7.4 DRAWINGS
The following assembly drawings (with parts lists) and
schematics are in the arrangement shown below.
7.2 ORDERING PARTS
When ordering spare parts, please specify part
number, circuit reference, board, serial number of
unit, and, if applicable, the function performed.
Drawing
Instrument Schematic
Chassis Assembly
Chassis Parts List
Generator Board Schematic
Generator Board Assembly
Generator Board Parts List
Sweep Board Schematic
Sweep Board Assembly
Sweep Board Parts List
SECTION 7
PARTS AND SCHEMATICS
7.3 ADDENDA
Under Wavetek's product improvement program, the
latest electronic designs and circuits are incorporated
into each Wavetek instrument as quickly as develop-
ment and testing permit. Because of the time needed
to compose and print instruction manuals, it is not
always possible to include the most recent changes in
the initial printing. Whenever this occurs, addendum
pages are prepared to summarize the changes made
and are inserted immediately inside the rear cover. If
no such pages exist, the manual is correct as printed.
Drawing No.
0004-00-0166
0102-00-0837
1101-00-0837
0103-00-0835
1100-00-0835
1100-00-0835
0103-00-0818
1100-00-0818
1100-00-0818
