SSV Works RZ3-GB10 Manual

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects
in material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. All SSV Works Speakers are
covered by a limited 1 year warranty against defects in material or workmanship. Labor
for replacement of defective components is not covered. Contact SSV Works for further
warranty information.
TOOLS NEEDED FOR INSTALLATION
- Wire Crimpers
- Wire Strippers
- 10mm Socket or Wrench
- Drill with 1/8" and 1/4" Drill bits
PARTS LIST IMAGES
1. WP-RZ3GBS10 Enclosure
(door not included)
5. Flat Mounting
Brackets x 2
INSTALLATION NOTES
The use of a thread locker is recommended on all screws to prevent loosening due to vibration. If the vehicle has SSV Works front kick panels
(RZ3-FKP65/RZ3-F65) installed, the passenger side kick panel will need to be removed prior to installation of the RZ3-GB10. Removal of the
passenger fender is not required (Step 3); however it will make the installation and alignment of the RZ3-GB10 easier.
- T-30 Torx Driver
- T-40 Torx Driver
- #3 Phillips Screwdriver
- #2 Phillips Screwdriver
- Panel removal tool
2. M6 x 1.0 Screws x 11
(Long)
6. "L" Bracket x 1
RZR XP1000 & 2015+ RZR900
Glove Box Subwoofer Enclosure
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
PARTS LIST
1. WP-RZ3GBS10 Enclosure
2. M6 x 1.0 Screws x 11
(Long)
3. M6 x 1.0 Screws x 2 (Short)
3. M6 x 8mm Screws x 2
(Short)
7. Glove Box Door
Bracket x 1
RZ3-GB10
4. M6 Washers x 13
5. Flat Mounting Brackets x 2
6. "L" Bracket x 1
7. Glove Box Door bracket x 1
4. M6 Washers x 13
