- Page 1 ASENTO INST AL L AT IO N MANUAL EV- RNG 19R FORD RANGER 2019 & UP PASSENGER SIDE...
- Page 2 EV600B-06R Pillar Trim -Right- Black EV-RNG19R-00 Installation Kit -Right- EV-RNG19RB-03 Floor Cover -Right- Black EV-RNG19RB-04 Seat Trim -Right- Black EV700-AL Electrical Kit PART NUMBER EV-RNG19R DESCRIPTION ASENTO Ford Ranger 2019 & Up -Right- 1 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 3 Socket Head Cap Screw Zinc Plated 1/4-20 UNC x 7/8" PRD 338-169P Flat Head Socket Cap Screw Zinc Plated 1/4-20 x 1 PRD 333-105 Nylon Insert Locknut 1/4-20 PART NUMBER EV-RNG19R DESCRIPTION ASENTO Ford Ranger 2019 & Up -Right- 2 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 4 Flat Washer Zinc Plated I.D. 3/16 USS PRD 400-583 Pan Head Machine Screw Phillips Stainless 10-24 x 5/8 PRD 400-289 Nylon Insert Locknut Stainless 10-24 PART NUMBER EV-RNG19R DESCRIPTION ASENTO Ford Ranger 2019 & Up -Right- 3 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 Hex Cap Bolt Zinc Plated 3/8-16 x 1 1/4 G5 SN 190-025 Binder Slot Head Post & Screw Black ,250 x ½"Lg SCALE 1:3 SCALE 1:3 PART NUMBER EV-RNG19R DESCRIPTION ASENTO Ford Ranger 2019 & Up -Right- 4 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 Transfer Plate Cushion -Right- Black EV300-05R Safety Arm - Right - U-EV-UNI-01 Machined Socket Shoulder Screw PRD 333-107M Nylon Insert Locknut 5/16-18 Thin PART NUMBER EV-RNG19R DESCRIPTION ASENTO Ford Ranger 2019 & Up -Right- 5 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 7 1. Remove the lower b-pillar trim. To do this, first, remove the rocker panel trims adjacent to the front driver and mid-row passenger’s doors.
- Page 8 NOTE: Drill slowly through the high strength steel using a 3/16 drill bit. 3. A ¾-inch hole will have to be drilled in the lower b pillar trim to be able to bolt the ASENTO to the b pillar adaptor. Mark the hole to be drilled by partially installing the lower b pillar trim and hitting it against the pointed allen screw to mark it for drilling.
- Page 9 4. Run the power from the battery to the ASENTO. To do this, thread the red power cable (+) under the doorstep moulding and through the firewall. Make sure you pass through a grommet in the firewall to prevent the cable from chaffing. Install the circuit breaker near the battery and then connect the battery to the circuit breaker.
- Page 10 6. Remove the two rear seat bolts, and the bolt holding the seat belt. Install the ASENTO floor adapter EV-RNG19R-01) use the provided M10x1.5x40 mm bolt for the seat belt, and reuse the OEM bolts at the rear seat floor mounting points.
- Page 11 7. Reinstall the b pillar trim. 8. Insert the provided carpet cover into the part cut out of the b pillar trim.
- Page 12 9. Remove the left hand side seat trim. It will have to be cut, and the provided plastic replacement trim EV-RNG19RB-04) installed on to it.
- Page 13 10. Reinstall the modified seat trim. 11. Install the ASENTO to the floor bracket using the 3/8"-16 x 2" bolt and to the b pillar using the 3/8- 16 x 1 1/4" bolt. Run the wire to be connected to the control box under the adapter.
- Page 14 12. Attach the seat belt to the bottom of the ASENTO with a zip tie. 13. Install the transfer board onto the ASENTO by sidling it onto the round rod, use a little grease on the rod. Install the security handle using the provided shoulder bolt and nut.
- Page 15 PROGRAMMING ASENTO 15. Before the ASENTO can be used, it will have to be programmed. Once the control box is connected to the 12-volt power supply and has beeped to signify that it is active, the ASENTO will be in a reduced power mode.
-
Page 16: Final Inspection
Make sure that ASENTO works well with and without a passenger. Make sure the door closes properly. (Note: It is normal for the ASENTO to touch the door panel trim.) Please note that our Technical Support Department is available Monday thru Friday from 7:30 am to 5:00 pm. - Page 17 ECTRICAL BOX CONNECTIONS ASENTO...
- Page 18 ASENTO WIT H SPEEDY-LIFT...
-
Page 19: Warning Decals
WARNING DECALS After completing the installation of the ASENTO, please take time to install the warning decals. NOTE: The surface must be clean, dry and at ambient temperature for the sticker to stick to the surface. Start by locating a position to install the decals. - Page 20 Fre ig ht a nd o the r re la te d re p a ir c ha rg e s will b e the re sp o nsib ility o f the o rig ina l p urc ha se r. T he o nly re me d y fo r a d e fe c t in o ne o f Ad a p t So lutio ns p ro d uc ts ( XL-BASE; XL-SEAT; ASENTO; HI-LIFT; SPEEDY- LIFT;...
