CHECK WEIGHING MODE
For DGT1SX Models
USER MANUAL
ENGLISH
www.diniargeo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGT1SX and is the answer not in the manual?

Questions and answers

Related Manuals for Dini Argeo DGT1SX

Summary of Contents for Dini Argeo DGT1SX

  • Page 1 CHECK WEIGHING MODE For DGT1SX Models USER MANUAL ENGLISH www.diniargeo.com...
  • Page 2 © Dini Argeo. All rights reserved. Dini Argeo® is a registered trademark. Dini Argeo owns the copyright for the contents of this document (including artwork, illustrations, photographs, and written material). You may not copy, reproduce, modify, republish, or distribute any material from this document without permission.

  • Page 3: Table Of Contents

      20 Determine Photocell Type   21 Set Data Acquisition Trigger   22 Configure Additional Trigger Parameters   22 Photocell Data Measurement Settings   24 Data Measurement Settings (Excluding Photocells) Weight Data Capture   26 Load Weight Data   27 DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 4 Table 7 - Page 5019 Modbus Registers   44   44 Table 8 - Registers 42801 - 42818   46 Table 9 - Registers 42821 - 42844 Firmware Check and Update   48   48 Check DGT1SX Firmware:   48 Update Firmware DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 5: Introduction

    Thank you for purchasing a DINI ARGEO product. This document is intended to be read in conjunction with the DGT1SX User Manual. See DGT1SX User Manual for a list of all warnings, general installation, configuration and operation. This document details the check weighing mode for the DGT1SX.

  • Page 6: Introduction

    Select OK. When the DGT1SX is connecting to the computer, the XSpeed Tool connection indicator in bottom left corner turns green while the status bar fills. When the connection indicator is green and status bar is empty, the DGT1SX is connected to the computer.

  • Page 7: Calibration

    Check Weigh Mode. Scale settings configures units, maximum weight capacity, and resolution (divisions). Adjustment performs zero calibration and point calibration (with up to eight points). Calibration Procedure: Select Scale. Enable Independent channels mode. Turn off belt path. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 8 Configure the calibration point to match the calibration weight value. If needed, add additional points with weight values. Select Start Calibration. The busy indicator briefly displays. The text in the 0 Capture button turns white, indicating it is available. Select the 0 Capture button. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 9 The busy indicator displays briefly. Pnt.0 displays on the DGT1SX screen and ACQUISITION appears in XSpeed Tool. As 0 calibration completes, Pnt0.ok displays on the DGT1SX screen and ACQUISITION OK appears in the XSpeed Tool. The next Capture button turns white.

  • Page 10: Analysis Overview

    Displays the processed signal. Buttons that adjust the package measurement. Lists currently loaded weights and filters. Provides data acquisition parameters. Provides filter parameters and buttons. Provides measurement data and functions. Sends parameters to DGT1SX . Retrieves parameters from the DGT1SX. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 11: Weight Display

    Displays a raw data signal in relation to weight and time. Displays a data signal in relation to decibels and hertz. Displays all raw data signals in the weigh column overlaid upon one another in relation to weight and time. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 12: Graph Elements

    Expands measurement size left. Expands measurement size left and right. Expands measurement size right. Decreases measurement size left. Decreases measurement size left and right. Decreases measurement size right. Moves measurement left. Moves measurement right. Opens Check/Settings menu (see page 17). DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 13: Weights And Filters Elements

    Time, Trigger 7 ÷ 8 Time(s) Defines acquisition time duration in seconds. Trigger 1 ÷ 4 Start (g) Defines the package weight in grams required to start acquisition. Trigger 1 ÷ 4 Stop (g) Defines the package weight in grams to stop acquisition. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 14: Filter Parameters

    Clears all measurement parameters (including in settings). Starting time of measurement. Minimum weight during measurement. Average weight during measurement. Ending time of measurement. Maximum weight during measurement. Standard deviation of weights. Difference between start and end measurement times. Difference between maximum and minimum weight. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 15: Signal Overview (Photocells)

    Blue shading that indicates the measured area. The Measure area parameter is configured with the Check/Settings Menu, Measurement Adjustment controls, or Enable selection option. Green shading indicates the area that is skipped during measurement. The Final skipped data parameter is configured in Check/Settings Menu. A vertical red line that indicates the end of measurement. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 16: Signal Overview (Without Photocells)

    Menu, shape controls, or Enable selection option. A dashed orange line that moves along the fine filter (red line). This indicates weigh and time relative to cursor position. A solid horizontal orange line that indicates the configured weight threshold. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 17: Check/Settings Menu

    Check/Settings Menu The Check/Setting Menu configures analysis parameters that affect how signals are measured. The main sections are identified below and then subsequently defined. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 18 Not used with Check Weigh Mode applications. Not used with Check Weigh Mode applications. This section describes the area identified as C in the Check/Setting menu image. Element Description Exits the Check/Settings menu while saving changes. Exits Check/Settings menu and aborts changes. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 19: Determine And Set Suggested Adc Rate

    Select Calculate. The system provides a recommendation for weighing time and ADC rate. The suggested ADC rate displays. Select Ok to close the Check/Settings menu. Set the Rate parameter to match the suggested ADC rate (6, 12, 25, 50, 100, 200, 400, 800, 1600, 2400, or 4800 hertz). Select Send. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 20: Data Acquisition Trigger And Settings

    The following procedure is for use with photocells, advance to next procedure if not using photocells. Determine the photocell type by entering diagnostic mode on the DTG1SX and observe digital input signal changes when the photocell is clear and obstructed. Remove objects from the belt path and near photocells. Restart the DGT1SX. Press and hold when 888888 displays.

  • Page 21: Set Data Acquisition Trigger

    Systems with photocells can use any trigger, however Triggers 5 or 6 are typically used. Systems without photocells can use Start/Stop, Time, and Triggers 1 ÷ 4. If uncertain of which trigger to use, Trigger 1 is often a good starting point. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 22: Configure Additional Trigger Parameters

    A recommended starting parameter value is 10%. • The blue area represents the Measure data parameter. This is the percentage of data used for measurement. A recommended starting parameter value is 20%. These values may need to change during signal analysis. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 23 Select the Check/Settings menu icon. Configure Mode parameter (typically 2 Photocells High or 2 Photocells Low). Configure Final skipped data parameter. The recommended starting value is 10%. Configure Measured data parameter. The recommended starting value is 20%. Select Ok. Select Send. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 24: Data Measurement Settings (Excluding Photocells)

    The orange bar represents the Threshold parameter The following example is a Post-Trigger mode, where: • The blue area represents the Measuring time parameter • The green area represents the Setting time parameter • The orange bar represents the Threshold parameter DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 25 The following procedure is typically for systems without photocells, return to the previous procedure if using photocells. Select the Check/Settings menu icon. Set the Mode: Configure the weight Threshold parameter in grams. Configure the Setting time in seconds. Configure the Measuring time in seconds. Select Ok. Select Send. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 26: Weight Data Capture

    In the prompt, navigate to the desired folder, enter the file name, then select Save. Note: The weight is saved as an *.xsd file (XSpeed Tool data file). Repeat the steps to process at least four additional packages and save their data. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 27: Load Weight Data

    Select Load in the Weighs column. The Data File window prompt. Navigate to the file, select the file, and then select Open. Data loads in the XSpeed Tool and the weight displays in the Weighs column. Repeat the procedure for additional data files . DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 28: Signal Analysis

    Send the configuration to the instrument when completed. Signal Analysis (with Photocell Data) Process or load data for at least 5 weights. Adjust Coarse and Fine filters to the suggested starting points: • Coarse Filter 3 Hz • Fine Filter 10 % DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 29 Repeat until coarse filter (green line) is straight as and noise free as possible. Adjust Fine filter. Select Refresh button and observe changes to the red line. Repeat until Fine filter (red line) is straight as and noise free as possible. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 30 View weight differences of each measurement in the Weighs column. Ideally, the weights are as close to each other as possible. If required, adjust the Measuring data parameter. Adjust filters until smallest difference between weights is achieved. Select Send. Proceed to testing. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 31: Signal Analysis (Without Photocell Data)

    Adjust Coarse and Fine filters to suggested starting points: • Coarse Filter 3 Hz • Fine Filter 10 % Adjust the Coarse filter. Select Refresh button and observe changes to the green line. Repeat until Coarse filter (green line) is straight and noise free as possible. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 32 If required, adjust the Measuring time parameter. View weight differences of each measurement in the Weighs column. Ideally, the weights are as close to each other as possible. Adjust filters until smallest difference between weights is achieved. Select Send. Proceed to testing. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 33: Signal Analysis - Enable Selection

    This procedure is the same for data with photocells. Load or process 5 data samples. Enable Raw Data or Overlap mode. Roll the mouse wheel to zoom in on the desired area. Use the scroll bars to adjust the view of the signal. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 34 Repeat until filters are flat as and noise free as possible. If needed, enable Overlap mode. View weight differences of each measurement in the Weighs column. Ideally, the weights are as close to each other as possible. Adjust filters until smallest difference between weights is achieved. Select Send. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 35: Testing

    − Adjust the Correction offset parameter (to account for the weight that caused the package to fail), and then Send the parameters. − Reprocess the package. If it passes, proceed to next step; if it fails, repeat this step until the package passes. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 36 If packages fail (highlight red) adjust and Send the Correction offset parameter and reprocess the packages until they pass. Process several packages that are underweight and overweight (greater than the tolerance) and verify they fail. If underweight or overweight packages pass, adjust and Send the Correction offset parameter and reprocess the packages until they fail. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 37: Fiedlbus Registers

    Fiedlbus Registers There are several register pages (2020, 2021, 2022, 5017, 5018, and 5019) for the DGT1SX. Each of these pages begin with the following 16 bytes: Table 1 - First 16 Bytes Byte Name Gross weight (B3) - (*)
  • Page 38 Weights placed in the queue (B0) (write zero to reset) Weights lost due to full queue (B1) Weights lost due to full queue (B0) Weight 1 (B3) Weight 1 (B2) Weight 1 (B1) Weight 1 (B0) Weight 2 (B3) Weight 2 (B2) Weight 2 (B1) Weight 2 (B0) DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 39 Weight 3 (B0) Weight 4 (B3) Weight 4 (B2) Weight 4 (B1) Weight 4 (B0) Weight 5 (B3) Weight 5 (B2) Weight 5 (B1) Weight 5 (B0) Weight 6 (B3) Weight 6 (B2) Weight 6 (B1) Weight 6 (B0) DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 40 The most significant bit of each weight value is set to 1 in the case of acquisition error so it is to be considered invalid. In the case of float data format if there is an acquisition error the stored value will be negative. All values are lost when the indicator is turned off. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 41 Average time counter (B1) Average time counter (B0) Check mode values follow: Value Mode None Pre trigger Post Trigger 2 Photocells High (*) 2 Photocells Low (*) * High/Low is the status of the digital input when the photocell is obstructed. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 42 Counter for auto reset weigh list (B0). Reference weight calculation mode (B1) Reference weight calculation mode (B0) Weight reference setting time counter (B1) Weight reference setting time counter (B0) Weight reference average time counter (B1) Weight reference average time counter (B0) DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 43 Automatic zero intervention time interval (sec) (B0) 23 - 32 To set the data, write values to the same positions and use the WRITE_SETUP command (27) with parameter 1 equal to 5019. To make the changes permanent use the WRITE_FLASH command (28). DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 44: Modbus Registers

    Counter for auto zeroing of weighing list. 0 (disabled) ÷ 10 42813 Reference weight calculation mode 42814 Reference weight setting time counter 42815 Reference weight average time counter 42816 Automatic zero range (H) 42817 Automatic zero range (L) 42818 Automatic zero time interval (sec) DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 45 Reference weight calculation mode: Value Mode None Post End trigger Pre Start trigger 2 photocells high (*) 2 photocells low (*) * High/Low is the level of the digital input when the photocell is obstructed. To save the configuration, use command 28. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 46 Weight 6 (H) 42836 Weight 6 (L) 42837 Weight 7 (H) 42838 Weight 7 (L) 42839 Weight 8 (H) 42840 Weight 8 (L) 42841 Weight 9 (H) 42842 Weight 9 (L) 42843 Weight 10 (H) 42844 Weight 10 (L) DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 47 The general counter is zeroed by writing the zero value to register 42822 or by means of command 74. The most significant bit of each weight value is set to 1 in the case of an error in the acquisition so it is to be considered invalid. All values are lost when the indicator is turned off. DGT1SX-CHECK_01.19_23.08_EN_U...

  • Page 48: Firmware Check And Update

    Micro-USB cable • Firmware update tool To update a DGT1SX with older firmware without check weigh mode, contact sales to purchase new firmware. Download the firmware update tool. Connect the DGT1SX to a Windows computer. Launch the firmware update executable.
  • Page 49 Select OK to close the pop-up window. Unplug the USB cable from the DGT1SX. Power cycle the DGT1SX. Default the device after the firmware upgrade is complete. 888888 f.mode Setup ConfiG defau Setup the DGT1SX as described in DGT1SX User Manual. DGT1SX-CHECK_01.19_23.08_EN_U...
  • Page 50 The Manufacturer declines all responsibility for any weighing errors. DGT1SX-CHECK_01.19_23.08_EN_U...
