. of the proper voltage and frequency. Wire size must ver is rated at 120V conform to the requirements of the National plug to connect to Electric Code or the prevailing local code for this...
-
Page 22: Your New Appliance
Installation Requirements Your new appliance Use this section to familiarise yourself with your new appliance. explained. You will find information on the cooking compartment The control panel and the individual operating controls are and the accessories. Control panel Touch keys and display Parameter The touch s are used to set the various additional functions. - Page 23 Parameter adjustment Installation Requirements nal functions. Use the adjusting keys to set the parameters. ave set. parameter function Auto menu Select 8 automatic programmes. rograms Weight Set the weight of cooking. ms for frozen Time time Se the of cooking. programs Select microwave power.100W,300W Microwave...
-
Page 24: Operation
Operation Setting the clock Once the appliance is connected, “12:00” will be displayed as the time of day. To set the correct time, proceed as follows: 2. Touch Clock. 3. Enter the correct time using the number keys. Example: To set the clock to 12:41 type in 1 2 4 1. 4. - Page 25 Operation Opening the oven door during operation Operation is suspended. After closing the door, touch the Start/Enter key. Operation +30 seconds continues. Cancelling operation Touch Clear/Off to cancel the active oven mode. The appliance turns off and the clock is displayed. 2.
-
Page 26: Suitable Ovenware
OPERATION Suitable ovenware Suitable dishes are heat-resistant ovenware made of glass, glass ceramic, porcelain, ceramic or heat-resistant plastic. These materials allow microwaves to pass through. You should only use ovenware with decorative gold or silver trim if the manufacturer guarantees that they are suitable for use in microwaves. Unsuitable ovenware Metal ovenware is unsuitable. - Page 27 function. Also you can open the door to cancel the function. Note: Only when you can hear alarm and preheating icon is blinking you can open the door and put food inside. Operation Microwave power settings You can select from 1 1 different microwave power levels. If you do not set a power level, the microwave will automatically operate at the highest power level 10.
-
Page 28: Setting The Microwave
OPERATION Change power le Power Microwave Use for You can change level output microwave opera … Cooking less tender cuts of meat Touch Power L Reheating frozen packaged foods Enter the desir Thawing meat, poultry & seafood „ Touch Start/En Cooking small quantities of food Microwave op Finish cooking casseroles,... - Page 29 Operation Opening the oven door during operation Operation is suspended. After closing the door, touch the Start/Enter key. Operation +30 seconds continues. Cancelling operation Touch Clear/Off to cancel the active oven mode. The appliance turns off and the clock is displayed. 2.
- Page 30 OPERATION Automatic programmes Setting a programme When you have selected a programme, set the oven. The temperature selector must be in the off position. 2. Touch Auto menu. 3. Touch Auto menu repeatedly to scroll through all Auto menu . 4.
-
Page 31: Defrosting Programmes
eight of your Program Weight range Food placement m setting. You 1 - Chicken Breasts 0.5 - 3.0 lbs Wire rack, facing down ment. Operation 2 - Chicken Thigh 0.5 - 3.0 Wire rack, facing down en. The 3 - Whole Poultry 1.5 - 4.5 lbs Turntable Defrosting programmes... - Page 32 OPERATION Popcorn Setting Froze Popcorn CAUTION The appliance Popcorn Touch Froz Do not leave oven unattended while popping corn. Do not leave oven unattended while popping corn. Popcorn may Setting Frozen F Popcorn may ignite and cause fire. You can cha CAUTION ignite and cause fire.
- Page 33 Operation Setting Beverage mode Touch Beverage. The cook time is displayed. 2. Touch Beverage repeatedly or touch number key 1 to 4 to choose the desired amount. 3. Touch Start/Enter. +30 seconds 4. The microwave timer starts counting down. When the microwave timer has elapse, a beep will sound.
- Page 34 Cancel operation Touch Clear/Off to cancel the active oven mode. The appliance turns off and the clock is displayed. yed. OPERATION The cooling fans may continue to run for awhile and then umber switch off automatically. Pizza Pizza You can use the Pizza mode to bake three different types own.
- Page 35 Operation Opening appliance door during operation Opening the appliance door during operation will interrupt the current mode. When you close the appliance door, operation will be resumed. Setting Pizza mode for microwave pizza Place the microwave pizza on the ceramic tray and put it in the oven following package directions.
-
Page 36: Sensor Cooking
OPERATION Sensor cooking You can select two sensor cooking modes. Sensor cooking allows you to cook many of your favorite foods without selecting cooking times and power levels. The microwave oven automatically determines the required cooking time for each food item. Food cooked with the sensor system should start from normal storage temperature. - Page 37 Operation at cooking suggestions Directions Quantity Reheat cooking suggestions er plate Use only pre-cooked, refrigerated foods. Cover plate with vented 1 serving (1 plate) Food Directions Quantity plastic wrap or waxed paper, tucked under plate. If food is not hot Dinner plate Use only pre-cooked, refrigerated foods.
- Page 38 OPERATION When sensing is complete, a beep will sound and the calculated cook time will start to count down. Do not open the door during the sensing process, or the program will be cancelled. WARNING: Once the calculated cook time is displayed, you can open the door to stir, turn or rearrange the food.
- Page 39 Operation Opening appliance door during operation Opening the appliance door during operation will interrupt the current mode. When you close the appliance door, operation will be resumed. Cancel operation Touch Clear/Off to cancel the active oven mode. The appliance turns off and the clock is displayed.
-
Page 40: Expert Cooking Guide
EXPERT COOKING GUIDE g foods. Once the oven is loss of heat. Place pans of food on the wire rack with the e oven quickly to minimize recess facing down. Cooking time Cooking tip / Procedure Cooking eggs in your microwave perature (minutes) °F (175°C) 13 - 20... - Page 41 The food was colder than usual. Stir or turn the food during cooking. Turntable grates or grinds. Dirt or debris in the area around the turntable Clean the rollers under the turntable and the drive. recess in the oven floor thoroughly. A particular operating mode or power The temperature, power level or combined Choose permitted settings.
- Page 42 (WEEE). The directive gives a framework for the (WEEE). The directive gives a framework for the Open the oven door as infrequently as possible while you are Open the oven door as infrequently as possible while you are ■ ■ collection and recycling of old appliances, which is valid collection and recycling of old appliances, which is valid cooking, baking or roasting.
-
Page 43: Cleaning And Maintenance
EXPERT COOKING GUIDE Cooking seafood in your microwave Be sure to place fish on a microwave-safe roasting rack in a microwave-safe dish. Be sure to always cook fish until it flakes easily with a fork. Use a tight cover to steam Cooking seafood in your microwave fish;... -
Page 44: Care And Cleaning
EXPERT COOKING GUIDE Care and cleaning Risk of electric shock! Penetrating moisture may cause an electric shock. Do not use any high-pressure cleaners or steam cleaners. WARNING: Risk of burns! Never clean the appliance immediately after switching off. Let the appliance cool down. WARNING: Risk of serious damage to health! Microwave energy may escape if the cooking compartment door or the door seal is damaged. -
Page 45: Maintenance
MAINTENANCE retain its Area Cleaning agents Appliance front Hot soapy water: Clean with a dish cloth and dry with a soft cloth. Do not use glass cleaners or metal or glass scrapers for cleaning. ot use Appliance front with Hot soapy water: stainless steel Clean with a dish cloth and dry with a soft cloth. -
Page 46: Childproof Lock
MAINTENANCE Childproof lock The oven has a childproof lock to prevent children switching it on accidentally. The oven will not react to any settings. The timer and clock can also be set when the childproof lock has been switched on. Switching on the childproof lock No cooking time should be set. -
Page 47: Troubleshooting
Troubleshooting nction table Problem Possible Cause Solution Malfunction table The appliance does not Faulty circuit breaker Look in the fuse box � often have simple explanations. Please refer to the Risk of electric shock! able before calling the after-sales service. work. - Page 48 Power cut Reset the clo ‹ ‹‹ plenty of cooking tips and tricks. ZLINE customer service is available at 1-614-777-5004. Power cut Check wheth The appliance does not work. Faulty circuit breaker. Look in the fu The microwave does not switch on.
- Page 52 Kitchen and Bath Three Locations: 350 Parr Circle Reno, NV 89512 916 Delaware Avenue Marysville, OH 43040 319 Rowland Mill Road Bruceton, TN 38317 www.zlinekitchen.com 1-614-777-5004...
