Harper Corner TV Fire Stand
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-41901
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 014-HG-41901 and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze 014-HG-41901

Summary of Contents for Belleze 014-HG-41901

  • Page 1 Harper Corner TV Fire Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41901 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 90 mins Weight limitations are as follows: Maximum Load 60 lb Maximum Load 15 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Left Side Panel Left Medial Panel Right Medial Panel Right Side Panel Back Panel Crossbar Top Surround Panel Left Surround Panel Right Surround Panel Bottom Panel Left Cabinet Door Right Cabinet Door Storage Shelf Panel Leg Crossbar Leg Crossbar Drawer Left Panel...
  • Page 6 PACKAGE CONTENTS 11x + 1x 21x + 2x 21x + 2x 30x + 3x 24 + 2x Install all hardware perpendicular to the opening.
  • Page 8 Required tools for assembly (Not included) Attach cam bolts to the top panel (1) and the drawer front panel (24). v.09112023U...
  • Page 9 Attach cam bolts to the medial panels (3, 4). Attach slider brackets to the medial panels (3, 4).
  • Page 10 Insert wood dowels to the medial panels (3, 4), crossbar (7) and right surround panel (10). Assemble the surround panels (8, 9, 10) to the medial panels (3, 4) and the crossbar (7). v.09112023U...
  • Page 11 Assemble back panel (6) and crossbar (7) to the right medial panel (4). Insert wood dowels the medial panels, back panel, top surround panel, and crossbar.
  • Page 12 Assemble the left medial panel (3) to the assembly. Insert wood dowels to the side panels (2, 5), then assemble the side panels and medial panels onto the bottom panel (11). v.09112023U...
  • Page 13 Assemble the legs (15, 16, 17) to the leg crossbar (18, 19). Note:Leave bolts 80% tightened. Attach the leg assembly under the stand. Note:Tighten all the bolts.
  • Page 14 Place the stand on its upright position and insert wood dowels to the top of the stand. For the exact instruction, refer to the user's manual provided with the replace. Note:Screws are provided in the heater package. v.09112023U...
  • Page 15 Attach the top panel (1) on top of the stand.
  • Page 16 Insert shelf pegs into the stand and put on the storage shelf panel (14). v.09112023U...
  • Page 17 Attach door hinges to the cabinet doors (12, 13). Attach door handles to the cabinet doors (12, 13).
  • Page 18 Attach the cabinet doors to the stand. When the clearance of the door is uneven, Adjust the cabinet door according to the gure,lf you still have trouble while adjusting the door,please contact us. Up and d In and out adjustment Side to side adjustment adjustment by by loosening the screws...
  • Page 19 Assemble the drawer left, right, and support panels (20, 22, 25) to the drawer front panel (24).
  • Page 20 Slide in the drawer bottom panel (21). Assemble the drawer back panel (23) to the drawer.
  • Page 21 Attach handle to the drawer front panel (24). Attach sliders to the bottom of the drawer. v.09112023U...
  • Page 22 Slide the drawer into the stand.
  • Page 24 YOU’RE FINISHED!
  • Page 25 Warning Serious or fatal crushing injuries may occur if the furniture tip-over. order to prevent the furniture from tipping over. stability and load bearing capacity of the furniture. If you are uncertain about which type of device to use, please contact us or your local hardware store. Warning Only place items on top of the product if they meet the recommended size and weight limits.
  • Page 26 60lbs(27.2kg)

  • Page 27: Maintenance

    FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
  • Page 28 © All copyright of this document belongs to BELLEZE. This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.09112023U...

  • Page 29: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
