- Page 1 Microwave Oven Installation Guide and Users Manual...
-
Page 2: Specifications
Hinges and Latches (broken or loosened) WARNING Door seals and sealing surfaces The oven should not be adjusted or repaired by anyone except properly qualified service personnel. specifications Model: EM034DW1 Rated Voltage: 120V - 60Hz Rated Input Power: 1500W Rated Output Power: 1000W Oven Capacity: 1.0 Cu. -
Page 3: Important Safety Instructions
important safety instructions When using electrical appliances basic safety precautions should be followed, including the following: To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy read all instructions before using the appliance. This appliance must be grounded or connected to a properly grounded outlet. - Page 4 safety instructions continued Visible bubbling or boiling when the container is removed from the microwave oven is not always present. This could result in very hot liquid suddenly boiling over when the container is disturbed. WARNING To reduce the risk of injury to persons: Do not overheat liquid.
-
Page 5: Grounding Instructions
grounding instructions This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. -
Page 6: Radio Interference
radio interference Operation of the microwave oven may cause interference to your radio, TV, or similar equipment. When there is interference, it may be reduced or eliminated by taking the following measures: Clean door and sealing surface of the oven. Reorient the receiving antenna of radio or television. -
Page 7: Materials You Can Use In Microwave
materials you can use in microwave Utensils Usage Browning dish Follow manufacturer* instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped dishes. -
Page 8: Setting Up Your Oven
setting up your oven Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: : Control Patch : Control Box : Right Mounting Plate : Cavity : Handle : Windows : Door Frame : Automatic putter : Drawer : Hinge Joint Board... -
Page 9: Operation
operation ) Open ) Setup ) Auto Menu ) Defrost Weight ) Close ) Clock/Kitchen Timer ) Defrost Time ) Number Keys ) Power Start/+30sec. ) Time Cook ) Stop/Cancel Power on: When the microwave oven is plugged into an outlet, buzzer sounds once. Screen displays “WELCOME”. - Page 10 operation Kitchen Timer: Press “CLOCK/KITCHEN TIMER” button twice, Screen will display 00:00. “FUNCTION” will light. Press the number buttons to enter the time. The maximum cooking time is 99 minutes 99 seconds. Press “START/+30SEC.” to confirm the setting. . The time begins to count down. When the kitchen time arrives, buzzer will ring 5 times.
-
Page 11: Weight Defrost Function
operation Microwave Cooking Function: In waiting state, instant cooking at 100% power level with 30 seconds cooking time can be started by pressing “START/+30SEC”. Each press on the same button will increase cooking time by 30 seconds. During microwave and defrost by time, “START/+30SEC.” can be pressed to increase cooking time. - Page 12 operation Auto Menu-Popcorn: Press “POPCORN” button. Screen displays “1.75”. “AUTO MENU” and “OZ” indicators will light. Continue to press “POPCORN” button, “1.75”, “3” or “3.5” will display in order. Press “START/+30SEC.” to start cooking. Buzzer sounds once. “OZ” will go out. The cooking time begins to count down.
-
Page 13: Buzzer On/Off
operation Auto Menu-Melt: Press “MELT” button. Screen displays “BUTTER”. “AUTO MENU” indicator will light. Continue to press “MELT” button, “BUTTER”, “CHOCOLA”, “CHEESE” or “MARSHMA” will display in order. Press “START/+30SEC.” to confirm the selection. Press “MELT” button to select the weight. “OZ” will light except butter menu. Press “START/+30SEC.”... -
Page 14: Inquiring Function
operation Inquiring Function: (1) In cooking state, press “CLOCK/KITCHEN TIMER ” button to check the clock. The current time will display for 3 seconds. (2) In the microwave cooking state, press “POWER” button to inquire the microwave power. The current microwave power will display for 3 seconds. Other Specifications: The buzzer sounds once by efficient press, inefficient press will be no response. -
Page 15: Troubleshooting
troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. Trouble Possible Cause Possible Remedy Electrical cord is unplugged. Plug into the outlet. -
Page 16: Special Warning
Microwave Drawer install ation manual SPECIAL WARNING INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER. IMPORTANT: save this installation manual for local electrical inspector’s use. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. CLEARANCES AND DIMENSIONS For SAFETY CONSIDERATIONS do not install drawer in any combustible cabinetry, which is not in accordance with the stated clearances and dimensions on pages 2 and 3. - Page 17 CLEARANCES & DIMENSIONS Dimensions shown in Figure 1 must be used. Given dimensions provide minimum clearance. Locate electrical outlet in the shaded area in the upper left-hand corner of the cutout (also see Figure 3) Contact surface must be solid and level. The floor of the opening should be constructed of plywood strong enough to support the weight of the oven.
-
Page 19: Drawer Install Ation
DRAWER INSTALL ATION Figure 4 1. Place the drawer adjacent to the wall or cabinet opening. Plug the power supply cord into the electrical outlet. 2. Carefully guide the drawer into the prepared opening. Avoid pinching the cord between the oven and wall. 3. - Page 20 Three Locations: 350 Parr Circle Reno, NV 89512 916 Delaware Avenue Marysville, OH 43040 319 Rowland Mill Road Bruceton, TN 38317 www.zlinekitchen.com 1-614-777-5004 15 15...
