How To Put It Together

The only tool you'll need to assemble your vacuum
cleaner is a screwdriver.

Attach Handle To Vacuum

Locate the vacuum Handle and remove the screw
1.
packet taped to the base of the Handle.
Stand the vacuum upright and slide the base of
2.
the Handle firmly into the grooves at the top of the
vacuum body.
Check to be sure the Handle is fitted to the vacuum
3.
body. If there is a gap in front, continue to push firmly
until the Handle is flush.
Insert the screw provided from the screw packet into the
4.
existing hole. Tighten securely with a screwdriver.

Attach Vacuum Hose and Tools

Attach the Twist 'n Snap ™ Hose by lining up the tabs on
1.
the base with the corresponding notches on the back of
the vacuum as shown.
Turn the Twist 'n Snap Hose to the right to lock the hose
2.
into place.
Snap Hose Clip onto Upper Handle (select models only).
3.
Grasping the Quick Reach Handle, slide the end of the
4.
Hose Wand onto the Hose Wand Base. Snap the Hose
into the Hose Clip.
nOTE: The Powerfoot will not operate
effectively unless the Hose Wand is
firmly attached.
Snap the Extension Wand and the Crevice Tool together
5.
into the storage clip as shown.
Snap the Combination Tool into the storage clip as shown.
6.
®
Attach the TurboBrush by aligning the small holes near the
7.
brush roll with the tabs at the bottom of TurboBrush housing.
Snap TurboBrush into place as shown.
Select Models Only
5
