SSV Works US2-C65 Instructions

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or
workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects
in material or workmanship. Labor for replacement of defective components is not covered. All
SSV Works Speakers are covered by a limited 1 year warranty against defects in material or
workmanship. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- 5mm Allen Key
- 3mm Allen Key
PARTS LIST IMAGES
1. US2-C65 Enclosures (1 pair)
5. M6 Hex Head Bolts &
Washers x4
INSTALLATION NOTES
It is recommended to wrap the
bag that the clamps come in
around the cage before you
slide the clamp onto the cage to
prevent scratching.
- 8mm Open End Wrench
- #2 Phillips Screwdriver
2. Dual Mounting Ring
Adapter x 2
6. M6 Allen Socket Head Bolts
& Washers x4
Figure 1
SSV Works 6.5" Speaker Enclosures
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
Placement of the pod depends on what type of roll
cage you have (factory or aftermarket) and your
preference of where you want the pods to be installed.
In these instructions, we have installed them on the
outside vertical bars at the back of the roll cage.
3. Ring Clamp x 4
7. M6 Set Screws x 8
FOR UNLOADED ENCLOSURES:
If using a different brand speaker, first see if
the speaker holes line up with the screw bosses
(circled in pink on Figure 1). Be sure to use the
8 supplied SSV Works #7 screws when installing
your own speaker.
US2-C65
Universal Cage Mount
4. Aftermarket Speaker Adapter
(comes with unloaded pods only)
8. #7 Screws x 8
(comes with unloaded pods only)
