SSV Works DF-US10U Quick Start Manual

Underseat subwoofer enclosure 10” - unloaded for 2018-up canam defender
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or
workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in
material or workmanship. All SSV Works Speakers are covered by a limited 1 year warranty against
defects in material or workmanship. Labor for replacement of defective components is not covered.
Contact SSV Works for further warranty information.
4 DOOR
DF-US10U
2018-Up CanAm Defender
Underseat Subwoofer Enclosure
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
2 DOOR
10" - Unloaded

Advertisement

loading
Need help?

Need help?

Do you have a question about the DF-US10U and is the answer not in the manual?

Questions and answers

Related Manuals for SSV Works DF-US10U

Summary of Contents for SSV Works DF-US10U

  • Page 1 WARRANTY INFORMATION: Please read and understand these All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or instructions completely before workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in installation to avoid possible injury, or material or workmanship.
  • Page 2 UNDER REAR SEAT SUB WOOFER ENCLOSURE PARTS LIST PARTS LIST IMAGES DF-US10U Enclosure Bracket Pack (B-MBP3315) M6x1 x 16,Torx Pan Head Screws and Washers,6 pack [B-HP1317] M6x1 x 16,Torx Pan Head M6x1 x 60mm Screw Plastic Thread Forming Screw Screws and Washers,4 pack...

  • Page 3: Tools Needed For Installation

    - Phillips Screw Driver INSTALLATION NOTE: The SSV Works DF-US10 Defender Subwoofer Enclosure can be mounted under the driver seat on 2 door models and under the driver side front and rear seats on 4 door models. A. Stick the 6 vibration pads to the bottom side of the enclosure.
  • Page 4 UNDERSEAT SUBWOOFER ENCLOSURE INSTALLATION (4 Door Models) TOOLS NEEDED FOR INSTALLATION - T30 Torx Driver - Philips Screw Driver A. Lift middle seat and remove underseat storage bin. B. Remove the driver side underseat storage bin by removing the 2 screws fastened to the floor.
  • Page 5 UNDERSEAT SUBWOOFER ENCLOSURE INSTALLATION (4 Door Models) G. Place the Defender sub enclosure under the seat and run the cable H. Use the factory screw to fasten bracket C to the U-Nut. Do not towards the amplifier location. completely tighten yet. I.
  • Page 6 UNDERSEAT SUBWOOFER ENCLOSURE INSTALLATION (4 Door Models) Note that the DF-US10 Defender subwoofer enclosure can also be installed under the driver side rear seat on 4 door models. Follow the installation steps outlined for the 2 door models. UNDERSEAT SUBWOOFER ENCLOSURE INSTALLATION (2 Door Models) TOOLS NEEDED FOR INSTALLATION - T30 Torx Driver - Philips Screw Driver...
  • Page 7 UNDERSEAT SUBWOOFER WIRING DIAGRAM Description Part # Detail Description Amplifier (not included) Connect DF-US10U to the amplifier Defender Underseat Subwoofer Enclosure DF-US10U © 2024 SSV Works, Oxnard, CA 93030 DF-US10 Rev. A 1-12-24...
