Page 1: Table Of Contents
After- Downl Get Star ted w App sales oads Power Your Devices Policy Prerequisites How to Connect Maximize Power Output Overview Find an Ideal Environment Wire Your Panels Storage and Maintenance Storage Cleaning What's in the Box Accessories https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 1/17... - Page 2 The panel has preset holes with an internal diameter of Preset holes 8mm. You can hang the panel with zip ties or hooks. Contains elastic straps, Bracket making it easy to adjust the panel's angle. https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 2/17...
- Page 3 It's recommended to stand behind the panel when unfolding it to save effort. Check the dot shadow on the solar angle guide to adjust the brackets, and let the https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 3/17...
-
Page 4: Power Your Devices
90° angle and the highest power output. Power Your Devices Prerequisites You can connect the panel to an EcoFlow portable power station to store power, or to an EcoFlow smart device to power the device directly. -
Page 5: How To Connect
Connect the other end of the charging cable to the solar input port (XT )³ the device to complete connection. If the port is not of the XT60 variety, refer to the device's user manual for connection instructions. https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 5/17... -
Page 6: Maximize Power Output
Make sure the cables were connected firmly before use to avoid port melting caused by bad connection. If the panel is connected to an EcoFlow device, you can check real-time output data on the screen of the device or on the device's homepage of EcoFlow app. -
Page 7: Wire Your Panels
Then, connect the solar to XT60i charging cable with the output cables of the first and the last panels. If the cables fall short, you can use solar extension cables for extra distances. https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 7/17... - Page 8 XT60i charging cable to the solar parallel connection cables. When connecting, refer to the instruction images to avoid misconnecting the male and female connectors of the parallel connection cables. Resulting Array Parameters Wiring solar panels of same ratings https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 8/17...
- Page 9 Same as the Total Adds up lowest value of Voltage the panels Same as the Total lowest value of Adds up Current the panels Equals the lowest Equals total Total current times current times the Power total voltage lowest voltage https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 9/17...
- Page 10 Solar port ratings of connected device The total voltage and the total current of the solar array should fall within the device's solar input range. When making your wiring plan, refer to the https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 10/17...
-
Page 11: Storage And Maintenance
If the panel is not in use, it's recommended to disconnect the panel, fold it, and put it away. For long-term storage, tie the output cable to avoid any contact with the photovoltaic module, and then fold the panel and put it back in the case. https://manuals.ecoflow.com/eu/product/160w-solar-panel?lang=en_US 11/17... -
Page 12: Cleaning
If the panel still generates no power after you exclude the factors above, contact EcoFlow's official customer service for help. . Can portable solar panels generate power with weak light, like on rainy days... -
Page 13: What's In The Box
160W Portable Solar Panel_User Manual monocrystalline cells, whose performance is restricted by weak light. . Is the panel compatible with all EcoFlow portable power stations? It depends on the electrical parameters of the panel and the solar input parameters of the power station. - Page 14 2024/5/13 18:13 160W Portable Solar Panel_User Manual Specifications Parameters Model EF-Fold-P160-04 Rated Power 160W (±5W) Open Circuit Voltage 21.3V Short Circuit Current 9.1A Optimal Operating 18.6V Voltage Optimal Operating 8.6A Current Recommended -20°C to 85°C Ambient Temperature Efficiency Temperature Coefficient of Rated -(0.30±0.02)%/°C...
- Page 15 EcoFlow is not liable for any loss caused by the user's failure to use the product in compliance with the product document.
- Page 16 2024/5/13 18:13 160W Portable Solar Panel_User Manual In compliance with laws and regulations, EcoFlow reserves the right to the final interpretation of this document and all documents related to the product. This document is subject to changes (updates, revisions, or termination) without prior notice.
- Page 17 10. When connecting this product in series or parallel, it is recommended that you purchase connecting wires through EcoFlow’s official sales channels. If you are using a third-party solar panel cable, make sure that the connector and the voltage and current of the cable are compatible.
