- Page 1 Range Road EcoPro 350 Owner’s Manual Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 2 DO NOT use the product until you have first contacted us to determine if it can or should be performed on the product. For technical questions please visit www.range-road.ca or www.range-road.com. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
-
Page 3: General Safety Rules
Be alert to your surroundings. Using a machine in confined work areas may put you dangerously close to rotating parts. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1... -
Page 4: Stay Alert
Store idle. When machine is not in use, store it in a secure place out of the reach of children. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1... -
Page 5: Important Safety Information
Use only lubricants and fuel recommended in the engine manual or in the Specifications Chart of this manual. CARBON MONOXIDE HAZARD !!! Using an engine indoors CAN KILL YOU IN MINUTES. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca... - Page 6 3. Wear ANSI-approved safety glasses, hearing protection, and NIOSH-approved dust mask/respirator under a full face shield during use. Wearing steel toe shoes is also recommended. 4. Wear heavy-duty work gloves when handling the blades. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1...
- Page 7 6. Use only accessories that are recommended by Range Road for your model. Accessories that may be suitable for one piece of equipment may become hazardous when used on another piece of equipment.
-
Page 8: Service Precautions
Wear approved safety goggles, heavy-duty gloves, and a dust mask/respirator during service. Maintain all labels on the saw mill. These show important information. If unreadable, missing or damaged, contact Range Road for a replacement. Have the equipment serviced by a qualified repair person using only OEM replacement parts. - Page 9 If you do not feel completely comfortable assembling it, please have a qualified technician assemble Undo the 4 nuts and bolts. One on each leg of top frame. See next picture. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1...
- Page 10 Lift top of metal crate off and move it out of the work area. Remove and unwrap components. Lift unit off of the crate. If using straps be careful not to bend or stress any components. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 11 Axle square should be out 10 ¾ inch on the side where the engine is mounted. The holes for mounting the fenders have to face up. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 12 Install cotter pin. The wheels can now be mounted, and the wheel nuts torqued at 75 ft/lbs. Top up tire pressures if needed to max. 44 PSI. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 13 Install the draw bar. Take out this bolt. Slide the draw bar into the square on the frame. Install that bolt. Tighten all 3 bolts. See picture next page. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 14 Install the stand. Mount the tongue jack. Set down the machine on the floor. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 15 Install the valve control set. Take out those bolts. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 16 Mount the valve. Find the sawdust chute. Mount the chute on the back side of the machine underneath the swivel plate with the saw motor. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 17 Install the small front cage. Take this bolt out. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 18 Place the end of the log holder spring in the hole of the log holder and install and tighten bolt. Find this bracket and install beside the small cage. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1...
- Page 19 There will be space between them. Install nut and bolt and cotter pin. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 20 Find the saw guard. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 21 Set the saw guard beside the cage. Install all the bolts and mount the saw guard to the cage. Adjust the latch on the front so the cage closes and can’t be opened. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 22 Find the tank for the saw oil. Install the tank on the back side of the saw guard. Connect the hose that comes from beside the saw motor to the tank valve. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 23 Take out those bolts. Find this tower and install with those bolts to where the bolts where in. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 24 Find the winch. Install the winch on the tower. Cable and hook towards the end of the machine. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 25 The safety pins are for the conveyor if installed. Install edge adjuster. Take out this bolt and washer. Slide this part through the mount behind the axle. Install the bolt and washer. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 26 Install the swivel bar. Take out this bolt and spring. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 27 Find the manual engagement lever. Install at the front of the machine. Install the wedge. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 28 Find those parts. This will be the tank mount. Mount them at the plate where the engine sits on. Both facing angles the outside making it shaped like a Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1...
- Page 29 This plate goes at he front of it. This frame will be mounted on the top of those side frames. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 30 The tank will be mounted on the top frame. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
- Page 31 Connect the fuel hose to the fuel filter on the top side of the engine. Install the fenders. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
-
Page 32: Start Procedure
Turn the power Switch of the equipment to its “OFF” position and wait for the engine to cool before performing any inspection, maintenance or cleaning procedures. Maintenance Procedures Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1... -
Page 33: Engine Maintenance And Service
5. For cold weather operation, store the equipment in a cool dry area to prevent condensation and premature wear. Equipment Troubleshooting Follow all safety precautions whenever diagnosing or servicing the equipment or engine. Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca... -
Page 34: Please Read The Following Carefully
Note: Some parts are listed and shown for illustration purposed only, and are not available individually as replacement parts. WARRANTY One-year limited warranty For technical questions, please visit www.range-road.ca www.range-road.com Range Road Enterprises Ltd Box 5 Site 9 RR1 Lacombe, AB T4L2N1 www.range-road.ca...
